Page 1: Network Camera
NETWORK CAMERA Model: IKS-WP806 User’s Manual For information on our latest products and peripheral devices, refer to the following web site: www.toshibasecurity.com If the URL changes, refer to www.toshiba.com 31970AC... - Page 3 This documentation is copyrighted. All other rights are reserved to TOSHIBA. TOSHIBA, and Surveillix are registered trademarks of TOSHIBA in the United States and elsewhere; Windows and Windows XP Embedded are registered trademarks of Microsoft Corporation. All other brand and product names are trademarks or registered trademarks of the respective owners.
-
Page 4: Important Safeguards
Important Safeguards Read Instructions Read all the safety and operating instructions before operating the product. Retain Instructions Retain the safety instructions and user's manual for future reference. Warnings Comply with all warnings on the product and in the user's manual. Follow Instructions Follow all operating and use instructions. - Page 5 Install this camera on a secure part of the ceiling or wall. If installed on an unsecured location the camera could fall causing injury and damage. 13. Lightning For additional protection on this camera during a lightning storm, or when it is left unattended and unused for long periods of time, unplug it from the wall outlet and disconnect the power supply and cable system.
- Page 6 Upon completion of any service or repairs to this camera, ask the service technician to perform safety checks to determine that the camera is in proper operating condition. Precautions Operating Before using, make sure power supply and others are properly connected. ...
- Page 7 Installation and Storage Do not install the camera in areas of extreme temperatures in excess of the allowable range. (14°F~ 122°F / -10°C ~ 50°C) Avoid installing in humid or dusty places. The relative humidity must be below 90%.
- Page 8 Protection of Personal Information Images taken by the camera that reveal the likeness of an individual person may be considered personal information. To disclose, exhibit or transmit those images over the internet or otherwise, consent of the person may be required. Usage Limitation ...
- Page 9 This symbol on the product or on its packaging indicates that this product shall not be treated as household waste in accordance with Directive 2002/96/EC. Instead it shall be handed over to the applicable collection point for the recycling of electrical and electronic equipment. By proper waste handling of this product you ensure that it has no negative consequences for the environment and human health, which could otherwise be caused if this product is thrown into the garbage...
- Page 10 Warning TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT EXPOSE THIS APPLIANCE TO RAIN OR MOISTURE. DANGEROUS HIGH VOLTAGES ARE PRESENT INSIDE THE ENCLOSURE. DO NOT OPEN THE CABINET. THIS INSTALLATION SHOULD BE MADE BY A QUALIFIED SERVICE PERSON AND SHOULD CONFORM TO ALL LOCAL CODES.
-
Page 11: Table Of Contents
Mounting Accessories ........................22 Installation with Indoor Pendant Mount ..................22 Installation with Ceiling Flush Mount Kit ..................23 Locate Camera ............................24 Surveillix Device Search ........................24 Installation ............................24 Starting Device search ........................24 Device Addressing ........................... 25 ... - Page 12 System ............................. 32 System ............................32 Security ............................34 Admin Password ........................34 Add User ..........................35 Delete User ........................... 35 Edit User ..........................35 Network ............................36 Get IP address automatically (DHCP) .................. 36 Use fixed IP address ......................36 QoS (Quality of Service) .......................
- Page 13 Server Gain Settings ......................66 Bit Rate ..........................67 PTZ Settings ............................68 Preset .............................. 68 Preset Setting ..........................68 Preset Go ........................... 69 Pattern ............................. 69 Pattern Setting..........................69 Pattern Run ..........................70 Auto Scan ............................70 Auto Scan Setting........................71 Auto Scan Run ...........................
-
Page 14: Introduction
INTRODUCTION OVERVIEW The IKS-WP806 is an IP PTZ camera capable of resolutions up to 1080p. The IKS- WP806 IP camera can transmit video at H.264 and MJPEG codecs. With digital wide dynamic rage, the IKS-WP806 is an excellent choice for installations with difficult lighting conditions. -
Page 15: Getting Started
GETTING STARTED CAMERA CONTENTS Before proceeding, please check that the box contains the items listed here. If any item is missing or has defects, DO NOT install or operate the product and contact your dealer for assistance. Dome Body Optical Cover Screws Quick Start Guide Hard Ceiling Mount... -
Page 16: Dome Setup And Cable Connection
DOME SETUP AND CABLE CONNECTION Before installing or connecting the dome camera, please refer to this section and complete preparations for dome setup and all switch settings. Dome Camera Setup Switch Definition Alarm input/output Reset button Setting switch Power Audio connection RJ-45 Connector SD card slot Note... -
Page 17: Dome Cable Definition And Requirements
For operation, the IP dome camera requires a network cable to carry the video signals to the remote viewing site and a power cable to power the dome. The IKS-WP806 IP camera is capable of using Power over Ethernet + or 24vAC power. -
Page 18: Ethernet Cable Connection
Ethernet Cable Connection Connect one end of the CAT 5 Ethernet cable to the RJ-45 connector of the camera and the other end of the cable to the network switch or recorder. Note In some cases, you may need to use an Ethernet crossover cable when connecting the camera directly to the recorder. -
Page 19: 12-Pin Alarm Input/Output Connection
12-Pin Alarm Input/Output Connection Using the 12-pin connector, installers can connect 4 digital alarm inputs and 2 digital alarm outputs. The alarm pins are serviceable for connecting alarm input and output devices such as sensors, sirens, or flashing lights to the surveillance system. For the definition of each pin, refer to the list below. -
Page 20: Dome Installation
DOME INSTALLATION OVERVIEW Depending on your installation environment, the dome can be installed on the ceiling, on a wall, or a pole. The following section illustrates installation methods and procedures for installing the dome and mounting accessories. DOME DIMENSIONS The dome dimensions are Ø6.5” (165.1 mm) x 8.6” (219.1 mm). -
Page 21: Installation
INSTALLATION You can install your IKS-WP806 using the included Hard Ceiling Mount or Pendant Mount. Installation with Hard Ceiling Mount Mark the positions of the three screw holes in the Hard Ceiling Mount at your chosen location. Drill each hole using a 3/16” bit. -
Page 22: Optional Accessories
OPTIONAL ACCESSORIES Mounting Accessories Ceiling Flush Mount Kit Part Number: JK-MFMK 1 ½” Threaded Adapter Part Number: JK-510PA50 1 ¼” Threaded Adapter Part Number: JK-510PA25 Large Pole Mount Part Number: JK-510PML 50 cm Pole Part Number: JK-510P50 25 cm Pole Part Number: JK-510P25 Corner Mounting Plate Part Number: JK-510C... -
Page 23: Installation With Ceiling Flush Mount Kit
Installation with Ceiling Flush Mount Kit The Ceiling Flush Mount Kit consists of three pieces: the in-ceiling mount, the camera bracket, and the trim ring. Attach the camera to the Hard Ceiling Mount that is affixed to the camera bracket. Tighten the screw on the side of the camera to secure it to the camera bracket. -
Page 24: Locate Camera
LOCATE CAMERA SURVEILLIX DEVICE SEARCH Use the included Device search software to easily find your network cameras for initial setup. The Surveillix Device Search software is included on the CD with all Surveillix IP devices. Installation You can install Device search on any personal computer (PC) or laptop using the software CD included with your Surveillix IP camera or by downloading the program from toshibasecurity.com. -
Page 25: Device Addressing
Device Addressing The functions on the Device Addressing tab allow you to find, configure, and view network cameras. Finding Network Devices Click Device Search. To narrow your search by Camera Model, Project, or Camera Name, select your desired criteria from the appropriate lists. -
Page 26: Setup & Configuration
SETUP & CONFIGURATION CONNECTING TO THE CAMERA Locate the camera on the Device search list. Double-click the camera to open the Viewer software in your web browser. Log in to the camera with the appropriate User Name and Password. Note The default User name is Admin and the default Password is 1234. -
Page 27: Connecting A Stream
Surveillix IP cameras using third party software like VLC media player (http://www.videolan.org). To connect the camera you may need to provide the stream URL. All Surveillix IP cameras are capable of delivering two RTSP streams, as well as streaming MJPEG over HTTP. -
Page 28: Connecting Over The Internet
You may experience some challenges connecting to Surveillix IP cameras over a Wide Area Network (WAN) connection. This is due to the fact that the IKS-WP806 streams video over RTSP. RTSP is an excellent protocol for media and is now used on many IP cameras (including Surveillix) as the default streaming option. -
Page 29: Viewer Software
VIEWER SOFTWARE To access the setup menu, you need to install the viewer software on your PC or DVR. The viewer software will install automatically the first time you connect to the camera. If your internet browser doesn’t install the viewer software, check the security settings or ActiveX controls and plug-in settings. -
Page 30: Home
Home Screen Size Adjustment Image display size can be adjusted to x1/2 and full screen via the related buttons. To switch between the normal view mode and full screen view mode, users can also move the cursor to the live video pane and right-clink to display the screen options. Click Normal View or Fullscreen to set the image display mode. - Page 31 Snapshot Click the Snapshot button, and a JPEG snapshots will automatically be saved in the designated location on the local workstation. The default place of saving snapshots is: C:\. This location can be changed in File Location under the System menu. Note If you are using Windows Vista or 7, you will need to change the snapshot location.
-
Page 32: System
System Note The System tab is only accessible by the Administrator. System Host Name The Host Name is used to identify the camera on your system. If camera based Motion Detection is enabled and is set to send alarm message by Mail/FTP, the host name entered here will display in the alarm message. - Page 33 Enable Daylight Savings Time Select to enable daylight savings time, then select the offset, start date and end date. In North America the typical offset is one hour (01:00:00); the start is the second Sunday in March at 2AM (02:00:00), and the end is the first Sunday in November at 2AM (02:00:00).
-
Page 34: Security
Security Admin Password To change the administrator password, type a new password in the Admin Password box and confirm below. Note The maximum length of the password is 14 characters. The following characters are valid: A-Z, a-z, 0-9, !#$%&’-.@^_~. -
Page 35: Add User
Add User The user name and passwords are limited to 16 characters. There is a maximum of twenty user accounts Type the new User name and Password Select the appropriate check boxes to give the user Camera Control, Talk and Listen permissions. -
Page 36: Network
Each camera has a unique Media Access Control (MAC) address, which can be used to identify the camera on the network. Record the IP Camera’s MAC address, which can be found using the Surveillix Device search application and on the label of the camera, for identification in the future. - Page 37 When using static IP address to log in to the IP Camera, you can access it either through Surveillix Device search software or type the IP address directly in the Address bar of your internet browser. General IP address – The IP Address is necessary for network identification.
-
Page 38: Qos (Quality Of Service)
QoS (Quality of Service) Quality of Service allows you to prioritize network traffic services of the camera’s functions. The QoS function utilizes the Differentiated Services prioritized using Codepoint values (DSCP). Note Routers and switches on the network must be QoS or DSCP capable, and have these settings enabled for this function to operate on your network. -
Page 39: Upnp (Universal Plug And Play)
UPnP (Universal Plug and Play) Enable UPnP: When enabled the camera will appear in My Network Places on Windows computers running UPnP on the same network. Enable UPnP Port Forwarding: When enabled the camera will attempt to open the web server port on the router automatically. -
Page 40: Ddns
DDNS DDNS (Dynamic Domain Name Service) is a service that allows a connection to an IP address using a hostname (URL) address instead of a numeric IP address. Most Internet Service Providers use Dynamic IP Addressing that frequently changes the public IP address of your internet connection;... -
Page 41: Mail
Mail The camera can send an e-mail via Simple Mail Transfer Protocol (SMTP) when motion is detected or when the sensor input is activated. SMTP is a protocol for sending e-mail messages between servers. SMTP is a relatively simple, text-based protocol, where one or more recipients of a message are specified and the message text is transferred. -
Page 42: Ftp
The camera can send alarm message to a specific File Transfer Protocol (FTP) site when motion is detected or when the sensor input is activated. You can assign alarm message to up to two FTP sites. Enter the FTP details, which include server, server port, user name, password and remote folder, in the appropriate boxes and click save when finished. -
Page 43: Http
HTTP The camera can send alarm messages to a specific Hypertext Transfer Protocol (HTTP) site when motion is detected or when the sensor input is activated. You can assign alarm messages to up to two HTTP sites. Enter the HTTP details, which include server, user name and password, in the appropriate boxes and click Save when finished. -
Page 44: Application
Application The IKS-WP806 supports 4 digital alarm inputs and 2 digital alarm outputs. Make sure the alarm connections are properly wired before starting to configure alarm related settings on the Application screen. Refer to the pin definition table below for alarm system wiring. -
Page 45: Alarm Pin Selection
Alarm Pin Selection Select an alarm pin from the Alarm Pin Selection box and click Edit to start alarm programming. -
Page 46: Alarm Status Settings
Alarm Status Settings Alarm Switch Alarm Switch – Enable or disable the alarm function. Alarm Type – Select an alarm type, Normal close or Normal open, that corresponds with the alarm application. Trigger Action (Multi-Option) Specify alarm actions that will take place when the alarm is triggered. ... - Page 47 PTZ Function – Assign a PTZ function (Preset, Tour, Auto Scan or Pattern) for the camera to perform when this alarm is activated. Note If Preset is selected, you will be prompted to enter a Dwell Time (1~256). This is the time in seconds that the camera will remain at that Preset location, and then it will return to the location that it was pointing at the time the alarm occurred.
-
Page 48: Motion Detection
Motion Detection Motion Detection allows the camera to detect motion and trigger alarms when motion in the detected area exceeds the determined sensitivity threshold value. On the Motion Detection page, there is a motion detection window (red box) displayed on the Live View Pane. The Motion Detection window defines the motion detection area. To change the size of the Motion Detection window, drag the edge of the frame to resize. - Page 49 When motion detection is activated, the Motion pop-up window will open. When motion is detected, the signals will be displayed on the Motion window as shown below Motion Detection Turn motion detection on or off. The default setting is Off. Motion Detection Setting In the Motion window the red line provides a motion detection threshold indication;...
- Page 50 Triggered Action Once motion detection has been fine tuned, the Triggered Action can be configured if you want the camera to take one of these actions upon sensing motion. Enable Alarm Output – Select to trigger the alarm output on the camera on motion detection.
-
Page 51: Storage Management
Storage Management Storage Management allows you to view information about an inserted Micro SD/SDHC card (up to 32GB), format the SD card, adjust cleanup settings, and download or delete files stored on the SD card. Device Information – When a compatible Micro SD/SDHC card is inserted into the camera, information about the card will be displayed in this section. - Page 52 Recording List - Each file recorded to the Micro SD/SDHC card will be listed in the Recording List. Note The maximum file is 60MB per file. Note The letters A/M/R appear at the beginning of each file, denoting the type of recording.
-
Page 53: Recording
Recording The recording schedule allows you to set up scheduled recording to a local Micro SD/SDHC card. Activating Micro SD/SDHC Card Recording To set up continuous micro SD/SDHC card recording: Select Always to continually record until the card is full. To set the camera to overwrite old data, see the instructions for Disk Cleanup Setting earlier in this section. -
Page 54: Snapshot
Snapshot The CM-L812 camera supports JPEG snapshot function. You can specify a storage location for the snapshots. The default setting is: C:\. Note If you are using Windows Vista or 7, you will need to change the Snapshot location. Windows UAC does not allow internet programs to write directly to C:\ for security reasons. -
Page 55: Information
Information The Information page to contains the System Log, User Information, and Parameter List. System Log Click System Log to view the system log file. The content of the file provides useful information about configuration and connections. -
Page 56: View User Information
View User Information The Administrator can view each user’s login information and privileges on the View User Information page All the users in the network are listed under User information. The example below shows that the Admin password is 1234. View User Privilege Select a user account from the list and click get user privacy to view the permissions for the user account. -
Page 57: Parameter List
Parameter List Click Parameter List to view the system parameter settings. -
Page 58: Software Upgrade
Software Upgrade Upgrading the Camera Viewer Software Note Make sure the software upgrade file is available before starting the software upgrade. Click Browse and find the upgrade file. Note Do not change the file name, or the system will fail to find the file. Select the file name from the list under Step 2. -
Page 59: Maintenance
Maintenance On the Maintenance page you can export the cameras current configuration, or import the configuration for a camera. Use the factory default page to reset the IP Camera to factory default settings if necessary. Do not import configuration files from different models of cameras. Note Set Default –To reset the IP camera to the factory default settings, including the default IP address, click Set Default. -
Page 60: Video And Audio Streaming Settings
Video and Audio Streaming Settings On the Streaming tab, the Administrator can configure specific video resolution, video compression mode, video protocol, audio transmission mode, etc. Video Format Select the desired video resolution for the camera on the Video Format page. The recorder will record video based on the resolution selected here. -
Page 61: Video Resolution
Video Resolution The camera provides four codec options under video resolution (two single streaming options and two sets of dual streaming options): MJPEG only H.264 only MJPEG + H.264 H.264 + H.264 Once a codec option is selected, multiple resolutions are available for each stream. MJPEG Resolutions* H.264 Resolutions* 1920x1080... -
Page 62: Video Rotate Type
Video Rotate Type You can change the orientation of the video output if necessary. Normal Video – This is the default rotation designed for a normal setup with the camera mounted with the dome facing down. Flip Video – This option will vertically flip the video image (without the intervention of another device this may cause the reversal of perceived left and right when viewing the image). -
Page 63: Video Compression
Video Compression You can select an MJPEG/H.264 compression mode on the video compression page appropriate for your application. You can also select to display compression information on the Home page. MJPEG Compression settings include: high compression, low bit rate, low quality ... -
Page 64: Video Ocx Protocol
Video OCX Protocol On the Video OCX protocol page, you can select different protocols for streaming media over the network. In the case of multicast networking, you can select the Multicast mode. Video OCX protocol setting options include: RTP over UDP ... -
Page 65: Frame Rate Control
Frame Rate Control Setting the camera to transmit fewer frames can save bandwidth. Each of the MJPEG and H.264 streams can have a separate frame rate setting from 1 to 30 frames per second. Note Higher frame rate will increase video smoothness, as well as file size and bandwidth usage. -
Page 66: Audio
Audio On the audio page, the Administrator can select an audio transmission mode and audio bit rate. Note Audio monitoring and recording laws vary from location to location. It is highly recommended that you consult your local, state, and federal laws to verify that you are in compliance before implementing audio recording. -
Page 67: Bit Rate
Bit Rate Selectable audio transmission bit rate include: 16 kbps (G.726) 40 kbps (G.726) 24 kbps (G.726) uLAW (G.711) 32 kbps (G.726) ALAW (G.711). Both uLAW and ALAW signify 64 kbps but in different compression formats. Higher bit rate will provide higher audio quality and require more bandwidth. -
Page 68: Ptz Settings
PTZ SETTINGS Use the PTZ tab to program Presets, Patterns, Auto Scans and Tours via PTZ controls. Additionally, various camera settings including Auto Exposure (AE), White Balance (WB), Back Light Compensation (BLC), Sharpness, Exposure Compensation, etc. also can be set here. Preset Note Up to 256 Presets can be programmed for the camera. -
Page 69: Preset Go
Preset Go To move the camera view to a specified Preset position: Select the Preset Point from the list under Preset Go. The camera will move to the target position. Pattern Note The camera supports up to eight patterns. Pattern Setting To create a Pattern: Select a path number from the Pattern Path list. -
Page 70: Pattern Run
Pattern Run Select the specified Pattern from the Pattern Path list and click Run. To view the camera in full screen mode, move the pointer onto the live view pane, right- click and select Fullscreen. To stop running a Pattern, move the cursor to the live view pane and use the PTZ controls to move the camera in any direction. -
Page 71: Auto Scan Setting
Auto Scan Setting To create an Auto Scan path: Select a path number from the Auto Scan Path list. Move the pointerr to the live view pane, and move the camera to a desired view as the Start Point of an Auto Scan Path. Click the “Set”... -
Page 72: Tour
Tour The camera supports up to eight Tours; each Tour supports up to 64 Presets. Note Before setting this function, you must pre-define at least two Presets. -
Page 73: Tour Set
Tour Set On the Tour screen, click Edit to open the Tour Set options. Select the number of the new tour from the Tour Line list at the top of the screen. Select each Preset to add to the tour. Enter the Dwell Time (0~127 seconds) and Speed (0~14) for each Preset. -
Page 74: Home
Home Set up the Home function to ensure constant monitoring. If the camera idles for a period of time, the selected function will be activated automatically and return the camera to the home function setting. The Home function allows constant and accurate monitoring to prevent the camera from idling or missing events. -
Page 75: Tilt Range
Tilt Range The camera’s Tilt Range is adjustable. The minimum tilt angle can be set between -10° and 10°. The maximum tilt angle can be set between 170° and 190°. Enter the desired min. and max. tilt angle into the corresponding fields respectively and click Set to save the tilt angle settings. -
Page 76: Privacy Mask Settings
Privacy Mask Settings The Privacy Mask function helps avoid any intrusive monitoring. When you create a mask, Toshiba recommends that you set it at least twice as big (height and width) as the masked object. The camera will assume the center of the selected view as a starting point. -
Page 77: Mask Setting
Mask Setting Activate/Disable Privacy Mask Function Set to On/Off to activate or disable the Privacy Mask function and click Set. Activate/Disable Transparency Mask Set the transparency of the Privacy Mask if necessary. Color Setting Select the desired color from the Color list for the specified Privacy Mask and click Set. Mask Number Specify the number of the programmed Privacy Mask in the corresponding field. -
Page 78: Camera - Exposure
Camera — Exposure On the Exposure screen you can select Full Auto mode or adjust the parameters manually for optimized video output in accordance with the operating environment. Shutter Priority When Shutter Priority is selected the shutter speed takes control of exposure. Shutter speed range is 1/60 ~ 1/10000. -
Page 79: Camera - White Balance
Camera — White Balance A camera uses a reference color temperature, which is a way of measuring the quality of a light source, to calculate all the other colors. The unit for measuring this ratio is degrees Kelvin (K). You can select the White Balance Control according to the operating environment. - Page 80 Auto Mode In Auto mode, white balance works within its color temperature range and calculates the best-fit white balance. Indoor/outdoor Mode Select for indoor or outdoor mode. ATW Mode (Auto Tracing White Balance) The Dome Camera takes out the signals in a screen in the range from 2000 K to 10000 Manual Mode In Manual mode, you can change the White Balance value manually by a specifying the R gain and B gain;...
-
Page 81: Camera - Misc1
Camera — Misc1 In Camera—Misc1, you can set various camera parameters including Backlight Compensation, Sharpness, Exposures Compensation, Image Freeze, Image Flip, Digital Zoom, Speed by Zoom and ICR Function. BLC – Activate or disable the Backlight Compensation function (On/Off). ... - Page 82 Flip – Track an object continuously when it passes under the camera by setting Flip to Mechanical (M.E.) mode or Digital Flip (Image) mode. M.E. Mode – M.E. is a standard mechanical operation. As the camera tilts to the maximum angle, it will pan 180°, and then continue tilting to keep tracking objects.
-
Page 83: Camera - Misc2
Camera — Misc2 In Camera—Misc2, you can set up various functions such Auto Calibration, Wide Dynamic Range, 2D Noise Reduction and TV System. WDR – Wide Dynamic Range is especially effective in an environment with extreme contrast. Auto Calibration – Auto Calibration function automatically calibrates the camera when the deviation of dome pivot is detected. -
Page 84: Camera - Default
Camera — Default Click Set Default to reset the camera back to factory default settings. LOGOUT Click the Logout tab to open the login window and log in with a different user name and password. -
Page 85: Specifications
SPECIFICATIONS CAMERA SPECIFICATIONS Model IKS-WP806 Image Sensor 1/2.8” Sony Progressive CMOS Type / Format H.264 / MJPEG Wide Dynamic Range Digital WDR 0.1 Lux (Color) / 0.03 Lux (B&W) (@ 50IRE) Minimum Illumination 0.05 Lux (Color) / 0.01 Lux (B&W) (@ 30IRE) -
Page 86: Ptz Specifications
PTZ SPECIFICATIONS Optical Zoom Pan/Tilt Range 360° Endless / -10° ~ 190° Presets Preset Accuracy ± 0.225° Preset Speed 5° ~ 400°/sec. Pattern Tour (Group) Auto Scan Privacy Mask Home Function Preset, Pattern, Tour, Autoscan Auto Flip Image / Mechanical / Off Digital Slow Shutter On / Off Focus Mode... - Page 87 www.toshibsecurity.com 1-877-855-1349 © 2013 Toshiba All rights reserved. No part of this publication may be reproduced by any means without written permission from Toshiba. The information in this publication is believed to be accurate in all respects. However, Toshiba cannot assume responsibility for any consequences resulting from the use thereof.
