tEchNicAL sPEcificAtiONs

charger model XS 0.8
Model number 1047
Rated Voltage Ac 220–240VAC, 50–60Hz
charging voltage 14.4V
start voltage 2.0V
charging current 0.8A max
current, mains 0.2A rms (at full charging current)
Back current drain* <1Ah/month
Ripple** <4%
Ambient -20°C to +50°C, output power is reduced
temperature automatically at high temperatures
charger type Six step, fully automatic charging cycle
All types of 12V lead-acid batteries
Battery types
(WET, MF, Ca/Ca, AGM and GEL)
Battery capacity 1.2―32Ah up to 100Ah for maintenance
dimensions 145 x 55 x 38mm (L x W x H)
IP65
insulation class
Weight 0.4kg
*) Back current drain is the current that drains the battery if the charger is not connected
to the mains. CTEK chargers has a very low back current.
**) The quality of the charging voltage and charging current is very important. A high
current ripple heats up the battery which has an aging effect on the positive electrode.
High voltage ripple could harm other equipment that is connected to the battery. CTEK
battery chargers produce very clean voltage and current with low ripple.
4 • EN
20014896E XS 0.8, Manual EU, Print file 002.indd 4
ERROR LAMP
If the error lamp is lit, check the following:
1. is the chargers positive lead connected to the
batterys positive pole?
2. is the charger connected to a 12V battery?
3. has charging been interrupted in stEP 1 or step 4?
Restart the charger. If charging is still being interrupted, the battery...
stEP 1: ...is seriously sulphated and may need to be replaced.
stEP 4: ...can not keep charge and may need to be replaced.
POWER LAMP
If the power lamp is lit with a:
1. stEAdy Light
The mains cable is connected to the wall socket.
2. fLAshiNg Light:
The charger has entered the energy save mode. This happens if the
charger isn´t connected to the battery in 2 minutes.

REAdy tO usE

The table shows the estimated time for empty battery to 80% charge
BAttERy siZE (Ah)
2Ah
8Ah
20Ah
32Ah
tiME tO 80% chARgEd
2h
8h
20h
32h
