Getting Started; Battery Installation - VTech Innotab 3 User Manual

Battery Compartment
InnoTab Cartridge Port
®
Brightness Button
microSD Card Slot
Headphone Jack
USB Port

Battery Installation

• Make sure the tablet is turned off.
• Use a coin or a screwdriver to unlock and remove the protective case.
• Locate the battery door lock sliding switch on the back of the tablet. Slide the
switch to open the battery covers, then remove the covers.
• Insert 4 AA batteries as shown in image.
• Make sure to replace the battery covers.
• Replace the protective cover. Use a coin or a screwdriver to secure the cover.
4
Insert 4 AA batteries (not included). For battery
installation instructions, please see the next
section.
Insert an InnoTab
®
this slot to play.
Press this button to adjust the screen brightness.
Slide this switch to open the battery doors. Always
replace the InnoTab
changing batteries.
Insert a microSD memory card (not included).
(NOTE: InnoTab
microSD memory cards up to 32GB.)
Use this to connect headphones (sold separately).
For safety, we do not recommend using headphones
until your child is 3 years or older.
Note: Maximum output voltage ≤ 1 50mV.
Plug the included USB cable into this USB port
to connect the tablet to your computer.
cartridge (sold separately) into
3 Baby battery doors after
®
3 Baby is compatible with
®
