SnapSAN VSS User Guide
replication operation is executed for a volume made up of multiple partitions or logical
volumes or for a dynamic disk volume. The table below shows the function range for each
disk.

Initial Setup of Volumes

Backup Server Connected to Snapshot Logical Volume (LV)
When performing backup operations in which the snapshot function is used, the initial
setup below is necessary. Execute identical operations for target volumes used in backup
operations. The volume states, which are the states in which "Installation Procedure" in the
"Snapshot User's Manual (Installation and Operation Guide for Windows) ended, are
assumed to be "active" for the SV state and "unlink" for the LV link state.
1. Start a command prompt on the backup server.
2. Confirm that volumes used in backup operations have been registered in the volume
list created in (Installation and Operation Guide for Windows)" and re-create the
volume list.
3. In order to change the LV access restriction to Not Available (NA), stop the volume
beforehand.
Here, the setting is made for logical disk name lv001.
4. Change the LV access restriction to Not Available (NA). Here, settings are made for
logical disk names lv001 and sv001.
The above is the end of environment setup for operation using the snapshot function.
10400401-001 08/2012
Table 3-1: Available Volume Type
Disk Type Volume Type
Basic disk Primary partition (MBR format)
Primary partition (GPT format)
Logical volume on expanded partition
Dynamic disk
Simple volume
Spanned volume
Striped volume
Mirror volume
RAID5 volume
√: Recommended configuration -: Operation inhibited
> iSMvollist -a
> iSMvss -devmode disable -vol lv001 -volflg ld
> iSMsc_link -lv lv001 -lvflg ld -sv sv001 -svflg ld -lvacc na
> iSMsc_unlink -lv lv001 -lvflg ld
©2012 Overland Storage, Inc.
Availability
√
√
-
-
-
-
-
-
 3-4
