EEDEN09-100

technical data

RXS-G2V1B
Outdoor units
Split -
Sky Air

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the R-410A and is the answer not in the manual?

Questions and answers

david cox
April 8, 2025

WHAT SIZE MOTOR

0
1 comments:
Mr. Anderson
April 9, 2025

The Daikin R-410A system uses a fan motor with a rated output of 34 W and a full load amperage (FLA) of 0.23 A for the outdoor unit, and a fan motor with an FLA of 0.15 A and rated output of 23 W for the indoor unit.

This answer is automatically generated

0

Subscribe to Our Youtube Channel

Related Manuals for Daikin R-410A

Summary of Contents for Daikin R-410A

  • Page 1: Technical Data

    EEDEN09-100 technical data RXS-G2V1B Outdoor units Split - Sky Air...
  • Page 2 EEDEN08-100 technical data RXS-G2V1B Outdoor units Split - Sky Air...

  • Page 3: Table Of Contents

    • Outdoor Units • R-410A • RXS-G2V1B TABLE OF CONTENTS RXS-G2V1B Features ............

  • Page 4: Features

    Outdoor units are fitted with a swing compressor, renowned for its low noise and high energy efficiency • Daikin outdoor units are neat and sturdy and can be mounted easily on a roof or terrace or simply placed against an outside wall. • Split Sky Air • Outdoor Units...

  • Page 5: Specifications

    • Outdoor Units • R-410A • RXS-G2V1B Specifications 2-1 NOMINAL CAPACITY AND NOMINAL INPUT RXS20G2V1B RXS25G2V1B RXS35G2V1B RXS42G2V1B RXS50G2V1B For combination indoor Indoor Units FTXS20G2V1B FTXS25G2V1B FTXS35G2V1B FTXS42G2V1B FTXS50G2V1B units + outdoor units Cooling capacity Minimum Btu/h 4,400 4,400 4,800...
  • Page 6 • Outdoor Units • R-410A • RXS-G2V1B Specifications 2-1 NOMINAL CAPACITY AND NOMINAL INPUT RXS20G2V1B RXS25G2V1B RXS35G2V1B RXS42G2V1B RXS50G2V1B For combination Nominal 3.48 3.12 3.03 indoor units + Nominal 3.52 3.39 3.02 outdoor units Energy Label Cooling Heating Annual energy consumption...
  • Page 7 • Outdoor Units • R-410A • RXS-G2V1B Specifications 2-1 NOMINAL CAPACITY AND NOMINAL INPUT RXS20G2V1B RXS25G2V1B RXS35G2V1B RXS42G2V1B RXS50G2V1B Power Input Cooling Minimum 0.30 0.30 0.45 Standard 0.65 1.13 1.72 Maximum 0.86 1.26 1.95 Heating Minimum 0.29 0.29 0.31 Standard 0.98...

  • Page 8: Technical Specifications

    • Outdoor Units • R-410A • RXS-G2V1B Specifications 2-1 NOMINAL CAPACITY AND NOMINAL INPUT RXS20G2V1B RXS25G2V1B RXS35G2V1B RXS42G2V1B RXS50G2V1B For combination Nominal 3.24 2.73 indoor units + Nominal 3.60 2.93 outdoor units Energy Label Cooling Heating Annual energy consumption Indoor Units...

  • Page 9: Electrical Specifications

    • Outdoor Units • R-410A • RXS-G2V1B Specifications 2-2 TECHNICAL SPECIFICATIONS RXS20G2V1B RXS25G2V1B RXS35G2V1B RXS42G2V1B RXS50G2V1B Sound Level Cooling Sound Power (nominal) Sound Pressure (Low) Sound Pressure (High) Heating Sound Pressure (Low) Sound Pressure (High) Refrigerant Type R-410A Charge Refrigerant Oil...

  • Page 10: Electrical Data

    • Outdoor Units • R-410A • RXS-G2V1B Electrical data Representative Unit Combination Power Supply Comp Indoor Unit Outdoor Unit Hz-Volts Voltage Range Max. 50Hz 264V FTXS20G2V1B RXS20G2V1B 50 - 220 9.75 0.23 0.15 Min. 50Hz 198V 3D055006B IMBOLS OTES Min. circuit amps.
  • Page 11 • Outdoor Units • R-410A • RXS-G2V1B Electrical data Representative unit combination Power supply Comp. Indoor unit Outdoor unit Hz-volts Voltage range 50 - 220 Max. 50Hz 264V RXS25G2V1B FFQ25B8V1B 50 - 230 9.75 0.16 Min. 50Hz 198V 50 - 240...
  • Page 12 • Outdoor Units • R-410A • RXS-G2V1B Electrical data Representative unit combination Power supply Comp. Indoor unit Outdoor unit Hz-volts Voltage range 50 - 220 Max. 50Hz 264V RXS35G2V2B FFQ35B8V1B 50 - 230 9.75 0.16 Min. 50Hz 198V 50 - 240...
  • Page 13 • Outdoor Units • R-410A • RXS-G2V1B Electrical data Representative unit combination Power supply Comp. Indoor unit Outdoor unit Hz-volts Voltage range 50 - 220 Max. 50Hz 264V RXS35G2V1B FHQ35BVV1B 50 - 230 9.75 0.22 Min. 50Hz 198V 50 - 240...
  • Page 14 • Outdoor Units • R-410A • RXS-G2V1B Electrical data Representative Unit Combination Power Supply Comp Indoor Unit Outdoor Unit Hz-Volts Voltage Range 50 - 220 Max. 50Hz 264V FTXS50G2V1B RXS50G2V1B 19.75 0.27 0.15 50 - 230 Min. 50Hz 198V 3D059718...

  • Page 15: Capacity Tables

    • Outdoor Units • R-410A • RXS-G2V1B Capacity tables 4 - 1 Cooling/Heating capacity tables FTXS20G2V1B + RXS20G2V1B Cooling 50Hz 220-240V 0.14 Indoor Outdoor temperature (°C DB) °C °C 14.0 2.05 1.84 0.36 1.96 1.80 0.40 1.86 1.76 0.43 1.83 1.74...
  • Page 16 • Outdoor Units • R-410A • RXS-G2V1B Capacity tables 4 - 1 Cooling/Heating capacity tables FTXS25G2V1B + RXS25G2V1B Cooling 50Hz 220-240V 0.16 Indoor Outdoor temperature (°C DB) °C °C 14.0 2.56 2.03 0.42 2.44 1.98 0.46 2.33 1.92 0.50 2.28 1.90...
  • Page 17 • Outdoor Units • R-410A • RXS-G2V1B Capacity tables 4 - 1 Cooling/Heating capacity tables FFQ25B8V1B+RXS25G2V1B Cooling 50Hz 220-240V 0.24 I n door Outdoor temperature (°CDB) (°C) (°C) Heating 50Hz 220-240V I n door Outdoor temperature (°CWB) (°C) 3D055487 SYMBOLS...
  • Page 18 • Outdoor Units • R-410A • RXS-G2V1B Capacity tables 4 - 1 Cooling/Heating capacity tables FTXS35G2V1B + RXS35G2V1B 10.4 Cooling 50Hz 220-240V 0.21 Indoor Outdoor temperature (°C DB) °C °C 14.0 3.59 2.60 0.67 3.42 2.52 0.73 3.26 2.43 0.80 3.19...
  • Page 19 • Outdoor Units • R-410A • RXS-G2V1B Capacity tables 4 - 1 Cooling/Heating capacity tables FFQ35BVV1B+RXS35G2V1B Cooling 50Hz 220-240V 0.25 I n door Outdoor temperature (°CDB) (°C) (°C) Heating 50Hz 220-240V I n door Outdoor temperature (°CWB) (°C) 3D055489 SYMBOLS...
  • Page 20 • Outdoor Units • R-410A • RXS-G2V1B Capacity tables 4 - 1 Cooling/Heating capacity tables FCQ35C7VEB+RXS35G2V1B 10.5 Cooling 50Hz 220-240V 0.28 I n door Outdoor temperature (°CDB) (°C) (°C) Heating 50Hz 220-240V 12.5 I n door Outdoor temperature (°CWB) (°C)
  • Page 21 • Outdoor Units • R-410A • RXS-G2V1B Capacity tables 4 - 1 Cooling/Heating capacity tables FBQ35C7VEB + RXS35G2V1B Cooling 50Hz 220-240V 0.15 Indoor Outdoor temperature (°CDB) °C °C 14.0 3.48 3.12 0.81 3.33 3.04 0.89 3.17 2.97 0.97 3.10 2.94 1.00...
  • Page 22 • Outdoor Units • R-410A • RXS-G2V1B Capacity tables 4 - 1 Cooling/Heating capacity tables FBQ50C7VEB + RXS50G2V1B Cooling 50Hz 220-240V 0.16 Indoor Outdoor temperature (°CDB) °C °C 14.0 5.12 3.88 1.27 4.89 3.76 1.39 4.66 3.65 1.51 4.56 3.60 1.56...
  • Page 23 • Outdoor Units • R-410A • RXS-G2V1B Capacity tables 4 - 1 Cooling/Heating capacity tables FTXS42G2V1B + RXS42G2V1B Cooling 50Hz 220-240V 0.14 Indoor Outdoor temperature (°C DB) °C °C 14.0 3.81 2.68 0.87 3.81 2.68 0.99 3.81 2.68 1.10 3.81 2.68...
  • Page 24 • Outdoor Units • R-410A • RXS-G2V1B Capacity tables 4 - 1 Cooling/Heating capacity tables FTXS50G2V1B + RXS50G2V1B 10.2 Cooling 50Hz 220-240V 0.18 Indoor Outdoor temperature (°C DB) °C °C 14.0 4.07 2.87 1.05 4.07 2.87 1.19 4.07 2.87 1.33 4.07...
  • Page 25 • Outdoor Units • R-410A • RXS-G2V1B Capacity tables 4 - 1 Cooling/Heating capacity tables FFQ50B8V1B+RXS50G2V1B 12.0 Cooling 50Hz 230V 0.16 I n door Outdoor temperature (°CDB) (°C) (°C) Heating 50Hz 230V 12.0 Indoor Outdoor temperature (°CWB) (°C) 3D041023 SYMBOLS...
  • Page 26 • Outdoor Units • R-410A • RXS-G2V1B Capacity tables 4 - 1 Cooling/Heating capacity tables FCQ50C7VEB+RXS50G2V1B 12.5 Cooling 50Hz 220-240V 0.21 I n door Outdoor temperature (°CDB) (°C) (°C) Heating 50Hz 220-240V 12.5 I n door Outdoor temperature (°CWB) (°C)

  • Page 27: Dimensional Drawing & Centre Of Gravity

    • Outdoor Units • R-410A • RXS-G2V1B Dimensional drawing & centre of gravity 5 - 1 Dimensional drawing RXS20-42G MINIMUM SPACE FOR AIR PASSAGE 4-Holes for anchor Drain Oulet bolts (M8 or M10) (I.D. Ø 15.9 Hose For Connection) Wall Height On Air Outlet Side = Less Than 1200...

  • Page 28: Centre Of Gravity

    • Outdoor Units • R-410A • RXS-G2V1B Dimensional drawing & centre of gravity 5 - 2 Centre of gravity RXS42G 4D059009B RXS50G The position of foundation bolt 4D051638L • Split Sky Air • Outdoor Units...

  • Page 29: Piping Diagram

    • Outdoor Units • R-410A • RXS-G2V1B Piping diagram RXS20G Outdoor Unit Outdoor Air Temperate Thermistor Heat exchanger Heat exchanger Thermistor Motor Operated Valve (6.4 CuT) (6.4 CuT) (7.0CuT) Muffler Muffler With With Filter Filter Propeller Fan 9.5 CuT Muffler...
  • Page 30 • Outdoor Units • R-410A • RXS-G2V1B Piping diagram RXS42G Outdoor Unit Outdoor Air Temperate Thermistor Heat exchanger (7.9 CuT) 7.9 CuT) Heat Exchanger Thermistor Motor Operated Valve (4.8 CuT) (6.4 CuT) (6.4 CuT) (4.8 CuT) Muffler Muffler With With...

  • Page 31: Wiring Diagram

    • Outdoor Units • R-410A • RXS-G2V1B Wiring diagram 7 - 1 Wiring diagram RXS20-35G WIRING DIAGRAM Field wiring Indoor Outdoor In case of heat pump In case of type cooling only (Outdoor) (Discharge) type (Condenser) C5, C6, C118 : Capacitor...
  • Page 32 • Outdoor Units • R-410A • RXS-G2V1B Wiring diagram 7 - 1 Wiring diagram RXS50G WIRING DIAGRAM Power Supply To Indoor Unit Indoor Field wiring (Outdoor) (Discharge) (Condenser) Outdoor Z1C~Z5C : Ferrite Core MRM10, MRM20 : Live : Compressor motor...

  • Page 33: Sound Data

    • Outdoor Units • R-410A • RXS-G2V1B Sound data 8 - 1 Sound pressure spectrum RXS20-25G RXS20-25G COOLING HEATING Approximate Approximate threshold hearing threshold hearing for continuous for continuous noise noise Octave band center frequency (Hz) Octave band center frequency (Hz)
  • Page 34 • Outdoor Units • R-410A • RXS-G2V1B Sound data 8 - 1 Sound pressure spectrum RXS42G RXS42G COOLING HEATING Approximate Approximate threshold hearing threshold hearing for continuous for continuous noise noise Octave band center frequency (Hz) Octave band center frequency (Hz)

  • Page 35: Operation Range

    • Outdoor Units • R-410A • RXS-G2V1B Operation range RXS20-42G HEATING COOLING Indoor temp. (°CWB) Indoor temp. (°CWB) 3D039536K NOTES The graphs are based on the following conditions. • Equivalent piping length 7.5m • Level difference • Air Flow Rate...
  • Page 37 Specifications are subject to change without environment. This challenge demands the eco design prior notice. Daikin Europe N.V. explicitly rejects any liability for any direct or and development of a wide range of products and an indirect damage, in the broadest sense, arising from or related to the use energy management system, resulting in energy and/or interpretation of this publication.
