- Page 1 USER'S MANUAL FLOOR & CEILING SERIES ASF-12A, ASF-18A, ASF-24A, ASF-30A ASF-36A, ASF-48A, ASF-60A...
-
Page 3: Important Safety Information
IMPORTANT SAFETY INFORMATION CAUTION Danger Do not attempt to install this unit by yourself. This unit requires installation by qualified persons. DANGER Do not attempt to service the unit yourself. This unit has no user serviceable components. Opening or removing the cover will expose you to dangerous voltage. -
Page 4: Hints For Economical Operation
HINTS FOR ECONOMICAL OPERATION The following should be noticed to ensure an economical operation. (Refer to corresponding chapter for details) Adjust the air flow direction properly to avoid winding toward your body. Adjust the room temperature properly to get a comfortable situation and to avoid supercooling and superheat. -
Page 5: Parts Names
PARTS NAMES Ceiling & Floor Type Display Panel NOTICE! The chart based on one model of our product is for reference only, which may be different from the unit you purchased. NAMES AND FUNCTIONS remote controller outdoor unit indoor unit connecting pipe air-in air flow louver (at air outlet) - Page 6 HINTS FOR ECONOMICAL OPERATION The following should be noticed to ensure an economical operation. (Refer to corresponding chapter for details) Adjust the air flow direction properly to avoid winding toward your body. Adjust the room temperature properly to get a comfortable situation and to avoid supercooling and superheat.
-
Page 7: Temporary Operations
TEMPORARY OPERATIONS This function is used to operate the unit temporarily in case you misplace the remote controller or its batteries are exhausted. Two modes including AUTO and mandatory COOL can be selected through the TEMPORARY BUTTON on the air inlet grill control box of the indoor unit. -
Page 8: Checks Before Operation
Checks before operation CAUTIONS Check that the wiring is not broken off or disconnected. Check that the air filter is installed. (Some air-conditioners haven't air filters.) Check that the outdoor unit air outlet or inlet is not blocked. Before you clean the air conditioner, be sure to disconnect the power supply plug. Cleaning the air filter The air filter can prevent the dust or other particulate from going inside .In case of blockage of the filter , the working efficiency of the air conditioner may greatly decrease .Therefore , the filter must be cleaned once two... -
Page 9: Air Conditioner Operations And Performance
AIR CONDITIONER OPERATIONS AND PERFORMANCE Three-minute protection feature A protection feature prevents the air conditioner from being activated for approximately 3 minutes when it restarts immediately after operation. Power failure Power failure during operation will stop the unit completely. The OPERATION lamp on the indoor unit will start flashing when power is restored. To restart operation, push the ON/OFF button on the remote controller. -
Page 10: Remote Controler
Please remove the nearby electronic device for they may affect the performance of remote controller. If necessary, contact the local Sinclair service centre or technical support centre. Do not put the used or different batteries into the remote controller, otherwise remote controller will fail to send signal. -
Page 11: Buttons And Their Functions
MODE: Once pressing, running mode will be selected in BUTTONS AND THEIR FUNCTIONS the following sequence: AUTO COOL HEAT NOTE: No heating mode for cool only type unit. AUTO FAN SPEED: Fan speed will be selected in following TEMP COOL sequence once pressing this button: Mode setting Fan speed setting... - Page 12 INDICATORS AND FUNCTIONS to adjust the figure. Setting or modification is effective only by pressing OK button to make confirmation. Temp TIME ON: For time ON setting. Once pressing this button, Transmitting display ON/OFF the time will increase by 0.5 hour. When the set time exceeds Running mode AUTO 10 hours, pressing the button will increase the time by 1 hour.
-
Page 13: Operation Instructions
Fan speed: Press FAN SPEED to display the current wind NOTE: On FAN mode, temp is nonadjustable and ECO is speed. AUTO, LOW, MED and HIGH can be selected. The ineffective. Procedure 2 is omitted. default state is high fan speed for the unit without medium DRY operation fan speed. - Page 14 Set TIME ON and TIME OFF simultaneously 1. Set TIME ON according to procedures 1 and 2 specified in TIME ON operation. 2. Set TIME OFF as the procedures 1 and 2 specified in TIME OFF operation. 3. If both the set time of TIME ON and TIME OFF not exceed 10 hours, time OFF operation will activated 0.5 hour later than time ON operation.
-
Page 15: Installation
INSTALLATION Location: During cooling operation, the air conditioner will dry the room air, so please fix a pipe to drain all the water away from the air conditioner. Please let the indoor unit more than one metre away from the TV set and the radio in order to avoid the picture and noise interference. -
Page 16: Troubles And Causes
TROUBLES AND CAUSES Before you ask for servicing or repairs, check the following points. Recheck Inoperative The power fuse is blown or the circuit breaker has been tripped. The batteries in the remote controller are exhausted. The timer is set. Does not cool or heat well. - Page 17 The Transmission Indicator " " Never Comes On Symptoms Reason and Disposal Causes Check whether the batteries The remote control signal is The remote control signal is not transmitted, because the in the remote controller are not transmitted even when power supply is off.
