Aqua Lung AXIOM Owner's Manual

Aqua Lung AXIOM Owner's Manual

Bcd
Hide thumbs
Table of Contents

Advertisement

Quick Links

Copyright Notice
Warnings, Cautions and Notes
Safety Information
Dealer Inspection and Service
Warranty Information
Basic Setup
Donning and Adjustment Procedures
TABLE OF CONTENTS
Axiom
© 2014 Aqua Lung International
Weight Integration Features
Inflation Methods
Deflation Methods
Special Features
Pre-Dive Inspection
Post-Dive Care and Maintenance
Storage

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the AXIOM and is the answer not in the manual?

Questions and answers

Related Manuals for Aqua Lung AXIOM

Summary of Contents for Aqua Lung AXIOM

  • Page 1 Weight Integration Features Warnings, Cautions and Notes Inflation Methods Safety Information Deflation Methods Dealer Inspection and Service Special Features Warranty Information Pre-Dive Inspection Basic Setup Post-Dive Care and Maintenance Donning and Adjustment Procedures Storage Axiom © 2014 Aqua Lung International...

  • Page 2: Copyright Notice

    Aqua Lung. It may not be distributed through the internet or computer bulletin board systems without prior consent in writing from Aqua Lung.

  • Page 3: Safety Information

    This manual provides essential instruction for the proper fitting, adjustment, inspection and care of your new BC. Because Aqua Lung BC’s utilize patented technology, it is very important to take the time to read these instructions in order to understand and fully enjoy the features that are unique to your specific model.
  • Page 4 Factory prescribed service for this BC must be performed at least once annually by a factory trained technician who is employed by an Authorized Aqua Lung Dealer or Distributor. Annual service consists of a complete overhaul of the power inflator, and a general air leak inspection of the bladder and valve connections.
  • Page 5 If you have any questions regarding your Buoyancy Compensator or the information found in this manual, please contact your regional Aqua Lung Dealer or Distributor. Distributor information is available on the Aqua Lung website at: www.aqualung.com...

  • Page 6: Dealer Inspection And Service

    NOTE: It is important to obtain prescribed dealer service for your BC at least once annually, from an Authorized Aqua Lung Dealer or Distributor, your personal safety and the mechanical integrity of your BC depends on it. © 2014 Aqua Lung International...
  • Page 7 Table of Contents ANNUAL SERVICE AND INSPECTION RECORD Purchase Date: Store Name: Country: BC Model: Serial Number: DATE DEALER NAME CITY, STATE COUNTRY TECH INITIALS © 2014 Aqua Lung International...

  • Page 8: Warranty Information

    Aqua Lung warrants to the original purchaser for the useful life of the product, from the date of purchase, that the product will be free from defects in materials and workmanship, provided that it receives normal use, proper care and prescribed dealer service subject to the limitations listed below.

  • Page 9: Warranty Limitations

    This warranty gives you specific legal rights. You may have rights which vary from state to state and country to country. AQUA LUNG DISCLAIMS AND EXCLUDES ANY LIABILITY FOR INCIDENTAL OR CONSEQUENTIAL DAMAGES. SOME STATES IN THE U.S. AND CERTAIN FOREIGN COUNTRIES DO NOT ALLOW EXCLUSIONS OR LIMITATIONS OF LIABILITY FOR INCIDENTAL OR CONSEQUENTIAL DAMAGES, SO THIS MAY NOT APPLY TO YOU.

  • Page 10: Basic Setup

    Table of Contents BASIC SETUP Aqua Lung recommends that you bring your buoyancy compensator, together with your regulator, to your authorized dealer for the installation of the MP inflator hose and other accessories. The retailer can also answer any questions you may have pertaining to the information in this manual.

  • Page 11: Attaching The Mp Hose To The First Stage

    3. Check to ensure the o-ring is present and in good condition. Screw the threaded end of the hose into the port and tighten to 40 in-lbs (4.5 Nm) with a 9/16” wrench. © 2014 Aqua Lung International...

  • Page 12: Griplock™ Cylinder Band Components

    Insert the open end of the cylinder band into the large opening of the bail, around the slide bar and out the small opening of the bail. Secure the hook and loop on the band to hold the bail in place. © 2014 Aqua Lung International...

  • Page 13: Adjusting The Griplock™ Cylinder Band

    B. Al 80 cf (7.25 in/184 mm) C. Smaller cylinder 2. Adjust the macro adjustment for the proper cylinder size. 3. Secure the excess webbing under the trim pocket (if equipped) after cylinder size is selected. © 2014 Aqua Lung International...

  • Page 14: Securing The Griplock™ Cylinder Band

    BC straight, parallel with the cylinder. NOTE: Over-tightening the valve strap can result in the BC being drawn in towards the cylinder which may be uncomfortable to wear. © 2014 Aqua Lung International...
  • Page 15 Repeat steps 1-4 to tighten and secure the cylinder band. WARNING: Verify the tension of the cylinder band prior to every dive. Failure to do so may result in the cylinder slipping during the course of a dive. © 2014 Aqua Lung International...

  • Page 16: Donning And Adjustment Procedures

    4. While your dive buddy lifts and holds the BC/cylinder behind you, place your arms through the BC torso straps as if you were putting on a jacket. © 2014 Aqua Lung International...
  • Page 17 Adjusting the shoulder straps too tightly will transfer the cylinder weight from the hips to the shoulders, restricting your arm movement and decreasing comfort. 8. If necessary, readjust the waistband and waist buckle so that they are comfortably snug, but not restricting. © 2014 Aqua Lung International...

  • Page 18: Adjusting The Chest Strap

    D-rings until the BC fits comfortably. Some BC models also offer vertical adjustment of the chest strap. Become familiar with the adjustment method on your particular model so that you can perform this adjustment in the water if necessary. © 2014 Aqua Lung International...

  • Page 19: Weight Integration Features

    Refer to the model-specific label, usually found in the pocket of your BC, to find the designated lift capacity, and load weight pouches accordingly. © 2014 Aqua Lung International...
  • Page 20 Your BC may not be able to float by itself on the surface if your BC is loaded with weight at or near its maximum buoyancy. In water weight of cylinders and other equipment may contribute to negative buoyancy of your full set of SCUBA equipment. Axiom BC Weight Capacity Chart Axiom BC Size...
  • Page 21 Loading Weight into the SureLock II™ Weight Pouches Aqua Lung recommends that each pouch is loaded with equal amounts of weight for optimum balance, preventing the tendency to roll to one side during the dive. Also, it is strongly recommended that each...
  • Page 22 Loading Soft Weight into the SureLock II™ Weight Pouches Aqua Lung recommends block weights be used in the SureLock II weight pouch for the best fit and ease of insertion. Soft weights may be used, but it is critical that the weights be loaded and secured correctly.

  • Page 23: Installing The Surelock Ii™ Weight Pouches On Your Bc

    INSTALLING THE SURELOCK II™ WEIGHT POUCHES ON YOUR BC CAUTION: Aqua Lung strongly recommends that you do not attempt to don your BC when it is fully loaded with weight. You may otherwise risk injury due to muscle strain or a temporary loss of balance.

  • Page 24: Releasing Surelock Ii™ Weight Pouches

    To avoid injuring other divers, always look below you before dropping weight. NOTE: In addition to becoming familiar with the weight system yourself, it is very important to explain its function to your dive buddy so that he/she is equally familiar with it. © 2014 Aqua Lung International...

  • Page 25: Non-Releasable Weight

    (trim) pockets after the BC has been secured to the cylinder. The non-releasable weight pockets are designed to hold single rectangular weight blocks. To avoid accidental loss of weight, Aqua Lung strongly advises against using small bullet-shaped weights and shot weight.
  • Page 26 While continuing to exhale into the mouthpiece, depress the oral inflator button (b) to inflate the BC. Immediately after exhaling, release the oral inflator button to prevent air from escaping. © 2014 Aqua Lung International...
  • Page 27 Dump Valve at the top of the airway assembly. You can vent air from the BC by firmly pulling straight down on the power inflator. This dump valve provides an effective and convenient way to vent air from the BC while in either an upright or facedown swimming position. © 2014 Aqua Lung International...
  • Page 28 Most training agencies recommend that you should descend in an upright, feet-first position, in order to maintain a slower and more controlled descent. This is especially true if you experience difficulty equalizing your ears, or if you are descending in low visibility conditions. © 2014 Aqua Lung International...

  • Page 29: Special Features

    BC knives available from Aqua Lung. For information on available knife models, consult an Authorized Aqua Lung Dealer or Distributor. To attach or remove the knife and sheath from the BC, refer to the instructions provided with the knife.
  • Page 30 The scooped style octo pocket on either BC lobe can also be used as a console pocket. The divers console can be run behind the pocket and out the scooped opening on the top, front of the lobe. © 2014 Aqua Lung International...
  • Page 31 BC. BC Buoyancy BC Single BC Double Cylinder Capacity Cylinder Capacity NOTE: The BC tag above is an example only. Reference the specific tag located on your model BC. Axiom BC Size Cylinder Capacity © 2014 Aqua Lung International...
  • Page 32 Cylinder Capabilities section of this manual prior to attaching double cylinders to confirm the approved double cylinders for your particular BC. Select BC’s can accommodate an Aqua Lung Twin Tank Kit. Consult your local Aqua Lung Dealer or Distributor for more information. Dealer or Distributor and product information can be found on the Aqua Lung website at www.aqualung.com...

  • Page 33: Pre-Dive Inspection

    WARNING: If you can hear any leaks, or if the bladder begins to deflate within 5-10 minutes, DO NOT attempt to use the BC until it has received service from an Authorized Aqua Lung Dealer or Distributor. 4. Make a final check of the cylinder band’s tension to ensure that been secured properly. Re-tighten if necessary.

  • Page 34: Post-Dive Care And Maintenance

    Store the BC partially inflated, away from direct sunlight and in a clean, dry area. Do not store the BC in an enclosed space, such as a car trunk, where temperatures may fall below 0ºF (-18ºC) or rise above 120ºF (49ºC). © 2014 Aqua Lung International...
