- Page 1 TECHNICAL MANUAL Malvern Multifuel Stove Model MV2CL To be retained by the user for future reference Serial Number ……………………………. Document MV2CL 0101 Version 1 Date 29/06/15 Thank you for purchasing an ACR Heat Products stove.
- Page 2 Important To ensure that you gain the most from your purchase, please take a few minutes to read through this manual before lighting the appliance for the first time. SINCE APRIL 2002 ONLY REGISTERED COMPETENT INSTALLERS CAN INSTALL SOLID FUEL APPLIANCES. INSTALLATIONS CARRIED OUT BY NON-REGISTERED INSTALLERS MUST BE INSPECTED BY LOCAL AUTHORITY BUILDING CONTROL.
- Page 3 MALVERN SPECIFICATIONS Nominal heat output ………… 5 kW – WOOD 4.8 kW – SMOKELESS FUEL Chimney draft required ……… 12Pa Height …………………………… 535 mm Width ……………………………. 445 mm Depth …………………………..285 mm Weight …………………………… 80 kg Air Requirement ……………….. N/A *** Flue Mass Gas Flow ……………...
-
Page 4: Mv2Cl Dimensions
MV2CL Dimensions... - Page 5 Order made and signed by the Secretary of State or Minister in the devolved administrations. The Malvern Classic (MV2CL) has been recommended as suitable for use in smoke control areas when burning wood. When the primary air control is in the closed position, it remains permanently open by 5mm and is prevented from closing fully by a screw.
-
Page 6: Installation Instructions
Installation Instructions CO Alarms It is required by building regulations that whenever a new or replacement wood/solid fuel or biomass appliance is installed in a dwelling a carbon monoxide alarm to BS EN 50292:2002 must be fitted in the same room as the appliance. - Page 7 appliance to enable the heat produced to rise and escape from the recess back into the room. Hearth Requirements The appliance must stand on a level fireproof hearth with a minimum thickness of 12mm. The hearth temperature created by this stove is below 100˚C.
-
Page 8: Assembly Of The Unit
Assembly of the unit This appliance is equipped with a manufactures smoke exempt stop Pre – fitted, under no circumstances should it be tampered with or removed unless expressly authorized by a competent person The appliance is supplied pre-assembled with the flue spigot in the top exit position. - Page 9 Maintenance The chimney should be swept at least once a year together with the flue pipe connection. Care should be taken to ensure that there is not a build up of soot on the baffle and in the airways of the appliance. If the appliance has not been operated for long periods, the flue should be inspected and swept before use to ensure there are no blockages within the flue.
-
Page 10: User Instructions
User Instructions Please note that during the first firing, we recommend a small fire is lit and that you slowly increase the temperature to enable the various parts to expand normally. You may also experience fumes and a haze being given off by the stove during the first firing and possibly for the next couple of firings as the paint cures. - Page 11 Always check with your dealer or directly with the manufacturer as using the incorrect fuel may invalidate your guarantee and damage your appliance. Instructions for use with wood Slide the top air control to the right and open the primary air fully by pulling the lever forward.
- Page 12 Re-fueling When refueling the stove always refuel onto a bed of hot embers, fully open the secondary and primary air controls until the new fuel is well alight, before adjusting the air controls for the desired setting. If there is insufficient burning material in the firebed to light a new fuel charge, excessive smoke emission can occur.
- Page 13 Daily Maintenance The ashpan should be checked and emptied regularly. You should never allow the ashes in the pan to build up to the level of the grate. If they are allowed to build up, the grate will become sandwiched between the ash below it and above it.
-
Page 14: Troubleshooting
Troubleshooting Problem Probable Cause Action Recommended Fire difficult to Green wood / wet wood Use hardwood logs Start / Fire goes with a maximum moisture content of 20% Logs are too large Use kindling and small logs to start the fire and once established use split logs Not enough primary air... -
Page 15: Commissioning Check List
Commissioning Check List (Please mark box when completed) Ensure the serial number has been recorded on the front of this manual for any future use Ensure the door seals are in good condition and that the glass is secured correctly in the door (do not over tighten the glass as this will prohibit its expansion and could cause the glass to crack) Ensure that all internal components are fitted correctly (these may have shifted in transit) - Page 16 Malvern Classic Exploded Diagrams...
- Page 19 SPAREPART LIST STOVE-MV2CL MALVERN CLASSIC Position Quantity Description Part number burning chamber door complete 8400-314 hinge 9900-972A flue spigot 3490-047 flue spigot gasket (8x3) 1982-004 leg frame 9900-1650 linear spring 6536-018 primary air regulator 5311-172 door cover plate 9900-993 blanking plate...
-
Page 20: Warranty Certificate
Warranty Certificate The specifications within this document are provided for information purposes only and are under no circumstances binding. With the aim of constantly improving our products, all modifications considered necessary may be made without notice. This manual is correct at time of printing. Our appliances are guaranteed against faults and hidden defects subject to the following conditions: ... - Page 21 Warranty Claim Form Customer Name: ……………………………………………………………………… Customer Address: ……………………………………………………………………. ……………………………………………………………………………………………… ……………………………………………………………. Postcode …………………. Daytime Tel: ……………………………. Mobile Tel: ……………………………… Model Name: …………………………… Model Number: ………………………. Serial Number: …………………………………………………………………………. Date of purchase: …………………………………………………………………….. Date of installation: …………………………………………………………………… Installer’s Name and address: ……………………………………………………… ………………………………………………………………………………………………...
