PROGRAMMING
Programming from the SmartNet console is performed exactly the same way as from the unit itself once the
SmartNet console is in the direct access mode for that unit.
Starting The Smartnet
Program
Exiting The Smartnet
Program
Updating Smartnet
Software
New System Load
Service Programming
Programming Passwords
Technical Manuals Online! - http://www.tech-man.com
Start the SmartNet program by typing SmartNet at the root directory prompt. The
SmartNet Program will automatically start when the computer is booted up.
Using the mouse, place the cursor in the top right hand corner of the screen and
click the left mouse button. When the system prompts for the password, enter the
level 6 password in the password.ini file. (default is Gamewell)
Software updates (part number SN600-SW) will be supplied on a 3.5" floppy disk.
To update the SmartNet software it is necessary to exit the SmartNet program.
1) Close down the SmartNet program and shut power off on the computer.
2) Turn power back on the computer and press the F5 key when you see Starting
MS-DOS on the screen.
3) Put disk into floppy drive, type A: [return], type UPGRADE [return]
4) Answer Yes when the screen asks if you wish to replace existing file.
5) Reboot the computer to start the network.
1) Make sure that there is no SmartNet directory in the computer.
2) Put disk into floppy drive, type A:[return], type INSTALL [return]
3) Follow directions on the screen.
4) Power down and power up the computer to start the network.
In the SmartNet directory the installer can change the system and network
parameters. Passwords, Privileges assigned to functions, Communication parameters
and Node assignments are configured in this area.
To change passwords, exit the SmartNet program. At the SmartNet prompt type:
EDIT PASSWORD [return]. This will load the password initiation file into the DOS
text editor. The file will look like this:
ONE,1,USER_ONE
TWO,2,USER_TWO
THREE,3,USER_THREE
FOUR,4,USER_FOUR
FIVE,5,USER_FIVE
SIX,6,USER_SIX
GAMEWELL,6,GAMEWELL
The type written number represents the password, the numeric number represents
the password access level (1-6) and the user_number is the identification assignment
for the user of the password.. All letters must be upper case and each field must be
separated with a comma. These assignments allow access to the various functions of
the SmartNet and display the identity of the user when accessed. Access levels can
be assigned from 1 to 6 and the user_number can be changed to represent the
individual accessing the function. The password and user_name must be 3 to 10
characters in length.
7
