Override Page Port; Global All Call Page; Global Priority Page - Class Connection VC-24 User Manual

P7 Connecting Block
35
R/S
10
S/R
36
BK/BL
11
BL/BK
GLOBAL ALL CALL PAGE (FROM ATTENDANT DIAL UP)
VC-24 #1
P7 Connecting Block
43 Y/G Y/BR 44
G/Y BR/Y
18 19
NOTE: Global all call page requires programming option to enable feature.
GLOBAL PRIORITY PAGE (FROM OVERRIDE PAGE PORT)
VC-24 #1
P7 Connecting Block
42 Y/O Y/BR 44
17 O/Y BR/Y 19
NOTE: Global all call page requires programming option to enable feature.

OVERRIDE PAGE PORT

Telephone
(SW4 ON)
T R
SW4 on the control board
must be set accordingly
VC-24 #2
P7 Connecting Block
43 Y/G Y/BR 44
G/Y BR/Y
18 19
VC-24 #2
P7 Connecting Block
Y/O Y/BR
42
44
17 O/Y BR/Y
19
9
Tel System
Page Port
OR
(SW4 OFF)
VC-24 #3
P7 Connecting Block
43 Y/G Y/BR
G/Y BR/Y
18
VC-24 #3
P7 Connecting Block
42
Y/O Y/BR
17
O/Y BR/Y
44
19
44
19
