Class Connection VC-24 User Manual page 19

System
Next select System from the Programming Window. A check in the box means ON (selected);
an empty box means OFF (not selected). Select the desired options and click on OK to exit this
screen. The options are described in more detail in the Control Unit (VC-24) document or select
Help from the pull-down menu for on-screen details.
The Dip Switch button displays the dip switch equivalent (see next page) of the options selected
with the programming tool. Note that SW2 and SW3 are not used with the VC-24 System.
19 947226
