Dipswitch Options - Basic System
Note SW1, SW2 and SW3 are not used in the VC-24 System.
Override Port Options
Main Board SW4
INSTALLATION OF THE PROGRAMMING TOOL
The VC-24 Programming Tool is a windows based software tool designed to interface with the VC-24.
Minimum Computer Requirements for the Class Connection
Hardware:
•
80486 (higher is recommended)
•
Hard drive with 30 Mbytes free
•
Mouse
•
8 Mbytes of RAM (more is recommended)
•
1 available serial communication port
Operating System:
•
The Programming Tool is 32-bit and requires Windows 95, Windows 98, or Windows NT 4.0.
The programming tool software is furnished on 1.4 MB disks and must be installed to the hard drive. To install the
software:
•
On the taskbar, click the Start button
•
Insert disk 1
•
Select Run
•
Type a:\Setup (Assuming a: is the disk drive being used)
•
Follow on-screen instructions for full installation, changing disks as the prompt requests
•
The Class Connection
USING THE PROGRAMMING TOOL
•
On the taskbar, click the Start button, point to Programs, and select Class Connection

Programming Tool.

•
The VC-24 Programming Tool splash screen appears momentarily and then the Programming screen
comes into view
Switch OFF
Tel. System Page Port Access
TM
VC-24 Programming Tool will automatically appear in the Programs list
Switch ON
Loop Start Trunk Port
TM
VC-24 Programming Tool:
11
