Class Connection VC-24 User Manual page 15

Enter information for the Main Board as well as each Expansion Unit being used and press OK
to accept.
Audio Connections
This screen allows selection of groups to receive Background Music, Time Tones and
Emergency Tones. This sample system consists of a "Main Board + Expansion 1" so eight
groups are available to receive audio connections. (Each group contains six stations).
Group 1
Group 2
Group 3
Group 4
Group 5
Group 6
Group 7
Group 8
Click on the tab of the desired feature to program zones. Click on each group button to receive
the audio connection. If all groups are to receive an audio connection for the specific feature,
select Include All.
Stations 1, 2, 3, 4, 5, 6
Stations 7, 8, 9, 10, 11, 12
Stations 13, 14, 15, 16, 17, 18
Stations 19, 20, 21, 22, 23, 24
Stations 25, 26, 27, 28, 29, 30
Stations 31, 32, 33, 34, 35, 36
Stations 37, 38, 39, 40, 41, 42
Stations 43, 44, 45, 46, 47, 48
15
Main Board
Main Board
Main Board
Main Board
Expansion 1
Expansion 1
Expansion 1
Expansion 1
