Troubleshooting

Symptom
Picture is jittery
No picture
POWER LED is
not lit
Image is unstable
Image is not
centered, too
small or too large
Picture bounces
or a wave pattern
is present in the

Specifications

UVM-2600 / UVM-3200 models

Items
Panel
EN 10
Check
Adjust Clock to set the
screen position and adjust
Clock value carefully until a
noise is no longer
displayed.
Check if the power switch
and computer power switch
are in the On position
Check if the signal cable is
correctly connected to the
video card.
Check if the pins of D sub-
connector are not bent.
Check if the computer is in
the power- saving mode.
Check if power switch is in
the On position.
Check if the power cord is
correctly connected.
Check if the signal cable is
suitable for the video card.
Adjust Clock or H&V
Center to get the proper
image.
Keep devices that may
cause electrical interference
away from the monitor.
See the FCC information at
the front cover of the
manual.
Screen size
Pixel pitch
View angle (H/V)
Contrast ratio
Response time
Brightness
Recommended
resolution
Symptom
Picture is blurred
Low sound
VIDEO screen
cannot be seen
No video
Poor color in the
video
Grainy picture in
the video
UVM-2600 model
26 in. (66 cm)
0.4215 x 0.4215 mm
178°/178°
3000:1 (typ)
6.5 ms (G-to-G)
450 cd/m² (typ)
1366 x 768 @ 60 Hz
Check
Adjust Contrast and
Brightness.
Adjust the volume on the
OSD menu.
Adjust the volume of the
sound card in the computer.
Check if PICTURE mode
has been set.
Check if the video terminal
is properly connected.
Check if the video cable is
correctly connected to the
computer and set to
Functions on the OSD
picture menu.
Adjust the Color or Tint
values on the OSD Picture
menu.
Adjust the Sharpness
the OSD Picture menu.
UVM-3200 model
32 in. (81.3 cm)
0.36375 x 0.36375 mm
178°/178°
5000:1 (typ)
6.5 ms (G-to-G)
450 cd/m² (typ)
1920 x 1080 @ 60 Hz
