- Page 1 Viper u s e r ` s g u i d e AMERICAN TECHNOLOGIES NETWORK CORP.
-
Page 2: Specifications
The information in this manual furnished for information use only, is subject to change without notice, is not to be construed as a commitment by ATN Corp. ATN Corp. assumes no responsibility or liability for any errors or inaccuracies that may appear in this book. ©2001 ATN Corp. All right reserved. - Page 3 You should not have to readjust the diopter. FOCUSING To focus the Viper, first you will need to adjust the diopter. Simply turn the diopter clockwise until it stops. Then, while looking throught the diopter at an object, slowly turn the diopter back counter clockwise until the grain in the image is sharp.
- Page 4 USING THE 4X TO 8X DOUBLER Unscrew 35 mm lens off the body of the Viper (make sure that the unit is turned off). Screw the doubler into the body of the Viper where the 35 mm lens was removed. Screw the 35 mm lens or your 90 mm lens into the doubler.
- Page 5 • We suggest that you find an open space to work in. Focus the Viper so that the scene is at its sharpest. For best results you should disable the auto focus (if any) on either the 35mm camera or the video camera and manually focus the 35mm camera or the video camera.
-
Page 6: Trouble Shooting
CLEANING THE EYEPIECE You may need to clean the eyepiece of the Viper from time to time in order to guarantee top performance. When you receive your Viper you should check for dust on the eyepiece of the unit. First you will need to remove the eyepiece. To do that you will need to initially loosen the 2 set screws that can be found on the base. -
Page 7: Limitation Of Liability
ATN, at its option, will either repair or replace the product, and such action on the part of ATN shall be the full extent of ATN’s liability, and the Customer’s sole and exclusive remedy. This warranty does not cover a product (a) used in other than its normal and customary manner;... - Page 8 20 S. Linden Ave. Suite 1B, South San Francisco, CA 94080 phone: 800-910-2862, 650-875-0130; fax: 650-875-0129 European Office phone: 44(0)870-0111286, fax: 44(0) 845-3349142 The following countries can use our toll free number 00 800 9102-8620 Austria, France, Germany, Holland, Italy, Spain, Sweden, Switzerland www.atncorp.com ©2001 ATN Corporation...
