- Page 1 Night Shadow Night Shadow Night Shadow u s e r ` s AMERICAN TECHNOLOGIES NETWORK CORP. g u i d e...
- Page 2 The information in this manual furnished for information use only, is subject to change without notice, is not to be construed as a commitment by ATN Corp. ATN Corp. assumes no responsibility or liability for any errors or inaccuracies that may appear in this book. ©2002 ATN Corp. All right reserved.
- Page 3 The objective lens protective cover is designed to protect the objective lens from dust and scratches. It also acts as a daylight filter allowing you to test the biocular in the daylight or other bright light situations. The pinhole in the center of the protective cover allows the user to check the operation ability of the device under the daylight conditions.
-
Page 4: Infra-Red Illuminator
NOTE: The distance between your eyes could be adjusted by manipulat- NOTE: ing the biocular eyepiece of the Night Shadow. To focus the Night Shadow you will need to adjust the diopters first. Simply turn the diopters clockwise until they stop. Then, while looking through the diopters at a subject, slowly turn the diopters back counter- clockwise until the grain in the image is sharp. - Page 5 USING THE CAMERA ADAPTER To use your Night Shadow with a 35-mm camera or camcorder you will need the following: 1) If you plan to use a camcorder then camcorder must have a MACRO feature. Most modern camcorders today have a MACRO feature built in. 2) If you plan to use a 35-mm camera you will need a MACRO lens.
- Page 6 USING THE DOUBLER NOTE: NOTE: When attaching the doubler do not be afraid to use a little force. NOTE: When attaching the doubler do not be afraid to use a little force. • Make sure that the unit is turned off. •...
-
Page 7: Operation
• Adjust the digital features as needed. • Take your time to learn about your “smart “ biocular. It will take practice to properly use the device. As you use these biocular you are able to improve your speed of focusing, as well as sharpness of the image. -
Page 8: Storage And Care
• Do not disassemble except to clean the front lens or eyepiece: it will void your warranty. • Evaluate the biocular function by looking through it in a lit environment with the daylight filter lens cap on. Never use in daylight without the daylight filter lens cap on. -
Page 9: Troubleshooting
TROUBLE SHOOTING Q: Flashes, flickers, or clicking occur while operating S: If it occurs within the first five minutes of inserting new batteries it is normal and the device will resume normal operation soon thereafter. If it occurs after 10 minutes contact to your dealer or other authorized representative for service instructions. -
Page 10: Specifications
SPECIFICATIONS Magnification ...3x (6x with Doubler) - 1st Gen.; ...5x (10x with Doubler) - 2nd Gen., 3rd Gen., 4th Gen. Intensifier Tube ...High Res. 1st+ Gen., 2nd+ Gen., 3rd Gen. or 4th Gen. Lens System ...6 elements; F1.2, 90 mm Field of View ...14°... -
Page 11: Limitation Of Liability
ATN, at its option, will either repair or replace the product, and such action on the part of ATN shall be the full extent of ATN’s liability, and the Customer’s sole and exclusive remedy. This warranty does not cover a product (a) used in other than its normal and customary manner;... - Page 12 20 S. Linden Ave. Suite 1B, South San Francisco, CA 94080 phone: 800-910-2862, 650-875-0130; fax: 650-875-0129 European Office phone: 44(0)870-0111286, fax: 44(0) 845-3349142 The following countries can use our toll free number 00 800 9102-8620 Austria, France, Germany, Holland, Italy, Spain, Sweden, Switzerland www.atncorp.com ©2002 ATN Corporation...
