Pulse Amperage Range
Gas Post Flow Time
Gas Pre Flow Time
Arc Starting Mode
AC Waveforms
AC Balance Control
AC Easy Start Parameters
DC Easy Start Parameters
Gross Weight
Insulation
Dimensions mm
Read entire section before starting installation
WARNING!
Electric Shock can kill – Only qualified personnel should perform this installation. Turn off input
power at the fuse box before working on this equipment. Do not touch electrically live parts. Always
connect the machine to an earthed mains supply as per national recommended standards.
Select suitable location
Place the welder where clean cooling air can freely circulate in and out of the front & rear louver
vents. Dirt, dust or any foreign material that can be drawn through vents into welder must be kept to
a minimum. Failure to observe these precautions can result in excessive operating temperatures
which can lead to plant failure.
Grinding
Do not direct grinding particles towards the welder. An abundance of conductive material can cause
plant failure.
Stacking
5
5 - 95%
0 - 50 Seconds
0 - 25 Seconds
High Frequency
Advanced Squarewave
Soft Squarewave
Triangular
Sine Wave
5 - 90% of Electrode Positive
AC Frequency 120Hz
AC Balance 25%
Pre flow Gas .5 seconds
Post Flow Gas 4 seconds
Main Amps 120A
Start/End Amps 50A
Upslope 1 seconds
Downslope 3 seconds
Pre flow Gas .5 seconds
Post Flow Gas 4 seconds
Main Amps 90A
Start/End Amps 50A
Upslope 1 seconds
Downslope 3 seconds
24 KG
IP21S
438H x 232W x 550L (mm)
