- Page 1 REVAMP2060T Instruction manual...
- Page 3 REVAMP2060T Instruction manual REVAMP2060T manual...
-
Page 4: Safety First
DIGITAL POWER AMPLIFIER Safety first! • Caution! This professional device needs to be installed by qualified personnel only. • Please check the carton box for any kind of damage on reception of the goods. In case of a damaged carton, please contact your dealer before opening the carton. - Page 5 REVAMP2060T Instruction manual • Do not use the unit if the electrical power cord is frayed or broken. • Always operate the unit with the AC ground wire connected to the electrical system ground. • Set level controls on amplifiers all the way down during power- up to prevent speaker damage if there are high signal levels at the inputs.
- Page 6 DIGITAL POWER AMPLIFIER • Do not run the output of any amplifier back into another input. • In case of mal-function this device should be serviced by qualified service personnel only. • This unit has NOT been designed for use in mobile applications, such as: mobile discobars, mobile PA systems, Live bands, audio rental systems, …...
- Page 7 REVAMP2060T Instruction manual Features • 1 rack unit high • High power class-D power amplifier module • Toroidal 100 volt output transformers • Bridgeable 2 channel amplifier • Output power: 2 x 60 W @ 100 V or 70 V •...
- Page 8 DIGITAL POWER AMPLIFIER Connections 1. Channel 2 overload led: when this led lights up, you are overloading the input. Lower the input level immediately to prevent distortion. 2. Channel 1 overload led: when this led lights up, you are overloading the input. Lower the input level immediately to prevent distortion.
- Page 9 REVAMP2060T Instruction manual switch lights up when bridge mode has been activated. Always disconnect the speaker(s) before (de-)activating bridge mode ! In bridge mode, the input signal from channel 1 is used. For use with low impedance speakers, the minimum load impedance in bridge mode is 8 ohms: connect –...
-
Page 10: Operation
DIGITAL POWER AMPLIFIER Operation 1. Removable rack ears for 19” rack mounting. 2. Power switch: after switching on the power, the power led will light up after approx 1 second. 3. Power led 4. Channel 1 status led bar and mute switch: when the mute switch is pressed, the orange “LIMIT –... - Page 11 REVAMP2060T Instruction manual 5. Bridged CH 1-2 led 6. Channel 2 status led bar and mute switch: when the mute switch is pressed, the orange “LIMIT – MUTED” led will light up. This led will also light up when the internal limiter is activated to avoid the amplifier from being overloaded by high input signals.
-
Page 12: Important Notice
… Note: Before using the amplifier for the first time, check the impedance of your 100 volt speaker lines using the Apart IMPMET: temporarily disconnect the speaker line from the amplifier and measure the speaker line. Impedance @ 100 volt must be 167 ohms... -
Page 13: Technical Specifications
REVAMP2060T Instruction manual Technical specifications output power RMS @ 100 volts 2 x 60 watts output power RMS bridged @ 100 120 watts volts output voltage tappings 100 -70 - 50 - 35 watts - 4 ohms RMS output power @ 4 ohms... - Page 14 DIGITAL POWER AMPLIFIER frequency response 50 - 20 kHz cooling system convectional Protection circuits over current, over temperature, DC offset Operating temperature range 0 to 40°C Net weight product 5.7 kg height- rack units (1U=44 mm) depth (build in) 230 mm depth (incl front) 239 mm 19"...
- Page 16 Apart Audio nv Industriepark Brechtsebaan 8 bus 1 2900 Schoten - Belgium Company names, product names and trademarks are property of their respective owners. Apart-Audio specifications are subject to change without notice.
