Clas Ohlson RC123 Instruction Manual

Radio Controlled Alarm Clock
Art.no 36-5340 Model RC123
Please read the entire instruction manual before using the product and save it
for future reference. We reserve the right for any errors in text or images and any
necessary changes made to technical data. If you have any questions regarding
technical problems please contact our Customer Services.
Things to consider:
• Other wireless equipment using the same frequency can reduce
the transmission range.
• The range of all wireless equipment depends on the type of obstacles located
between the transmitter and the receiver (e.g. a concrete wall will interfere with
the signal more than a plasterboard wall).
If you experience problems, try the following:
• Turn off any other existing wireless equipment and check if this is the cause of
the problem.
• Reposition the wireless equipment, shorten the distance between the sending
and receiving devices or reduce the number of obstacles (walls, furniture, etc.)
between them.
What is a radio controlled clock?
A radio controlled clock is an extremely accurate timekeeping device. The time is
controlled by the atomic clock in Braunschweig, Germany (accuracy ±1 second per
1 million years). The clock has a built -in radio receiver that decodes the incoming
atomic clock signal (long wave 77.5 kHz). The product also has a precisely
calibrated quartz clock movement with a frequency of 32 kHz that keeps it running.
The transmitter in Germany has an official range of 2,000 km. This means that
the UK and Ireland should be well within range.
Safety
• The alarm clock must only be repaired by qualified service technicians.
• The alarm clock is intended for indoor use only.
• Do not place the alarm clock where there is a risk of it falling into water or
other liquid.
• Do not place the alarm clock in damp or dusty environments or where it could
be subject to strong vibrations.
• Do not expose the alarm clock to extremely high or low temperatures. Do not
expose the product to direct sunlight.
• Never try to open, change or modify the alarm clock in any way.
• Always remove the batteries if the alarm clock is not to be used for a long time.
Buttons and functions
1. [ Alarm on/off ]
2. [ Date set, Time set,
Alarm set — ]
GREAT BRITAIN • customer service tel: 08545 300 9799 e-mail: customerservice@clasohlson.co.uk internet: www.clasohlson.com/uk
3. [ ▲ ] Increases and sets values for
date, time, alarm and activates
backlight
4. [ ▼ ] Decreases and sets values
for date, time, alarm and activates
backlight
5. Battery holder
Display symbols
Time signal received
Time signal scan
PM (shown only for the 12-hour clock display)
Alarm
Snooze
Time zone
British Summer Time (GMT+1)
Low battery

Operating instructions

1. Open the battery cover by sliding it downwards.
2. Insert 2 × AAA/LR03 batteries. Note the polarity markings in the battery
compartment to ensure correct insertion.
3. Once the batteries have been inserted the clock will immediately begin
scanning for the time signal transmission
4. If the time signal is received, both time and date will automatically be set and
the received time signal icon will appear.
If no time signal is received, the search icon will stop flashing and no icon will ap-
pear. The time and date must also be set manually.
Manually setting the date
1. Set the [ Date set, Time set, Alarm set — ] switch in the Date set position.
2. Hold in [ ▲ ] or [ ▼ ] until the correct year appears. Release the button when
the correct year is shown.
3. Hold in [ ▲ ] or [ ▼ ] until the correct month appears. Release the button when
the correct month is shown.
4. Hold in [ ▲ ] or [ ▼ ] until the correct day appears. Release the button when
the correct day is shown.
1
Manually setting the time
1. Set the [ Date set, Time set, Alarm set — ] switch in the Time set position.
2. Hold in [ ▲ ] or [ ▼ ] until the correct time appears.
Setting the alarm
1. Set the [ Date set, Time set, Alarm set — ] switch in the Alarm set position.
2
2. Hold in [ ▲ ] or [ ▼ ] until the correct alarm time appears.
3. Set the [ Date set, Time set, Alarm set — ] switch in the — position once all
desired settings have been entered.
4. Press [ Alarm on/off ] to turn the alarm on or off.
5. When the alarm sounds, both the set alarm time and alarm icon will flash.
6. Press [ Alarm on/off ] to turn the alarm off.
3
7. If no button is pushed the alarm will automatically shut off after 2 minutes.
4
12/24 hour time display
Press [ ▲ ] to select either a 12 or 24 hour clock display.
5
Displaying seconds or day and language selection
Press [ ▼ ] to select whether to display seconds or current day.
Hold in [ ▼ ] for 3 seconds to select language from the rolling display:
"DE" (German), "FR" (French), "IT" (Italian), "SP" (Spanish), "DU" (Dutch),
"SW" (Swedish) or "EN" (English). Release the button once the desired
language is shown.
Dual time zone setting
1. Hold in [ ▲ ] until "F" appears in the display.
2. Set the [ Date set, Time set, Alarm set — ] switch in the Time set position.
3. Press [ ▲ ] or [ ▼ ] until the desired time zone is displayed (-12 to +12 hours).
4. Set the [ Date set, Time set, Alarm set — ] switch in the — position once all
desired settings have been entered.
5. Hold in [ ▲ ] to switch between local/normal time display and the other time zone.
Snooze function
Press [ ▲ ] or [ ▼ ] when the alarm sounds to activate the snooze function.
The alarm will pause and then sound again after 4 minutes.
Display illumination
Press [ ▲ ] or [ ▼ ] to turn on the backlight. The backlight has a 5-second duration
and turns off automatically.

Care and maintenance

Clean the product using a lightly moistened cloth. Only use mild cleaning agents,
never solvents or corrosive chemicals.

Troubleshooting guide

The clock is not working.
Disposal
This product should be disposed of in accordance with local regulations.
If you are unsure how to proceed, contact your local authority.

Specifications

Batteries
Size
• Check that the batteries are not flat.
• Check for correct battery insertion.
2 × AAA/LR03
80 × 80 × 30 mm
