Alarm Clock
Art.no: 31-4183 / 31-4184 Model: C-8172ADB AMB AWB
Please read the entire instruction manual before using and
save it for future use. We apologise for any text or photo
errors and any changes of technical data. If you have any
questions concerning technical problems please contact our
Customer Services.

Product description

Radio controlled alarm clock. The clock is equipped
with a radio receiver which decodes a time signal and
automatically adjusts the time.

Buttons and functions

1
2
5
3
4
6
7
GREAT BRITAIN For consumer contact, please visit www.clasohlson.co.uk and click on customer service.
ENGLISH
1. LCD-display
2. [MODE]
Press to switch between normal time and alarm mode.
Depress the button for 3 seconds to reach the set mode.
3. [UP]
In normal mode, push once to switch between a 12
and 24 hour display. In the settings mode, press UP to
increase the value.
4. [DOWN]
In normal mode, push once to switch between °C and °F.
In the settings mode, press DOWN to decrease the value.
5. [ALARM]
In normal time or alarm time mode, press once to
activate the alarm. Press twice to activate the snooze
function and press 3 times to turn off the alarm and the
Snooze function. During snooze, press once to turn off
the alarm and the snooze function.
6. [SNOOZE/LIGHT]
Press once to turn on the backlight for 5 seconds.
During snooze, press once to temporarily turn off
the alarm and continue using the snooze function. In
normal mode, depress the button for 3 seconds to begin
receiving and synchronising the time signal. In radio
signal reception mode, depress the button for 8 seconds
to halt the current reception.
7. [RESET]
Display
Normal time mode
1. Normal time
8
2. Month
7
6
3. Date
5
4. Day of the week
5. Seconds
1
2
7. Summer time/Winter time
8. Temperature
4
3
Alarm mode
1. Alarm time
4
2. Snooze function
3
3. Alarm icon
2
4. Alarm mode indicator
1

Inserting the batteries

1. Remove the battery cover by carefully pressing the side tab.
2. Insert 2x AAA/LR03 batteries. Make sure the battery
poles are facing the right direction by following the
markings in battery compartment.
3. Replace the battery cover.
When the batteries are in place all the display icons will
illuminate for a short time before the alarm clock goes
into normal time mode. The alarm clock will automatically
search for a radio signal after 10 seconds.
Considerations for alarm
clock placement
For the best reception, consider the following:
-
We strongly recommend that you turn on the alarm
clock in the evening and let it automatically receive the
time signal during the night.
-
Place the clock at a distance from possible signal
disturbances like TVs, computers, etc.
-
The clock may lose some performance when used
in enclosed spaces such as cellars or buildings with
thick walls.
-
Do not turn on the time reception function if you are in
movement i.e. on a train, car, etc.
