Clas Ohlson 922265 Instruction Manual

Wooden Cube Alarm Clock
Art.no 44-2516-1 Model 922265
44-2516-2 922263
Please read the entire instruction manual before using the product
and then save it for future reference. We reserve the right for
any errors in text or images and any necessary changes made to
technical data. In the event of technical problems or other queries,
please contact our Customer Services.
Product description
1. Outer battery cover
2. [ SET ] Settings
3. [ UP ] Move up in menu/
increase a value
4. [ DOWN ] Move down
in menu/decrease a value
5. USB port
SET
1 2

Operating instructions

Operation using USB cable
Connect the clock to a computer or other USB charging device
using the included USB cable. Note: A compatible USB charger is
not included but can be purchased separately.
Note: For optimum operation and to preserve battery charge,
the alarm clock should be powered using the USB cable
wherever possible.
Battery operation
Remove the battery cover (1) and insert 3 × AAA/LR03 batteries
with the terminals facing in the same direction as shown on
the markings on the bottom of the battery compartment.
Refit the battery cover.
GREAT BRITAIN customer service tel 020 8247 9300 e-mail customerservice@clasohlson.co.uk
internet www.clasohlson.co.uk postal 10 – 13 Market Place, Kingston Upon Thames, Surrey, KT1 1JZ
Power save mode on/off
Note: During battery operation the power save mode should
always be ON.
• Press [ DOWN ] repeatedly to switch between power save
mode ON/OFF. When "oNSd" is displayed, the power save
mode is ON. When "−−Sd" is displayed, the power save mode
is OFF.
• The display will switch off after 10 seconds of inactivity and
remain off until any of the sides of the cube is touched or until
the alarm sounds.
Clock memory battery
If the clock no longer keeps time after a power cut the factory
installed CR2032 battery must be changed. To gain access to
this battery you must remove the cover at the bottom of the main
battery compartment.
Setup
Time, date and alarm
DC 5V
1. Press [ SET ] repeatedly to toggle to the desired function.
UP DOWN
2. Press [ UP ]/[ DOWN ] to select the desired value.
3. Press [ SET ] or wait 15 seconds for the setting to be saved.
3 4 5
Alarm on/off
1. Press [ SET ] the required number of times until alarm "A1", "A2"
or "A3" is displayed.
2. Press [ UP ] to toggle between –– (off) and ON (on).
Temperature
1. Press [ SET ] repeatedly until the temperature setting is displayed.
2. Hold down [ DOWN ] for 3 seconds to toggle between
Celsius (°C) and Fahrenheit (°F).
Display programmes
Press [ UP ] to choose one of the display programmes dp-1, dp-2
or dp-3.
• Display programme 1 "dp-1". The display alternates between
showing the time, date and temperature. The time is shown for
10 seconds, the date and temperature for 2 seconds.
• Display programme 2 "dp-2". Press [ SET ] repeatedly to
choose which type of display you want shown; date, alarm
or temperature.
• Display programme 3 "dp-3". The display will show the time,
which is the standard setting.

Care and maintenance

Clean the product using a lightly moistened cloth. Use only mild
cleaning agents, never solvents or corrosive chemicals.
Responsible disposal
This symbol indicates that this product should not
be disposed of with general household waste. This
applies throughout the entire EU. In order to prevent
any harm to the environment or health hazards caused
by incorrect waste disposal, the product must be
handed in for recycling so that the material can be
disposed of in a responsible manner. When recycling
your product, take it to your local collection facility
or contact the place of purchase. They will ensure
that the product is disposed of in an environmentally
sound manner.

Specifications

Power supply USB cable or
3 × AAA/LR03 batteries (sold separately)
Time memory 1 × CR2032 battery (factory installed)
Size 63 × 63 × 63 mm
Quick guide
