- Page 1 For Firmware Version V1.9 Publication AP10287...
- Page 2 Any changes or modifications to the product not approved by Allen & Heath could void the compliance of the product and therefore the user’s authority to operate it. Qu-SB Getting Started Guide AP10287 Issue 1 Copyright © 2016 Allen & Heath. All rights reserved ALLEN&HEATH Allen &...
-
Page 3: Safety Instructions
USB key. Read the Release Notes that come with the firmware. V1.9 This guide refers to Qu-SB firmware Software licence agreement By using this Allen & Heath product and the software within it you agree to be bound by the terms of the relevant End User Licence Agreement (EULA), a copy of which can be found on the Allen &... -
Page 4: Packed Contents
• Check this is correct for your territory Options and Accessories available 19” Rack Ears kit Qu-SB polyester carry bag Part: QU-SB-RK19 Part AP10560 Remote Audio Racks Provides access to all 32 channels and extra mixes over dSNAKE Cat5 cable digital snake. -
Page 5: Table Of Contents
2. Contents Packed contents ..........................4 Contents ............................5 Introduction to Qu-SB ........................6 Installing Qu-SB ..........................8 Connector Panel ..........................9 Connect and Power Up ......................... 11 Set up the Wireless Network ....................11 Connect dSNAKE (option) ....................12 Power up the mixer ....................... -
Page 6: Introduction To Qu-Sb
3. Introduction to Qu-SB Qu-SB is part of the Allen & Heath Qu Series of digital mixers. It is similar to the faderless Qu-Pac but without front panel controls. Qu-SB provides a compact solution for wireless mixing using an iPad. An external Wi- Fi router (wireless access point) is required. - Page 7 The following diagram shows the available Qu-SB signal flow and processing. A more detailed diagram and further information is available within the Qu Mixer Reference Guide which can be downloaded from the Allen & Heath website. Qu-SB SIGNAL FLOW Cat5 Digital Snake to AudioRack and ME Personal Monitor System...
-
Page 8: Installing Qu-Sb
A gap underneath the unit lets you feed cables through from within the rack. Rack mounting option kit QU-SB-RK19 is available from Allen & Heath. - Ensure adequate air flow. Do not block the rear ventilation slots or the gap underneath the front of the unit. -
Page 9: Connector Panel
This is the front panel of the mixer. It provides all control and audio connections, USB sockets, headphones and reset functions. The only connection provided on the rear panel is the mains power input. Network Port – Qu-SB is controlled using an iPad running the Allen & Heath Qu-Pad app. Connect a wireless router (wireless access point) to this port to set up a Wi-Fi network for the iPad to connect to the mixer. - Page 10 To prevent damage to your hearing start with the Phones level turned down and avoid listening to loud volume for extended periods. Qu-32 Core – Qu-SB is the smallest model in the Qu range but uses the same 32 channel DSP mix engine as the largest model, the Qu-32.
-
Page 11: Connect And Power Up
6. Connect and Power Up 6.1 Set up the Wireless Network Qu-SB is set up and controlled using an iPad. This connects to the mixer via a wireless router plugged into the Network port. This sets up a private Wi-Fi network for the mixer. -
Page 12: Connect Dsnake (Option)
Switching the mixer off – Mute or turn the PA speakers off first. Turn the Qu-SB power off at the mains socket or simply pull out the IEC mains cord at the AC MAINS IN socket. Qu-SB Getting Started Guide... -
Page 13: Connect The Ipad
6.4 Connect the iPad The Qu-SB mixer is controlled using an iPad running the Allen & Heath Qu-Pad app. Choose and set up a wireless router as described previously. Settings are stored in the mixer. Audio will continue to run even if the iPad is disconnected. -
Page 14: Get To Know The Qu-Pad App
Mix master strip - This fader strip becomes the master for the mix selected using the buttons to the right. Learn more about using Qu-Pad from the Help manual within the app. Open Help from either the Login page button or the Setup page Help tab. Qu-SB Getting Started Guide AP10287 iss1... -
Page 15: Qu-Start
7. Qu-Start This section provides a quick guide to get you started mixing with Qu-SB and Qu-Pad. For more information please refer to the Qu-Pad Help manual and to the Qu Mixer Reference Guide available for download from www.allen-heath.com/key-series/qu-series. 7.1 Set a known starting point... - Page 16 Assign the Custom Layers – Use the Setup screen Strips page to drag and drop strips to the three available custom strips. Qu-SB Getting Started Guide AP10287 iss1...
-
Page 17: Save The Settings
The Qu-Pad app requires the Admin password if set. Admin can set a separate password for Qu-You users. A scene range and login scene can be set for the Standard and Basic users. Qu-SB Getting Started Guide AP10287 iss1... -
Page 18: Usb Recording And Playback
The Qu AMM can automatically take over the level of these mics to improve clarity and reduce the risk of feedback caused by many open microphones. Qu-SB Getting Started Guide AP10287 iss1... -
Page 19: Network Reset
7.7 Network Reset There are two reset functions available using the Qu-SB recessed panel switch above the Network socket. While the mixer is on, use a thin pointed object to press and hold the front panel Network Reset key. - Page 20 Qu-SB Getting Started Guide AP10287 iss1...
