CYBEX RUBY User Manual page 12

EN CONTENT
I. General Information & Safety .......................................................20
II. Instructions for maintenance ........................................................21
III. Instructions for use .........................................................................21
1. Opening the stroller ....................................................................................
2. Assembling the front wheels ......................................................................
3. Assembling the basket ...............................................................................
4. Using the brakes ..........................................................................................
5. Automatic front wheel swivel locks ...........................................................
6. Using the harness system ............................................................................ 22
7. Attaching the hood .................................................................................... 22
8. Reclining the seat ....................................................................................... 22
9. Folding the stroller ....................................................................................... 22
10. Carrying the stroller ..................................................................................... 22
11. Removing the seat cover ........................................................................... 22
12. Attaching the rain cover (optioal) ............................................................ 22
13. Inserting the seat inlay ................................................................................ 22
IV. Part list ..............................................................................................
V. Guarantee ......................................................................................23
20 20
I. GENERAL INFORMATION & SAFETY
WARNING: IT MAY BE DANGEROUS TO LEAVE YOUR CHILD UNATTENDED.
Your child´s safety is your responsibility. Always use the harness system to prevent
your child from falling or sliding out of the seat. This vehicle is suitable for one child
only.
Follow all instructions carefully to avoid incorrect handling as this can impair the
stroller's correct function.
THIS VEHICLE IS INTENDED FOR CHILDREN FROM 6 MONTHS AND UP TO 15kg.
Use of this stroller with a child weighing more than 15 kg will cause excessive wear
and tear on the stroller.
WARNING: ALWAYS USE THE CROTCH STRAP IN COMBINATION WITH THE WAIST BELT.
The harness always needs to be attached and adjusted correctly. If not adjusted
correctly according to the instructions the stability of the stroller will be affected.
WARNING: USE A HARNESS SYSTEM AS SOON AS THE CHILD CAN SIT UNAIDED
21
The harness and seat belt do not replace the permanent supervision by an adult.
21
WARNING: THIS PRODUCT IS NOT SUITABLE FOR RUNNING OR SKATING.
21 – To attach an additional full harness system for safety reasons 'D' rings (according
to EN13210 or BS6684) are provided.
21
– The child should be clear of any moving parts while making adjustments. Prevent
22
children from grabbing the stroller while folding and unfolding, as fi ngers can
become trapped and scissoring actions are unavoidable.
WARNING: ANY LOAD ATTACHED TO THE HANDLES AFFECTS THE STABILITY OF THE
STROLLER.
Do not carry additional children, do not hang shopping bags from the handlebars
or carry shopping bags on the stroller except in the stroller's basket. Maximum
load 2 kg. Otherwise the stroller is likely to become unstable. Overloading can also
damage the vehicle.
– Damages caused by the use of accessories not approved by CYBEX, such as
rain covers, buggy boards, bag hooks, etc. will not be covered by the terms of
our warranty.
– It may be unsafe to use replacement parts other than those approved by
CYBEX.
– Before using the stroller, always check whether the accessories are well
23
secured.
– Ensure that the stroller is always in the brake position when you put your child into
the seat.
– Never lift the stroller with the child inside; never ascend or descend stairs or
escalators with the child inside or when traveling on other forms of transport.
– When opening and closing the stroller, do not use force, as incorrect folding can
damage or break the stroller. Check the instruction manual if necessary.
– Drive carefully over curbs and gravel roads. The vehicle will be damaged by
repeated impact.
– Make sure your child does not use the footrest to stand on.
– Do not expose the stroller to any artifi cial heat or direct sunlight.
II. INSTRUCTIONS FOR MAINTENANCE
– The user is responsible for the regular maintenance of the stroller. All connecting
parts and rivets have to be tightened and secured properly. It is particularly
important to ensure that the locking mechanism and swiveling mechanism
are treated regularly with Tefl on spray (dry lubricant). It is important that brakes,
wheels and tyres are not impaired during use. Inspect them regularly and repair
or replace if necessary. STOP using any product that does not appear structurally
sound.
– Do not make any modifi cations to the product. If you have any complaints or
problems, please contact your supplier or importer.
– A service should be scheduled every 12 months.
– Never lubricate the wheels or axles with oil. If you treat the axles with acid-free
Vaseline regularly, the wheels will continue to run smoothly.
– You can also treat the other moving parts with Tefl on spray (dry lubricant). After
spraying on the Tefl on, wipe the product with a soft cloth.
– Use only original CYBEX replacement parts. It may be unsafe to use substitutes.
– The frame tubes covered by the locking mechanism and turning mechanism
should also be regularly cleaned and sprayed. This will ensure that you enjoy
your stroller without any problems.
CLEANING
– Do not use abrasives to clean the frame! Use a damp cloth and a mild detergent
and dry thoroughly.
– Should the stroller be exposed to salt water, please rinse it down with fresh (tap)
water as soon as possible afterwards.
– The upholstery and cover can be washed by hand with mild detergent (not
warmer than 30°C).
– See care labels for details. Do not use the washing machine or tumble drier. Dry
thoroughly before reuse.
– All CYBEX fabrics have been tested, but when the stroller is very wet, the water
may permeate the lining through the bottom edges and seams and leave
water stains on the upholstery. We advise you to use a rain cover to avoid this.
Also please do not fold or store the product while wet. If the stroller is wet, allow
to dry with the hood extended. Never store in a damp environment as this can
cause mildew to form.
Note! Please wash the cover separately before you use it the fi rst time. Do not
tumble dry and do not expose to direct sunlight! Do not iron!
This product was approved according to the EN 1888:2003 + A1/A2/A3:2005
standard.
DISPOSAL
When you are done using your CYBEX RUBY, a proper disposal is important.
Garbage disposal can be different in every country. Please contact your local
waste management company to make sure you are taking the right steps to
dispose of the CYBEX RUBY. Always follow the disposal regulations of your country.
III. INSTRUCTIONS FOR USE
IMPORTANT: READ THESE INSTRUCTIONS CAREFULLY BEFORE USE AND KEEP THEM
FOR FUTURE REFERENCE. YOUR CHILDREN'S SAFETY MAY BE AFFECTED IF YOU DO
NOT FOLLOW THESE INSTRUCTIONS.
Please fold out the pages with illustrations which can be found in the beginning of
this manual and then refer to the instructions.
1. OPENING THE STROLLER
1. Release the folding lock lever.
2. Open the stroller.
3. Push the pedal button down until the locking system is engaged.
WARNING: ENSURE THAT ALL LOCKING DEVICES ARE ENGAGED BEFORE USE.
2. ASSEMBLING THE FRONT WHEELS
1. Snap in the front wheels until the snap finger is engaged.
3. ASSEMBLING THE BASKET
1. Slide the two front loops of the basket over the seat tubes.
2. Hook in the remaining two loops in the basket´s corners into the two C-shaped
rings on the rear tubes.
Reverse this procedure to take the basket off.
4. USING THE BRAKES
1. Use your foot to push the brake lever down on one of the back wheels to engage
the brakes. The brakes of the back wheels are linked to each other, so that both
brakes are operated simultaneously.
2. Lift the brake lever again to release the brake.
WARNING: ENSURE THAT THE PUSHCHAIR IS ALWAYS IN THE BRAKE POSITION WHEN
YOU PUT YOUR CHILD INTO THE SEAT.
21
