Panasonic S-60PT2R5A Operating Instructions Manual

Panasonic S-60PT2R5A Operating Instructions Manual

Hide thumbs Also See for S-60PT2R5A:

Advertisement

Ceiling
(T2 type)
Model No.
INDOOR UNIT
Ceiling
(T2 type)
S-60PT2R5A
S-71PT2R5A
S-100PT2R5A
S-125PT2R5A
S-140PT2R5A
Before operating the unit, read these operating instructions thoroughly and keep them for future reference.
Panasonic Corporation
1006 Kadoma, Kadoma City, Osaka, Japan
4-Way Cassette
(U1 type)
4-Way Cassette
(U1 type)
S-60PU1R5A
S-71PU1R5A
S-100PU1R5A
S-125PU1R5A
S-140PU1R5A

Operating Instructions

Air Conditioner

OUTDOOR UNIT
Single Split
(Single-phase)
U-60PE1R5A
U-71PE1R5A
U-100PE1R5A
U-125PE1R5A
U-140PE1R5A
Single Split
(3-phase)
U-100PE1R8A
U-125PE1R8A
U-140PE1R8A
F569618

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the S-60PT2R5A and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Panasonic S-60PT2R5A

  • Page 1: Operating Instructions

    Air Conditioner Ceiling 4-Way Cassette (T2 type) (U1 type) Model No. INDOOR UNIT OUTDOOR UNIT Ceiling 4-Way Cassette Single Split (T2 type) (U1 type) (Single-phase) S-60PT2R5A S-60PU1R5A U-60PE1R5A S-71PT2R5A S-71PU1R5A U-71PE1R5A S-100PT2R5A S-100PU1R5A U-100PE1R5A S-125PT2R5A S-125PU1R5A U-125PE1R5A S-140PT2R5A S-140PU1R5A U-140PE1R5A...
  • Page 2: Table Of Contents

    Thank you for purchasing this Panasonic product. WARNING This product is a commercial air conditioner indoor unit. Installation Instructions attached. Contents Confirm to authorized dealer or specialist on usage of specified refrigerant type. Using of refrigerant other than the Safety Precautions ............2 specified type may cause product Precautions for Use ............
  • Page 3 CAUTION This appliance is intended to be used Provide a power outlet to be used by expert or trained users in shops,in exclusively for each unit, and a light industry and on farms, or for power supply disconnect, circuit commercial use by lay persons. breaker and earth leakage breaker This appliance is not intended for for overcurrent protection should be...
  • Page 4: Precautions For Use

    Precautions for Use Installation Operation Condition This air conditioner must be installed properly by qualified Use this air conditioner under the following temperature range. installation technicians in accordance with the Installation „ Indoor temperature range: Instructions provided with the unit. Cooling mode 14°C ~ 25°C (*WBT) / 18°C ~ 32°C (*DBT) Before installation, check that the voltage of the electric sup-...
  • Page 5: Names Of Parts

    Names of Parts INDOOR UNIT OUTDOOR UNIT Water drain Air intake Air intake Ceiling panel (optional) Air outlet (4 locations) Air intake grille (air intake) U1 type (4-Way Cassette) Air outlet Air outlet Air outlet 60, 71 type 100, 125, 140 type Water drain Air intake grille (air intake) T2 type...
  • Page 6: Adjusting Airflow Direction

    Adjusting Airflow Direction This section is described in the instruction manual supplied with the timer remote contoller (CZ-RTC2). Regarding the High-spec Wired Remote Controller (CZ-RTC3), refer to the Operating Instruction supplied with the model CZ-RTC3. Adjusting the upward and downward motion of airflow direction (U1 and T2 types) „...
  • Page 7: Indoor Units

    Adjusting airflow direction for multiple indoor units (Timer remote controller only) When operating multiple indoor units using 1 remote controller, airflow direction can be adjusted for indoor each unit individually or all units at the same time. Unit No. „ When setting the airflow direction of each indoor unit individually Press to select the Unit No.
  • Page 8: Maintenance

    Maintenance Indoor unit (e.g. U1 type) WARNING Air outlet For safety, be sure to turn the air conditioner off and dis- connect the power before cleaning. Air intake (Otherwise, electric shock or injury may result because the fan is rotating at high speed.) Do not pour water on the indoor unit.
  • Page 9: Troubleshooting

    Troubleshooting Check before consulting or requesting services. Symptom Cause / Action Sound like streaming water is heard • Sound of refrigerant liquid flowing inside unit during operation or after operation. • Sound of drainage water through drain pipe Noise Cracking noise is heard during operation Sound due to temperature changes of parts or when operation stops.
  • Page 10: Specifications

    Unit dimensions (H×W×D)* 290×950×950 290×950×950 353×950×950 353×950×950 353×950×950 Net weight* * Values include the dimension and weight of an optional ceiling panel. Ceiling (T2 type) Model Name S-60PT2R5A S-71PT2R5A S-100PT2R5A S-125PT2R5A S-140PT2R5A Power source 230/240 V~ 50 Hz 10.0 12.5 14.0 Cooling capacity...
  • Page 11: Outdoor Unit

    Outdoor unit Single Split Outdoor Unit Model Name U-60PE1R5A U-71PE1R5A U-100PE1R5A U-125PE1R5A U-140PE1R5A Power source 230/240 V~ 50 Hz 10.0 12.5 14.0 Cooling capacity 20,500 24,200 34,100 42,700 47,800 BTU/h 11.2 14.0 16.0 Heating capacity 23,900 27,300 38,200 47,800 54,600 BTU/h Sound pressure level (C/H) 48 / 50 48 / 50...
  • Page 12 Panasonic Corporation Website: http://panasonic.net/ © Panasonic Corporation 2014 F569618 Printed in China DC1213-0...
