Page 1
E-MANUAL Thank you for purchasing this Samsung product. To receive more complete service, please register your product at www.samsung.com/register Model Serial No.
Connecting a Mobile Device Using Smart Hub Using Smart View (Screen Mirroring) or contents sharing Connecting mobile devices without a wireless router (Wi-Fi Connecting to Samsung Smart Control Direct) Using Voice Interaction Connecting a mobile device via Smart View App...
Page 3
Signing in to a Samsung account Viewing recorded programmes Managing payment information saved on the TV Setting Up a Schedule Viewing Deleting a Samsung account from the TV Setting up a schedule viewing for a channel Using the GAMES Service Using Timeshift...
Page 4
Learning about the remote control (for the visually impaired) Selecting speakers Listening to the TV through Bluetooth devices (for the hearing Listening to the TV with a Samsung audio device impaired) Listening to the TV through Bluetooth devices Configuring advanced system settings...
Page 5
Troubleshooting Read Before Using Apps Read Before Using the Web Browser Getting Support Read Before Playing Photo, Video, or Music Files Getting support through Remote Management Limitations on use of photo, video, and music files Finding the contact information for service Supported external subtitles Requesting service Supported internal subtitles...
Using Smart Hub Connect Smart Hub for use. Connecting to the Internet Settings Network Open Network Settings Connect the TV to the Internet wired or wirelessly. Network Settings Network Type How do you connect to the Internet? Wireless Wired " The image may differ by the specific model and area.
Can connect Samsung Smart Control to your TV for control. When you turn on the TV for the first time, the Samsung Smart Control pairs to the TV automatically. If the Samsung Smart Control does not pair to the TV automatically, point it at the remote control sensor of the TV, then press the ①...
Running Voice Interaction Say a command while the button is pressed and release the button. The voice command is then identified. " If the command is not identified, try again with correct pronunciation. Editing Channels Learn quickly how to change channel numbers or delete channels. Running the Edit Channel function Live TV Channel List...
Connecting an Antenna (Aerial) Can connect the antenna cable to your TV. " An antenna connection is not necessary if you connect a cable box or satellite receiver. It is best to connect the both connectors using a Multi-Switch or DiSEqC. Switch, etc and to set Aerial Connection Type Dual...
Connecting to the Internet Can get access to the Internet through your TV. Connecting Internet network Settings Network Open Network Settings Try Now Connect to an available network. Establishing a wired Internet connection " Use Cat7 (*STP Type) cable for the connection. * Shielded Twist Pair "...
Establishing a wireless Internet connection Settings Network Open Network Settings Wireless Make sure that you have the wireless router's SSID (name) and password settings before attempting to connect. Network Settings Wireless Connection Select your wireless network. Refresh " The image may differ by the specific model and area. "...
Troubleshooting Internet Connectivity Issues If the Internet is not accessed, find solutions. Troubleshooting wired Internet connectivity issues Try Now After referencing the following content, troubleshoot the wired Internet connection issue. If the problem persists, contact your Internet Service Provider. No network cable found Make sure that the network cable is plugged in.
Troubleshooting wireless Internet connectivity issues After referencing the following content, troubleshoot the wireless Internet connection issue. If the problem persists, contact your Internet Service Provider. Wireless network connection failed If a selected wireless router is not found, go to Open Network Settings and select the correct router.
Connecting Video Devices Make proper video connection between your TV and the other external device. Connecting with an HDMI cable Connecting with a component cable (Only the models with COMPONENT IN / AV IN) Connect the component cable to the component input connections of the TV and the component output connectors of the device using component and AV adapters as shown in the image below.
Connecting with a composite cable (only the models with COMPONENT IN / AV IN port) Connect the video and audio cables to the provided adapters after referencing the following figure and then connect the adapters between the COMPONENT/AV IN port on your TV and the OUT port on an external device.
Connecting with a digital audio (optical) cable Connecting Bluetooth Devices You can connect the TV or audio devices via Bluetooth communication. For more information, refer to Connection Guide Source Connection Guide). Connecting a Computer Use the TV as a computer monitor or connect the TV to a computer via your network and access the computer's content.
Connecting a mobile device via Smart View App When you install Smart View App app from Google Play Store, Samsung Apps, and App Store, you can play the mobile device's multimedia content on the TV, or control the TV using the mobile device.
Note that this function may not be supported depending on the device. For smooth automatic setup of universal remote control, place the Samsung Smart Control so that it is close to and facing the TV. "...
Connection Notes! Read this section before connecting an external device to the TV. " The number of connectors and their names and locations may vary depending on the model. " Refer to the external device's operating manual when connecting it to the TV. The number of external device connectors and their names and locations may vary depending on the manufacturer.
Connection notes for audio devices For better audio quality, it is a good idea to use an AV receiver. ● Connecting a device using an optical cable does not automatically turn off the TV speakers. To turn ● off the TV's speakers, set Sound Output to something other than Speaker.
About the Samsung Smart Control This function may not be supported depending on the model or geographical region. This function is available for the remote control with a microphone.
Page 22
" The image, buttons and functions of the Samsung Smart Control may differ with the model. " Use the Samsung Smart Control at a distance of less than 6m. The usable distance may differ with the wireless environmental conditions.
Pair the TV with the Samsung Smart Control. When you turn on the TV for the first time, the Samsung Smart Control pairs to the TV automatically. If the Samsung Smart Control does not pair to the TV automatically, point it at the remote control sensor of the TV, then press the ①...
Connecting a Bluetooth keyboard and gamepad Settings System Input Device Manager Add Bluetooth Keyboard & Gamepad Try Now " If your keyboard was not detected, position the keyboard close to the TV, and then select Refresh. The TV scans for available devices again. Using the keyboard Button Remote control functions...
Entering Text using the On-Screen QWERTY Keypad Use the QWERTY keyboard to enter text on your TV. Using additional functions Select on the QWERTY keyboard screen. The following options are available: Recommend text ● Reset recommended text data ● Predict Next Character (when using direction buttons) ●...
Smart Hub services are for pay services. To use a for pay service, you must have an account with the service provider or a Samsung account. For more information, refer to "Using a Samsung account." " To use this feature, the TV must be connected to the Internet.
Displaying Home Screen In Home Screen, you can easily run the apps that have been used previously or frequently. The apps can also be moved or deleted in the screen. When you press the button on your remote control, you can use the following functions and features. Settings ●...
Removing an app in Home Screen To remove an app in Home Screen, move the focus to app you want to remove, press the down directional button, and then select Remove. Moving an app in Home Screen To move an app in Home Screen, move the focus to app you want to specify a new position, and press the down directional button, and then select Move.
To use a for paid service, you must have an account with the service provider or a Samsung account. " You can also create a Samsung account at http://content.samsung.com. Once you have an account, you can use the same ID on both the TV and the Samsung website. "...
Managing payment information saved on the TV Settings System Samsung Account Payment Info " To managing the payment information, you must be logged in to your Samsung account. Deleting a Samsung account from the TV Settings System Samsung Account Remove Account "...
Installing and running a game Installing games Move to the desired game to install and then press the Select button. The detailed information screen appears. Select Install If the installation is complete, you can directly run it. " You can see the installed games in My Games screen.
Removing a game Select My Games Options Delete. Select a game to delete. Select Delete. Then the selected game is deleted. " Through the pop-up menu, you can also delete games in Home Screen. Updating a game Select My Games Options Update Select a game to update.
Using the APPS Service Download and run various apps from Smart Hub. APPS APPS My Apps What's New Most Popular Video Life Plus Entertainment " The image may differ by the specific model and area. You can enjoy a wide range of content including news, sports, weather, and games by installing corresponding apps on your TV.
Launching an app You can run the selected app on My Apps screen. The icons below appear in the selected apps and indicate the following: : The app is installed on a USB device. ● : The app has a password. ●...
Removing an app Select My Apps Options Delete. Select an app to delete. Select Delete. Then the selected app is deleted. " Ensure that the related app data is also removed when you remove an app. Updating apps Select My Apps Options Update.
Support Open e-Manual You can view the embedded e-Manual containing information about your TV's key features. " Alternatively, you can download a copy of the e-Manual from Samsung's website. " Words in blue (e.g., Picture Mode) indicate a menu item.
"Read Before Playing Photo, Video, or Music Files." " Backup important files before connecting a USB device. Samsung is not responsible for damaged or lost files. " To connect the TV to a computer, refer to "Connecting a Computer."...
" The content may not be played smoothly due to the network communication problems. In this case, use a USB device. " When the device is connected to a USB port, a notification appears. If you select Browse, the media content list of the device appears.
Using Voice Interaction Access and run certain menu options and functions using voice commands. " This function may not be supported depending on the model or geographical region. This function is available for the remote control with a microphone. Settings System Expert Settings Voice Interaction...
Viewing Digital Broadcast Information at a Glance See overview of each digital channel's programme lineup. Using the guide Live TV Guide Try Now You can see the daily programme schedules for each broadcaster through the Guide, in which the programme information can be seen and you can watch or schedule recording. In the Guide, you can see only the TV programme schedule after the current time.
Changing the broadcast signal Live TV Channel List After pressing the right directional button on the your remote control, select Aerial to choose Terrestrial or Cable. " This function is not needed if your TV is connected to a cable or satellite box. Checking digital channel signal info and strength Settings Support...
Using the Instant and Schedule Recording options from programme info window Press the Select button while watching to display the programme info window. When you press and hold the Select button in the programme info window and then select Record, you can record the programme. Use the left or right directional button to select a broadcast scheduled programme.
Setting Up a Schedule Viewing Configure the TV to show a specific channel or programme at a specific time and date. appears next to programmes that have been configured for a schedule viewing. " To set up a schedule viewing, you must first set the TV's clock ( Settings System Time...
Using Timeshift Play, pause, or rewind live TV. You can pause and rewind live TV by using Timeshift. Activating this function disables the Broadcasting function. Try Now " To use Timeshift, the USB device must have been connected for recording. "...
If you press the right directional button on Channel List screen, you can use the following functions: ● Displays the channels that have been automatically searched. Favourites ● Displays favourites list 1 to 5. Category ● Sorts the list so that it includes channels of a selected genre only. However, Category can only be used channels contain the genre information.
Editing registered channels You can access the following options by selecting Edit: Lock Unlock channels ● Try Now " If you want to set the password, set Settings Broadcasting Channel Lock to On. Rename channels ● " This option is only available on analogue channels. Change Number ●...
Viewing and selecting channels on favourites lists only Live TV Channel List Press the right directional button on your remote control. Select Favourites. Select the desired list among five favourites lists on the screen. Then the channels in the selected favourites list appear.
Making Sports programmes More Realistic with Sports Mode Make sporting events appear and sound more realistic as if you are actually there. Settings Picture Special Viewing Mode Sports Mode Try Now You can use Sports Mode to get optimal picture and sound settings for sports events, making them appear and sound as if you are there.
Viewing a game recorded in sports mode You can view a recorded game on the MY CONTENT screen. " For more information about the functions, refer to "Buttons and functions available while using sports mode" and "Buttons and functions available while recording a programme or Timeshift." "...
Selecting the broadcast audio language Settings Broadcasting Expert Settings Audio Options Try Now This is the language you will hear while watching TV if the language is included in the broadcast signal. Audio Options functions differently for analogue and digital channels. Selecting a Language Settings Broadcasting...
Tuning digital channels Settings Broadcasting Expert Settings Manual Tuning Digital Channel Tuning Select Search to scan for digital channels automatically and store the scanned channel list in the Tuning analogue channels Settings Broadcasting Expert Settings Manual Tuning Analogue Channel Tuning Select and configure Programme, Colour...
Setting satellite system Settings Broadcasting Expert Settings Satellite System You can configure a set of satellite dish settings before performing a channel scan. " This function is only available on certain models in specific geographical areas. Changing teletext language Settings Broadcasting Expert Settings Teletext Language...
Adjusting the Picture Quality Change the Picture Mode and adjust Expert Settings. Choosing a picture mode Settings Picture Picture Mode Try Now You can select the picture mode that provides the best viewing experience. Dynamic ● Makes the picture brighter and clearer in bright viewing environments. Standard ●...
Page 54
Digital Clean View ● " This function is available for analogue channels only. Analogue Clean View ● " This function is available for analogue channels only. Auto Motion Plus ● " When LED Clear Motion is set to On, the screen appears darker than when it is Off. Smart LED ●...
Colour Tone ● Try Now " Cool Standard are only available when Picture Mode is set to Dynamic. " Colour Tone is only available when the TV is connected to a computer via an HDMI-to-DVI cable. White Balance ● Try Now Gamma ●...
Changing the picture size Settings Picture Picture Size Picture Size Try Now You can change the size of the picture displayed on the TV screen. 16:9 Standard ● Custom ● ● [ Do not watch TV in 4:3 mode for an extended period of time. This action may cause black bars to appear and rest for a while at the top, bottom, left, and right sides of the screen.
You can personalize the sound quaility, by adjusting the following settings. Balance ● Try Now Equaliser ● Try Now TV Installation Type ● Try Now Wireless Speaker Manager ● Try Now " For more information, refer to 'Listening to the TV with a Samsung audio device.'...
HDMI Audio Format ● Try Now Audio Format ● Try Now DTV Audio Level ● Try Now Audio Delay ● Try Now Auto Volume ● Try Now Sound Feedback ● Reset Sound ● Try Now " Standard audio signals are sampled at 48 kHz while HD audio signals are sampled at 96 kHz. "...
Wireless Speaker Manager Add TV SoundConnect Try Now You can connect Samsung audio device to the TV. They must be paired using the TV's Bluetooth function. For more information on pairing, refer to the Samsung audio device's operating manual. "...
Sound Expert Settings Wireless Speaker Manager Multiroom Link Settings You can connect a Samsung Multiroom Link compatible speaker to the TV to enjoy a richer sound. " This function is not available on certain models in specific geographical areas. "...
Setting the Time and Using the Timer Set the current time and use the timer function. Setting the current time Settings System Time Try Now You can set the Clock manually or automatically. Once the Clock is set, you can view the current time on the TV anytime.
● Switches the Daylight Saving Time (DST) function on or off. " This function is only available when the Clock Mode is set to Auto. ● Selects your time zone. " When Country (Area) is set to others, you can use this function. Using the timers Using the sleep timer Settings...
Using the Screen Burn Protection and Energy Saving Functions Protect the screen from screen burn-in and reduce the TV's energy consumption. Preventing screen burn Settings System Expert Settings Auto Protection Time Still images can leave burned-in after-images if left on the screen for a long period of time. Select a time setting from the list.
Connecting an external device through Anynet+ and using their menus Settings System Expert Settings Anynet+ (HDMI-CEC) Try Now Anynet+ (HDMI-CEC) to On. Connect an HDMI-CEC-compliant device to the TV. Turn on the connected external device. Then the device is automatically connected to the TV. After connection is finished, you can use the menus of the connected device by using your remote control.
Updating the TV’s Software View your TV’s software version and update it if necessary. Settings Support Software Update Try Now Updating the TV’s software to the latest version Settings Support Software Update Update now " This function requires an Internet connection. "...
Checking the TV and connected storage for malicious code Settings System Expert Settings Smart Security Scan If malicious code is found, the results of the scan will appear on the screen. This result window displays all malicious code found. You can quarantine (isolate) the code from executing. Select all the malicious code to quarantine.
Changing the volume, pitch, and speed of the voice guide You can configure the volume, pitch, speed, and level of the Voice Guide. Watching TV broadcasts with subtitles Settings System Accessibility Subtitle Try Now Subtitle to On. Then you can watch the programme with the caption displayed. "...
Audio Description Settings System Accessibility Audio Description Try Now You can use the Audio Stream for the Audio Description (AD) which is sent along with the Main audio from the broadcaster. Adjust the audio description volume using Volume. " This function is only available on digital channels. Audio Description ●...
Learning about the remote control (for the visually impaired) Settings System Accessibility Learn About your Remote Control Try Now This function helps individuals with a visual impairment to learn the positions of the buttons on the remote control. When this function is activated, press a button on the remote control and then the TV displays its name.
You can view the list of event messages generated by the TV. View Notifications appear on the screen when events such as an update release for an app or Samsung Account login/logout occurs. " To delete all notifications, select Delete All.
Registering the TV as a DivX-certified device (watching for pay DivX movies) Settings System Expert Settings DivX® Video On Demand Try Now " Digital Rights Management (DRM) functions as a technical security mechanism to protect the content provider's copyright. " You can watch recorded movies or free DivX movies without registration.
Some channels may not include the HbbTV service. In some countries, HbbTV is disabled by default. In this case, HbbTV can be used by installing the HbbTV widget (the HbbTV Activation Widget) from Samsung APPS. To set the HbbTV automatic start to on or off, access...
Using HbbTV: When the screen indicates (with the red colour button etc.) that HbbTV is being accessed. ● Select TTX using the remote once to enter the HbbTV text-input mode. ● Select TTX using the remote twice to enter the non-HbbTV text-input mode. ●...
Using the “CI or CI+ Card” To watch paid channels, the “CI or CI+ CARD” must be inserted. Samsung TV follow up CI+ 1.3 standard. When TV product display the "Scrambled Signal", it may ● happen due to CI+ 1.3 Version inconsistency. If you have a problem, please contact Samsung Call Centre.
Page 75
Teletext on / mix / off: Activates the Teletext mode for the current channel. Press twice to overlap the Teletext mode with the current broadcasting screen. Press it one more time to exit teletext. Store: Stores the Teletext pages. Size: Displays the teletext on the upper half of the screen in double-size. To move the text to the lower half of the screen, press it again.
Page 76
Part Contents Selected page number. Broadcasting channel identity. Current page number or search indications. Date and time. Text. Status information. FASTEXT information.
Try Now You can use this feature to let Samsung Electronics diagnose your TV remotely when you need assistance with your TV. Set it to On. You will need to read and agree to the service agreement before using this feature.
Contact Samsung Try Now You can view the address of the Samsung website, the call centre phone number, your TV's model number, your TV's software version, the Smart Hub info, and other information you may need to get service support from a Samsung call agent or the Samsung website.
Pb, Pr, and Y jacks are plugged into their proper connectors. If the colours on your Samsung TV are correct but just a little too dark or bright, try adjusting the following settings first.
Page 80
" If the test picture does not appear or there is noise or distortion, the TV may have a problem. Contact Samsung’s Call Centre for assistance. " If the test picture is displayed properly, there may be a problem with an external device. Please check the connections.
I Can't Hear the Sound Clearly When the TV has difficulties with sound, these steps may help resolve the problem. Testing the sound Settings Support Self Diagnosis Start Sound Test Try Now If the TV plays the Start Sound Test melody without distortion, there may be a problem with an external device or the broadcast signal's strength.
There Is a Problem with the Broadcast When the TV has difficulties receiving broadcasts, these steps may help resolve the problem. The problem Try this! Select Source to confirm that the correct input source has been selected. “Weak or No Signal” displayed in TV mode/ If the TV is not connected to a cable or satellite box, run Auto Tuning...
I Can't Connect to the Internet When the TV has difficulties connecting to the Internet, these steps may help resolve the problem. The problem Try this! The TV cannot connect Make sure the TV has a network connection ( Settings Network to your network or apps Network...
Data Service When the TV has difficulties using Data Service, these steps may help resolve the problem. The Problem Try this! Auto Run Data Service is set to On, messages will automatically appear on the Why am I getting on- screen when you watch a broadcast that supports the Data Service.
The Schedule Recording/Timeshift Function Isn't Working When Timeshift or Schedule Recording aren't working, these steps may help resolve the problem. The problem Try this! Check if there is a USB device connected to the TV. Schedule Recording cannot Recording will automatically stop if the signal becomes too weak. The Timeshift be used.
Page 86
The problem Try this! Check whether the device supports Anynet+. Check whether the HDMI cable is properly connected. Go to Anynet+ (HDMI-CEC) Settings System Expert Settings Anynet+ (HDMI-CEC)) and see if Anynet+ (HDMI-CEC) has been set to On. The connected device is not Scan for Anynet+ devices again.
Reset Resets all Smart Hub settings to their factory defaults and Settings deletes all information related to Samsung accounts, linked Reset Smart Hub Support Self Diagnosis service accounts, Smart Hub service agreements, and Smart Reset Smart Hub Hub applications.
Other Issues Use these procedures to resolve other issues which may occur. The problem Try this! Watching TV for an extended period of time causes the panel to generate heat. The heat from the panel is dissipated through internal vents running along the top of The TV is hot.
Page 89
The problem Try this! There are small particles This is part of the product’s design and is not a defect. on the TV's bezel. The PIP menu is not functionality is only available when you are viewing video from an HDMI or available.
Before Using the Recording and Timeshift Functions Read these instructions before using Recording and Timeshift. " This function is only available on certain models in specific geographical areas. Before using the recording and schedule recording functions To set up a Schedule Recording, you must first set the TV's clock. Set the Clock Settings ●...
If the Schedule Recording function is operating while a recording is being made on an HDMI-CEC ● external device, the priority is given to the Schedule Recording. Connecting a recording device to the TV automatically deletes abnormally saved recording files. ●...
Supported Resolutions for each of UHD Input Signals Check the supported resolution for UHD input signals. Resolution: 3840 x 2160p, 4096 x 2160p ● " The HDMI connector with HDMI UHD Color set to supports up to UHD 50P/60P 4:2:0 input signals, while the HDMI connector with HDMI UHD Color set to...
Read Before Using Apps Read this information before using Apps. Due to the product characteristics featured on the Samsung Smart Hub, as well as limitations in ● available content, certain features, applications, and services may not be available on all devices or in all territories.
For more information about applications, visit the applicable service provider's website. ● An unstable Internet connection may cause delays or interruptions. In addition, applications may ● terminate automatically depending on the network environment. If this occurs, check your Internet connection and try again. Application services and updates may become unavailable.
Page 95
E-commerce for online purchases is not supported. ● With websites that have scrollable windows, scrolling a window can result in corrupted characters. ● ActiveX is not supported. ● Certain options are not accessible in Link Browsing mode. (Switch to Pointer Browsing to activate ●...
Read Before Playing Photo, Video, or Music Files Read this information before playing media content. Limitations on use of photo, video, and music files Try Now The TV supports MSC (Mass Storage Class) USB devices only. MSC is a class designation for mass ●...
Other restrictions Codecs may not function properly if there is a problem with the content. ● Video content does not play or does not play correctly if there is an error in the content or container. ● Sound or video may not work if they have standard bit rates/frame rates above the TV’s compatibility ●...
Read After Installing the TV Read this information after installing the TV. Picture sizes and input signals Picture Size setting is applied to the current source. The applied Picture Size will remain in effect whenever you select that source unless you change it. Input signal Picture size Component...
– Encryption Types: WEP, TKIP, AES – In compliance with the newest Wi-Fi certification specifications, Samsung TVs do not support WEP ● or TKIP security encryption in networks running in the 802.11n mode. If the wireless router supports WPS (Wi-Fi Protected Setup), you can connect the TV to your network ●...
Read Before Connecting a Computer (Supported Resolutions) Check the supported resolution for PC input signals. When you connect your TV to a computer, set the computer's video card to one of the standard ● resolutions listed in the tables below or on the next page. The TV will automatically adjust to the resolution you choose.
Supported Resolutions for Video Signals Check the supported resolution for video signals. CEA-861 Horizontal Polarity Resolution Vertical frequency Clock frequency frequency Display format (horizontal / (Dots x lines) (Hz) (MHz) vertical) (KHz) 720(1440) x 576i 50 Hz 15.625 50.000 27.000 - / - 720(1440) x 480i 60 Hz...
Read Before Using Bluetooth Devices Read this information before using a Bluetooth device. Restrictions on using Bluetooth The Samsung Bluetooth Speaker is only available for devices supporting SoundConnect. ● You can't use Bluetooth devices, SoundConnect, and the Surround feature simultaneously.
Buttons and Functions Use convenience features or check available buttons and their descriptions for use while in playing media content. " The available buttons and functions may differ with content. Buttons and functions available while playing multimedia content Press the Select button while playing any video, photo or recorded content. Then the following buttons appear.
Page 108
Zoom ● Zooms the photo in by up to a factor of 4. Fit to screen ● Fits the photo to the screen. Background Music ● Play the background music while the TV displays photos with the background music. Options ●...
Buttons and functions available while using sports mode If you press the Select button, the following buttons appear. Zoom ● Pauses the current screen and zooms in any part of the screen by using 4 directional buttons. " This function is not available when MY CONTENT is active.
Page 110
Manual Highlight ● Saves a video from 10 seconds before you press the button to 10 seconds after. " You can set the TV to automatically save highlights without user intervention. Select Settings Picture Special Viewing Mode Sports Mode, and then set Auto Highlights to On.
Rovi Guide system. Open Source License Notice Open Source used in this product can be found on the following webpage. (http://opensource.samsung.com) Open Source License Notice is written only English.
