Safety and operating instructions
Handheld pneumatic breakers
Prescriptions de sécurité et instructions pour
l'opérateur
Brise-béton pneumatiques portatifs
Sicherheits- und Betriebsanleitung
Hand-Drucklufthämmer
Instrucciones de seguridad y de funcionamiento
Martillos neumáticos manuales
Instruções de segurança e operação
Demolidores pneumáticos manuais
Istruzioni per la sicurezza e per l'uso
Demolitori pneumatici manuali
Veiligheidsvoorschriften en bedieningshandleiding
Handbediende pneumatische sloophamers
Sikkerhedsinstruktioner og betjeningsvejledning
Håndholdte tryklufthamre
Säkerhetsinstruktion och instruktionsbok
Handhållna tryckluftsspett
Instrukcje bezpieczeństwa i obsługi
Ręczny mlot pneumatyczny
© 2012 Atlas Copco Construction Tools AB | No. 9800 0683 82f | 2012-08-07
Original instructions
140PS, 150PE, 180PS, 190PE, 220PS, 230PE, 270PS, 280PE
Advertisement
Table of Contents
Related Manuals for Atlas Copco 140PS
Summary of Contents for Atlas Copco 140PS
- Page 1 Demolitori pneumatici manuali Veiligheidsvoorschriften en bedieningshandleiding Handbediende pneumatische sloophamers Sikkerhedsinstruktioner og betjeningsvejledning Håndholdte tryklufthamre Säkerhetsinstruktion och instruktionsbok Handhållna tryckluftsspett Instrukcje bezpieczeństwa i obsługi Ręczny mlot pneumatyczny © 2012 Atlas Copco Construction Tools AB | No. 9800 0683 82f | 2012-08-07 Original instructions...
-
Page 2: Table Of Contents
Technical data..............20 © 2012 Atlas Copco Construction Tools AB | No. 9800 0683 82f | 2012-08-07... - Page 3 EC Declaration of Conformity (EC Directive 2006/42/EC)......22 © 2012 Atlas Copco Construction Tools AB | No. 9800 0683 82f | 2012-08-07...
-
Page 4: Introduction
Safety and operating instructions 270PS, 280PE Introduction Thank you for choosing a product from Atlas Copco. Since 1873, we have been committed to finding new and better ways of fulfilling our customers' needs. Through the years, we have developed innovative and ergonomic product designs that have helped customers improve and rationalize their daily work. -
Page 5: Safety Instructions
Proper protective boots and that it is not damaged or worn out. Appropriate work overall or similar clothing (not loose-fitting) that covers your arms and legs. © 2012 Atlas Copco Construction Tools AB | No. 9800 0683 82f | 2012-08-07... -
Page 6: Operation, Precautions
► environment. Never use the machine near flammable materials, ► fumes or dust. Make sure that there are no undetected sources ► of gas or explosives. © 2012 Atlas Copco Construction Tools AB | No. 9800 0683 82f | 2012-08-07... - Page 7 Make sure that no unauthorised persons trespass ► instructions into the working zone. Keep the workplace free from foreign objects. ► Ensure that the work piece is securely fixed. ► © 2012 Atlas Copco Construction Tools AB | No. 9800 0683 82f | 2012-08-07...
- Page 8 Before resuming the work, find and remove the cause of the increased vibrations. Never grab, hold or touch the inserted tool when ► using the machine. © 2012 Atlas Copco Construction Tools AB | No. 9800 0683 82f | 2012-08-07...
-
Page 9: Maintenance, Precautions
Keep the machine and tools in a safe place, out ♦ the machine from the power source. of the reach of children and locked up. © 2012 Atlas Copco Construction Tools AB | No. 9800 0683 82f | 2012-08-07... -
Page 10: Overview
If it takes less than 10 seconds a smaller breaker should be selected. If it takes more than 20 seconds a larger breaker should be selected. TEX 150PE, 190PE, 230PE, 280PE © 2012 Atlas Copco Construction Tools AB | No. 9800 0683 82f | 2012-08-07... -
Page 11: Labels
EC-approved. Water separator (optional) Lubricator (optional) Max. 3 m (10 ft) compressed air hose between the lubricator and the machine. © 2012 Atlas Copco Construction Tools AB | No. 9800 0683 82f | 2012-08-07... -
Page 12: Methods To Prevent Freezing
Wait until the insertion tool has cooled down before ► Breaker and hammer AIR-OIL or mineral oil with the carrying out maintenance work. properties recommended in the table below. © 2012 Atlas Copco Construction Tools AB | No. 9800 0683 82f | 2012-08-07... -
Page 13: Selecting The Right Insertion Tool
Learn how the machine is switched off in the event ► of an emergency. Stop the machine immediately in all cases of ► power supply interruption. © 2012 Atlas Copco Construction Tools AB | No. 9800 0683 82f | 2012-08-07... -
Page 14: Start And Stop
In the event of a longer break or when leaving the ♦ workplace: Switch off the power supply and then bleed the machine by activating the start and stop device. © 2012 Atlas Copco Construction Tools AB | No. 9800 0683 82f | 2012-08-07... -
Page 15: Maintenance
Check the threads in the machine lubricator and ♦ on the oil plug. Make sure they are not damaged or worn out. Handle Bearing Spring © 2012 Atlas Copco Construction Tools AB | No. 9800 0683 82f | 2012-08-07... -
Page 16: Periodic Maintenance
♦ hose are according to the recommendations. See “Installation”. If there is a risk of freezing, check that the ♦ machine's exhaust ports are not blocked. © 2012 Atlas Copco Construction Tools AB | No. 9800 0683 82f | 2012-08-07... -
Page 17: Technical Data
We, Atlas Copco Construction Tools AB, cannot be held liable for the consequences of using the declared values, instead of values reflecting the actual exposure, in an individual risk assessment in a work place situation over which we have no control. -
Page 18: Noise And Vibration Data
3.6–5.1 28 x 160/152 32 x 160/152 TEX 270PS 14.9 28 x 160/152 32 x 160/152 TEX 280PE 4.2–4.8 4.0–4.3 28 x 160/152 32 x 160/152 © 2012 Atlas Copco Construction Tools AB | No. 9800 0683 82f | 2012-08-07... -
Page 19: Ec Declaration Of Conformity
EC Declaration of Conformity EC Declaration of Conformity (EC Directive 2006/42/EC) We, Atlas Copco Construction Tools AB, hereby declare that the machines listed below conform to the provisions of EC Directive 2006/42/EC (Machinery Directive) and 2000/14/EC (Noise Directive), and the harmonised standards mentioned below.
