Page 1: Installation Manual
InstallatIon manual rec Peak energy For the installation of all REC Peak Energy 72 solar panels, certified according to UL 1703. -
Page 2: Table Of Contents
Be sure to follow the safety instructions for all system components. Ensure relevant local codes and regulations for health and safety and accident prevention are observed. REC Peak Energy 72 Installation Manual - UL 1703 Rev C.3 - 02.16... -
Page 3: Introduction
ReC soLAR Pte. LtD. and/or in the event of an intentional or grossly negligent breach of obligations by a legal representative or vicarious agent. -
Page 4: Electrical Installation
(1000 v for the ReC Peak energy 72 series and 1500 v for the ReC Peak energy 72 xv series). the maximum reverse current is 20 A and the maximum series fuse rating is 20 A. -
Page 5: Mechanical Installation
GuIDElInEs ReC Peak energy 72 panels have a type 2, Class C fire rating. the fire rating of this panel is only valid when mounted in the manner specified in these mechanical mounting instructions. utilize the following fire safety guidelines when installing ReC Peak energy 72 panels: •... -
Page 6: Ii) Clamp Specifications
InstallatIon ReC Peak energy 72 panels are typically installed on a rail-based mounting system. there are two different methods of installing an ReC Peak energy 72 panel, as decribed below (fig 1a & 1b), depending on the design of the array. the rails can run under the frame or parallel to the frame, directly under the indicated clamping zones. -
Page 7: Fig. 1 Panel Mounting Options 6 Fig. 6 Mounting Holes
Installation using mounting holes ReC Peak energy 72 panels have been evaluated by uL for mounting using the four elongated holes (18/32 in x 11/32 in (14 x 9 mm)) on 7/16 the underside of the panel frame at a distance of 10 in (270 mm) from the short side edge (fig. -
Page 8: Grounding
If you have any questions regarding a mounting system and its suitability for ReC Peak energy 72 panels, please contact your local office for technical support. -
Page 9: Connections And Connectors
• the cables on the ReC Peak energy 72 have a minimum bending radius of 1.2 in (30 mm) to avoid damage to the insulation (fig. 10) •... -
Page 10: Panel Information
At low irradiance of 200 w/m² (AM 1.5 and cell temperature 25°C) at least 95.5% of the stC panel efficiency will be achieved. * followed by the product designations 72 or 72 xv. REC Peak Energy 72 Installation Manual - UL 1703 Rev C.3 - 02.16... -
Page 11: Document History
(47” ), type 2 system fire Class rating, addition of Connections chapter 03.2015 updates required by addition of 1500 v ReC Peak energy 72 xv series 11.2015 updates to technical Information, general Data and Low light behaviour value 02.2016... - Page 12 REC SoLaR PtE. Ltd. 20 tUaS SoUth avENUE 14 SINgaPoRE 637312 SINgaPoRE tel: +65 6495 9228 Mail: post@recgroup.com www.recgroup.com...
