REC ALPHA PURE
PANELS
INSTALLATION MANUAL
• REC ALPHA PURE 2
• REC ALPHA PURE-R
• REC ALPHA PURE-RX
FOR ALL ALPHA PURE SOLAR PANELS CERTIFIED ACCORDING TO IEC 61215 & IEC 61730 STANDARDS

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ALPHA PURE-R and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for REC ALPHA PURE-R

  • Page 1 REC ALPHA PURE PANELS INSTALLATION MANUAL • REC ALPHA PURE 2 • REC ALPHA PURE-R • REC ALPHA PURE-RX FOR ALL ALPHA PURE SOLAR PANELS CERTIFIED ACCORDING TO IEC 61215 & IEC 61730 STANDARDS...
  • Page 2: Table Of Contents

    1-13 SYSTEM INSPECTION 1-13 RECYCLING 1-13 DISPOSAL OF OLD ELECTRICAL AND ELECTRONIC EQUIPMENT 1-13 SPECIAL INSTALLATIONS 1-14 WATER PLATFORMS 1-14 MODULE LEVEL POWER ELECTRONICS 1-15 REC Alpha Pure PANELS INSTALLATION MANUAL - IEC61215:2021/IEC61730:2023 REF: PM-IM-23-06 REV: 15 IEC EN 1.2025...
  • Page 3 INSTALLATION OF REC ALPHA PURE 2 SERIES PANELS MOUNTING REC ALPHA PURE 2 SERIES PANELS WITH CONTINUOUS RAILS PARALLEL TO LONG SIDE OF THE PANEL MOUNTING REC ALPHA PURE 2 SERIES PANELS WITH CONTINUOUS RAILS PARALLEL TO SHORT SIDE OF THE PANEL...
  • Page 4: Introduction

    SUPPORT Do not attempt to install REC solar panels if you are unsure of the procedure or suitability. For further support, questions or guidance with your installation, please call your distributor or contact your REC sales office, which can be found at: www.recgroup.com/contacts.
  • Page 5: Safety Measures

    SAFETY IN THE WORKING AREA Installation of REC solar panels may involve working on rooftops or raised platforms. Ensure all local regulations regarding working at heights and fall protection are followed. Before beginning work on an installation, ensure all working surfaces are structurally sound and capable of bearing the weight of employees and required equipment.
  • Page 6: Panel Handling

    PANEL HANDLING In order to avoid damage, all REC solar panels should be handled with care and protected from damage at all times. All warnings and instruc- tions on the packaging should be observed. Follow these guidelines when unpacking, transporting, carrying, installing or storing panels: •...
  • Page 7: Electrical Installation

    APPLICATION CLASS REC solar panels are rated for use in electrical Application Class A, Protection Safety Class II; at hazardous levels of voltage (>35V), cur- rent(>8A) and power (>240W) where general contact access is anticipated (panels qualified for safety through IEC 61730:2023).
  • Page 8: Mechanical Installation

    MECHANICAL INSTALLATION FIRE GUIDELINES The REC solar panels covered by this manual have a Class C (referencing UL 790) fire classification. Alpha Pure Family panels are rated type 2 fire classification according to IEC61730-2:2023 (ref. ANSI/UL 61730-2); • Check with all relevant local authorities for fire safety requirements for any building or structure on to which the panels will be installed, •...
  • Page 9: Panel Installation

    REC modules must be secured with a torque as shown in the table below (fig. 1-1). Clamp installation must be carried out according to the manufacturer’s instructions, including specific hardware and torque requirements. Ensure the clamps used are suitable for the planned installation and expected system design loads.
  • Page 10: Mounting Methods: Slide In Systems

    For any questions regarding installation on such systems, please contact REC directly. MOUNTING METHODS: MOUNTING HOLES The REC solar panels covered by this manual can be installed utilizing the mounting holes (11 mm x 6.6 mm (0.43 in x 0.26in)) on the underside of the panel (fig. 1-3).
  • Page 11: Grounding

    Local regulations may require grounding of the panels. Installers are responsible for ensuring compliance with relevant local regulations. Grounding must be done using an electrical connection from the panel frame. REC solar panels have a small round grounding hole posi- tioned near each corner of the panel on both the long side and the short side, (fig.
  • Page 12: Cable Management

    • To enable correct cooling and drying of the connectors, do not add extra protection to the connector, e.g., heat shrink, grease or tape. More detailed information is given in the Guide to Best Practice - Connections and Connectors which can be found via the REC online Down- load Center (www.recgroup.com/downloads) Fig.
  • Page 13: Panel Maintenance

    For installations in the European Union, REC solar panels are subject to WEEE regulations. The symbol in fig. 1-7 as found on the label on the rear of the panel indicates that this product must not be treated as household waste and must be disposed of at an appropriate collection point for the recycling of electrical and electronic equipment.
  • Page 14: Special Installations

    The REC solar panels covered by this manual may be installed on water platform-type mounting systems (note that the certification test- ing of solar panels does not include testing on these types of systems). When installing REC solar panels on fixed position (e.g., anchored) water platforms, for example, floating pontoons, follow the instructions below specific to such applications.
  • Page 15: Module Level Power Electronics

    ‘retro-fit’ system made by third-party manufacturers. MLPE devices may be used on REC solar panels where desirable or mandatory (note that the certification testing of solar panels does not include testing with MLPE devices). When installing an MLPE device directly onto the frame structure of an REC solar panel, follow the instructions provided by the device manufacturer and the instructions specific for REC solar panels given below.
  • Page 16: Installation Of Rec Alpha Pure 2 Series Panels

    INSTALLATION OF REC ALPHA PURE 2 SERIES PANELS REC Alpha Pure PANELS INSTALLATION MANUAL - IEC61215:2021/IEC61730:2023 REF: PM-IM-23-06 REV: 15 IEC EN 1.2025...
  • Page 17 INSTALLATION OF REC ALPHA PURE 2 SERIES PANELS MOUNTING REC ALPHA PURE 2 SERIES PANELS WITH CONTINUOUS RAILS PARALLEL TO SHORT SIDE OF THE PANEL A continuous rail (or other support structure) spans the complete underside of the panel Fig. 2-1...
  • Page 18: Mounting Rec Alpha Pure 2 Series Panels With Continuous Rails Parallel To Long Side Of The Panel

    MOUNTING REC ALPHA PURE 2 SERIES PANELS WITH CONTINUOUS RAILS PARALLEL TO LONG SIDE OF THE PANEL A continuous rail (or other support structure) spans the complete underside of the panel Fig. 2-1 Fig. 2-2 Clamping of REC Alpha Pure 2 panels with Rails parallel to the Long Side of the Panel...
  • Page 19: Mounting Rec Alpha Pure 2 Panels With Short Rails

    A short rail (or other short support structure) has a minimum length of 25 mm and does not span the complete underside of a panel. Fig. 2-2 Fig. 2-3 Clamping of REC Alpha Pure 2 panels using short rails 20 - 40 mm 40 - 60 mm >60 mm...
  • Page 20: Six Point Mounting: Rec Alpha Pure 2

    A six-point mounting configuration secures the panel on three continuous rails (or other support structures) with three clamps on each side of the panel in the zones marked below: Fig. 2-3 Fig. 2-4 Six-point mounting configuration clamping zones: REC Alpha Pure 2 20 - 40 mm 40 - 60 mm >60 mm...
  • Page 21: Mixed Six-Point Mounting For Short Rails: Rec Alpha Pure 2

    A mixed six-point mounting configuration secures the panel on three short rails (or other support structures) with three clamps on each side of the panel in the zones marked below: Fig. 2-4 Fig. 2-5 Mixed Six-Point Mounting of REC Alpha Pure 2 Series Panels using short rails 20 - 40 mm 40 - 60 mm >60 mm...
  • Page 22: Installation Of Rec Alpha Pure-Rseries Panels

    INSTALLATION OF REC ALPHA PURE-R SERIES PANELS REC Alpha Pure PANELS INSTALLATION MANUAL - IEC61215:2021/IEC61730:2023 REF: PM-IM-23-06 REV: 15 IEC EN 1.2025...
  • Page 23 INSTALLATION OF REC ALPHA PURE-R SERIES PANELS MOUNTING REC ALPHA PURE-R SERIES PANELS WITH CONTINUOUS RAILS PARALLEL TO SHORT SIDE OF THE PANEL A continuous rail (or other support structure) spans the complete underside of the panel Fig. 2-5 Fig. 3-1...
  • Page 24: Mounting Rec Alpha Pure-R Series Panels With Continuous Rails Parallel To Long Side Of The Panel

    MOUNTING REC ALPHA PURE-R SERIES PANELS WITH CONTINUOUS RAILS PARALLEL TO LONG SIDE OF THE PANEL A continuous rail (or other support structure) spans the complete underside of the panel Fig. 3-2 Clamping of REC Alpha Pure-R panels with Rails parallel to the Long Side of the Panel...
  • Page 25: Mounting Rec Alpha Pure-R Panels With Short Rails

    A short rail (or other short support structure) has a minimum length of 25 mm and does not span the complete underside of a panel. Fig. 3-3 Clamping of REC Alpha Pure-R panels using short rails 20 - 40 mm 40 - 60 mm >60 mm...
  • Page 26: Six Point Mounting: Rec Alpha Pure-R

    A six-point mounting configuration secures the panel on three continuous rails (or other support structures) with three clamps on each side of the panel in the zones marked below: Fig. 3-1 Fig. 3-4 Six-point mounting configuration clamping zones: REC Alpha Pure-R 32.3 - 35.8 in 15.7 - 3.9 in 3.9 - 15.7 in...
  • Page 27: Installation Of Rec Alpha Pure-Rx Series Panels

    INSTALLATION OF REC ALPHA PURE-RX SERIES PANELS REC Alpha Pure PANELS INSTALLATION MANUAL - IEC61215:2021/IEC61730:2023 REF: PM-IM-23-06 REV: 15 IEC EN 1.2025...
  • Page 28 INSTALLATION OF REC ALPHA PURE-RX SERIES PANELS MOUNTING REC ALPHA PURE-RX SERIES PANELS WITH CONTINUOUS RAILS PARALLEL TO SHORT SIDE OF THE PANEL A continuous rail (or other support structure) spans the complete underside of the panel Fig. 4-1 Clamping of REC Alpha Pure-RX panels with Rails parallel to the Short Side of the Panel...
  • Page 29: Mounting Rec Alpha Pure-Rx Series Panels With Continuous Rails Parallel To Long Side Of The Panel

    MOUNTING REC ALPHA PURE-RX SERIES PANELS WITH CONTINUOUS RAILS PARALLEL TO LONG SIDE OF THE PANEL A continuous rail (or other support structure) spans the complete underside of the panel Fig. 4-2 Clamping of REC Alpha Pure-RX panels with Rails parallel to the Long Side of the Panel...
  • Page 30: Mounting Rec Alpha Pure-Rx Panels With Short Rails

    A short rail (or other short support structure) has a minimum length of 25 mm and does not span the complete underside of a panel. Fig. 3-2 Fig. 4-3 Clamping of REC Alpha Pure-RX panels using short rails 20 - 40 mm 40 - 60 mm >60 mm...
  • Page 31: Six Point Mounting: Rec Alpha Pure-Rx

    A six-point mounting configuration secures the panel on three continuous rails (or other support structures) with three clamps on each side of the panel in the zones marked below: Fig. 3-3 Fig. 4-4 Six-point mounting configuration clamping zones: REC Alpha Pure-RX 3.9 - 15.7 in 32.3 - 35.8 in 15.7 - 3.9 in...
  • Page 32: Mixed Six-Point Mounting For Short Rails: Rec Alpha Pure-Rx

    A mixed six-point mounting configuration secures the panel on three short rails (or other support structures) with three clamps on each side of the panel in the zones marked below: Fig. 3-4 Fig. 4-5 Mixed Six-Point Mounting of REC Alpha Pure-RX Series Panels using short rails 33.1 in. - 35.0 in. 840 mm - 890 mm 20 - 40 mm 40 - 60 mm >60 mm...
