- Page 1 REC Alpha Pro PANELS INSTALLATION MANUAL • REC ALPHA PRO M • REC ALPHA PRO MG FOR REC ALPHA PRO SOLAR PANELS CERTIFIED ACCORDING TO IEC 61215 & UL 61730 STANDARDS:...
- Page 2 WATER PLATFORMS 1-14 MODULE LEVEL POWER ELECTRONICS 1-15 REC Installation Manual - Module REC Alpha Pro - IEC61215/UL61730 REC Installation Manual - Module REC Alpha Pro - IEC61215/UL61730 REC Installation Manual - Module REC Alpha Pro - IEC61215/UL61730 Ref: PM-IM-23 Rev: 8.2024 US...
- Page 3 INSTALLATION OF REC ALPHA PRO M SERIES PANELS MOUNTING REC ALPHA PRO M SERIES PANELS WITH CONTINUOUS RAILS PARALLEL TO SHORT SIDE OF THE PANEL MOUNTING REC ALPHA PRO M SERIES PANELS WITH CONTINUOUS RAILS PARALLEL TO LONG SIDE OF THE PANEL...
- Page 4 SUPPORT Do not attempt to install REC solar panels if you are unsure of the procedure or suitability. For further support, questions or guidance with your installation, please call your distributor or contact your REC sales office, which can be found at: www.recgroup.com/contacts. ...
- Page 5 SAFETY IN THE WORKING AREA Installation of REC solar panels may involve working on rooftops or raised platforms. Ensure all local regulations regarding working at heights and fall protection are followed. Before beginning work on an installation, ensure all working surfaces are structurally sound and capable of bearing the weight of employees and required equipment. ...
- Page 6 PANEL HANDLING In order to avoid damage, all REC solar panels should be handled with care and protected from damage at all times. All warnings and instruc- tions on the packaging should be observed. Follow these guidelines when unpacking, transporting, carrying, installing or storing panels: •...
- Page 7 APPLICATION CLASS REC solar panels are rated for use in Electrical Application Class A, Protection Safety Class II; at hazardous levels of voltage (>35V), cur- rent(>8A) and power (>240W) where general contact access is anticipated (panels qualified for safety through UL 61730-1 and -2).
- Page 8 FIRE GUIDELINES The REC solar panels covered by this manual have a Class C (referencing UL 790) fire classification. REC Alpha Pro panels are rated type 1 or 29 fire classification according to IEC 61730-2:2016 (ref. ANSI/UL 1703). The fire performance rating of the panels is only valid when mounted in the manner specified in this installation manual.
- Page 9 REC modules must be secured with a torque as shown in the table below (Fig. 1). Clamp installation must be carried out according to the manufacturer’s instructions, including specific hardware and torque requirements. Ensure the clamps used are suitable for the planned installation and expected system design loads. ...
- Page 10 MOUNTING METHODS: MOUNTING HOLES The REC solar panels covered by this manual can be installed utilizing the mounting holes (14 x 9 mm) on the underside of the panel (Fig. 3). Installation must be performed in conjunction with a device, e.g., screws or lockbolts, with specifications suitable for the installation (Fig. 4).
- Page 11 CONNECTIONS AND CONNECTORS The connectors used on REC panels are indicated in the Panel Characteristics at the rear of this manual. The connector IP rating is only valid when correctly connected. All connectors and cables must be secure and tight as well as electrically and mechanically sound. UV-resistant cables and connectors approved for outdoor use must be used.
- Page 12 • To enable correct cooling and drying of the connectors, do not add extra protection to the connector, e.g., heat shrink, grease or tape. More detailed information is given in the Guide to Best Practice - Connections and Connectors which can be found via the REC online Down- load Center (www.recgroup.com/downloads) Fig.
- Page 13 DISPOSAL OF OLD ELECTRICAL AND ELECTRONIC EQUIPMENT Panels should be recycled at the end of their useful life according to local guidelines and regulations. By ensuring REC solar panels are dis- posed of correctly, you will help prevent any negative impact on the environment and human health. The majority of the panel components can be recycled.
- Page 14 The REC solar panels covered by this manual may be installed on water platform-type mounting systems (note that the certification test- ing of solar panels does not include testing on these types of systems). When installing REC solar panels on fixed position (e.g., anchored) water platforms, for example, floating pontoons, follow the instructions below specific to such applications.
- Page 15 ‘retro-fit’ system made by third-party manufacturers. MLPE devices may be used on REC solar panels where desirable or mandatory (note that the certification testing of solar panels does not include testing with MLPE devices). When installing an MLPE device directly onto the frame structure of an REC solar panel, follow the instructions provided by the device manufacturer and the instructions specific for REC solar panels given below.
- Page 16 INSTALLATION OF REC ALPHA PRO M SERIES PANELS REC Installation Manual - Module REC Alpha Pro - IEC61215/UL61730 REC Installation Manual - Module REC Alpha Pro - IEC61215/UL61730 REC Installation Manual - Module REC Alpha Pro - IEC61215/UL61730 Ref: PM-IM-23 Rev: 8.2024 US...
- Page 17 Once a module is secured in each of the 4 zones , additional clamps, i.e., ≥5, may be freely located on panel frame without affecting the warranty. Loads marked with a * were not certified as part of IEC 61215/61730 testing; these have been evaluated by REC’s internal testing process.
- Page 18 Once a module is secured in each of the 4 zones , additional clamps, i.e., ≥5, may be freely located on panel frame without affecting the warranty. Loads marked with a * were not certified as part of IEC 61215/61730 testing; these have been evaluated by REC’s internal testing process.
- Page 19 INSTALLATION OF REC ALPHA PRO MG SERIES PANELS REC Installation Manual - Module REC Alpha Pro - IEC61215/UL61730 REC Installation Manual - Module REC Alpha Pro - IEC61215/UL61730 REC Installation Manual - Module REC Alpha Pro - IEC61215/UL61730 Ref: PM-IM-23 Rev: 8.2024 US...
- Page 20 Once a module is secured in each of the 4 zones , additional clamps, i.e., ≥5, may be freely located on panel frame without affecting the warranty. Loads marked with a * were not certified as part of IEC 61215/61730 testing; these have been evaluated by REC’s internal testing process.
- Page 21 Once a module is secured in each of the 4 zones , additional clamps, i.e., ≥5, may be freely located on panel frame without affecting the warranty. Loads marked with a * were not certified as part of IEC 61215/61730 testing; these have been evaluated by REC’s internal testing process.
- Page 22 REC SOLAR PTE. LTD. 20 TUAS SOUTH AVENUE 14 SINGAPORE 637312 SINGAPORE Tel: +65 6495 9228 Mail: post@recgroup.com www.recgroup.com...
