Page 1: Installation Manual
InstallatIon manual rec Peak energy series For the installation of panels certified according to UL 1703... -
Page 2: Table Of Contents
Be sure to follow the safety instructions for all system components. Ensure relevant local codes and regulations for health and safety and accident prevention are observed. REC Peak Energy Series Installation Manual - UL 1703 Ref: NE-06-03-M... -
Page 3: Introduction
This does not apply to damages due to a panel fault, in cases of loss of life, bodily injury or damage to health or in the event of a grossly negligent breach of obligations on the part of reC solar PTe. lTD. and/or in the event of an intentional or grossly negligent breach of obligations by a legal representative or vicarious agent. -
Page 4: Electrical Installation
ReQuIRements system Requirements reC Peak energy panels are only for use where they meet the specific technical requirements of the complete system. ensure other components do not cause mechanical or electrical damage to the panels. Connection if panels are connected in series, they should have the same amp rating. if panels are connected in parallel, they should have the same voltage rating. -
Page 5: Mechanical Installation
GuIDelInes reC Peak energy panels have a Class C, Type 2 fire classification. The fire rating of this panel is only valid when mounted in the manner specified in these mechanical mounting instructions. utilize the following fire safety guidelines when installing reC Peak energy panels: •... -
Page 6: Mounting The Panels
Peak energy panels are designed for capturing solar radiation and are not suitable for installation as overhead or vertical glazing. The panels are considered to be in compliance with ul 1703, only when the panel is mounted specified by the mounting instructions below. The reC junction box on the back of the panel is protected to iP67 and hence panels can be mounted in any orientation. -
Page 7: Iv) Slide-In Systems
Peak energy panels have not been certified by ul for use with slide-in type mounting systems. if you have any questions regarding a mounting system and its suitability for reC Peak energy panels, please contact your local office for technical support. -
Page 8: Vi) Long Side Mounting Using Clamps
Mounting of reC Peak energy panels utilizing clamps on the two long sides of the panel have been found to be in compliance with ul 1703 require- ments for a maximum design load of 75.2 lbs/ft² (3600 Pa) (fig. 8). -
Page 9: Connections And Connectors
ReCyClInG reC has made every effort to ensure panel packaging is kept to a minimum. The paper and cardboard packaging can be recycled and the protective wrapping and panel separating blocks are also recyclable in many areas. Please recycle according to local guidelines and regulations. -
Page 10: Annex 1.Installations On Water Platforms
InstallatIon enVIRonment Installation site • reC panels may only be installed on closed bodies of fresh water where water salinity does not exceed 15 Psu at 77°f (25 ms/cm at 25°C). This specifically excludes mounting on sea and ocean applications. •... -
Page 11: Panel Information
(in) MEChANICAL DATA GENERAL DATA Dimensions: 65.55 x 39.02 x 1.5 in Cell Type: 60 reC Pe multi-crystalline 6 x 6 in (156 x 156 mm) area: 17.76 ft² 3 sub-strings of 20 cells with bypass diodes weight: 39.6 lbs glass: 1/8"... -
Page 12: Document History
DoCuMeNT HisTorY Date Revision number Reason 01.2010 first release 02.2010 Textual updates 02.2010 Textual updates 03.2010 Textual updates 05.2010 Textual updates 07.2010 Textual updates 03.2011 Textual updates, update of electrical data 10.2012 release of separate ieC 61215/61730 and ul1703 specific installation manual version. 01.2013 Textual update of technical characteristics 01.2013... - Page 13 REC SoLaR PtE. Ltd. 20 tuas South avenue 14 Singapore 637312 Singapore tel: +65 6495 9228 Mail: post@recgroup.com www.recgroup.com...
