Summary of Contents for Gram DSI 6411-60
- Page 1 Dishwasher Instruction Manual Instruction Manual Instruction Instruction Manual Manual...
-
Page 2: Table Of Contents
ENGLISH CONTENTS • Technical specifications ......... 3 •... - Page 3 Upper basket with racks Upper spray arm Lower basket Lower spray arm Filters Rating plate Control Panel Detergent and rinse-aid dispenser Cutlery basket Salt dispenser Upper basket track latch Active drying unit: This system provides better drying performance for your dishes.
-
Page 4: Technical Specifications
Technical specifications Capacity 12 place settings Height 820 mm - 870mm Width 596 mm Depth 550 mm Net Weight 41 kg Electricity input 220-240 V, 50 Hz Total Power 2200 W Heating Power 2000 W Pump Power 100 W Drain Pump Power 30 W Water supply pressure 0.03 MPa -1 MPa... -
Page 5: Safety Nformat On And Recommendat Ons
SAFETY INFORMATION AND RECOMMENDATIONS Recycling • Certain components and the packaging of your machine have been produced from recyclable materials. • Plastic parts are marked with international abbreviations: (>PE< , >PS< , >POM<, >PP<, ) • Cardboard parts have been produced from recycled paper and they should be disposed of into waste paper collection containers for recycling. - Page 6 • Check whether the indoor electrical fuse system is connected according to the regulations. • All electrical connections must match the values indicated on the rating plate. • Pay special attention and be sure that the machine does not stand on the electricity supply cable. •...
- Page 7 mental capabilities or lack of experience and knowledge if they have been given supervision or instruction concerning use of the appliance in a safe way and understand the hazards involved. Children shall not play with the appliance.Cleaning and user maintenance shall not be made by children without supervision.
-
Page 8: Recommendations
For your children’s safety • After removing the machine’s packaging, make sure that the packaging material is out of reach of children. • Do not allow children to play with or start the machine. • Keep your children away from detergents and rinse aids. •... -
Page 9: Items Not Suitable For Dishwashing
Items not suitable for dishwashing: • Cigarette ashes, candle leftovers, polish, paint, chemical substances, iron-alloy materials; • Forks, spoons and knives with wooden or bone, or ivory or nacre-coated handles; glued items,items soiled with abrasive, acidic or base chemicals. • Plastic items that are not heat-resistant, copper or tin-coated containers. -
Page 10: Water Connections
Position the machine close to a water tap or drain. You need to site your machine, taking into consideration that its connections will not be altered once they are made. Do not grip the machine by its door or panel in order to move Take care to leave a certain clearance from all sides of the machine so that you can comfortably move it back and forth during cleaning. -
Page 11: Water Inlet Hose
Water inlet hose Do not use the water inlet hose of your old machine,if any. Use the new water inlet hose supplied with your machine instead. If you are going to connect a new or long - unused water inlet hose to your machine ,run water through it for a while before making the connection. -
Page 12: Water Outlet Hose
Water outlet hose The water drain hose can be connected either directly to the water drain hole or to the sink outlet spigot. Using a special bent pipe (if available), the water can be drained directly into the sink via hooking the bent pipe over the edge of the sink. -
Page 13: Electrical Connection
Electrical connection The earthed plug of your machine should be connected to an earthed outlet supplied by suitable voltage and current. If there is no earthing installation, have a competent electrician carry out an earthing installation. In case of usage without earthing installed, our company will not be responsible for any loss of usage that might occur. -
Page 14: Prior To Using The Machine
ENGLISH Pr or to us ng the mach ne for the f rst t me • Check whether the electricity and supply water specifications match the values indicated by the installation instructions for the machine. • Remove all packaging materials inside the machine. •... -
Page 15: Testing Strip
Position the machine close to a water tap or drain. You need to site your machine, taking into consideration that its connections will not be altered once they are made. Do not grip the machine by its door or panel in order to move Take care to leave a certain clearance from all sides of the machine so that you can comfortably move it back and forth during cleaning. - Page 16 ENGLISH Adjust the water softener according to how hard your tap water is. Press the program selector button and keep it pressed down. (3) Meanwhile, energise the machine by pressing the Power On/Off button. (1) Keep Start/Pause keys press until the leds “P1-P2-P3-P4-P5-end of program indicator”...
-
Page 17: Detergent Usage
ENGLISH Detergent usage Use a detergent specifically designed for use in domestic dishwashers. You can find powder,gel,and tablet detergents in the market that have been designed for household dishwashers. Detergent should be put into the compartment prior to starting the machine. Keep your detergents in cool, dry places out of reach of your children. -
Page 18: Filling With Rinse Aid And Making The Setting
ENGLISH • When the conditions of use of such products and the machine settings are appropriate, they ensure savings in salt and/or rinse aid consumption. • Contact the detergent manufacturers if you are not obtaining good wash results (if your dishes stay calcareous and wet) after having used 2 in 1 or 3 in 1 detergents. -
Page 19: Load Ng Your D Shwasher
LOADING YOUR DISHWASHER If you properly place your dishes into the machine, you will be using it in the best way in terms of energy consumption, washing and drying performance. There are two separate baskets for you to load your dishes into your machine. You can load into the lower basket such round and deep items as pots with long handles, pot lids, plates, salad plates, cutlery sets. -
Page 20: Lower Basket
Top basket height adjustment Top basket of your machine is in upper position. When it is in this position, you can place big items such as pans, etc. on lower basket. When you take top basket to lower position, you can place and wash big sized plates on the top basket. - Page 21 Multi-functional Rack System Multi-functional rack system is located in the bottom basket of your machine. You can easily wash spare glasses or dishes like long ladles, bread knife with the help of this accesory. Please fold the racks by putting them from position to position, in order to put the racks in the multi-functional rack system into the...
-
Page 22: Alternative Basket Loads
Alternative basket loads Lower Basket Top basket... - Page 23 Faulty loads Important Note for Test Laboratories For detailed information on performance tests, please contact following address: "dishwasher@standardtest.info” . In your email, please provide the model name and serial number (20 digits) which you can find on the appliance door.
-
Page 24: Programme Items
ENGLISH PROGRAMME DESCRIPTION Programme items Reference Programme No Intensive 70°C Super 65 Prewash Programme Eco 50 ° Quick 40 ° °C No Heat ( 5) names and temp. ( 3) ( 4) ( 2) Pre-wash to rinse coffee, milk, tea, coffe, milk, tea, Type of food soups, sauces,... -
Page 25: Gett Ng Fam L Ar W Th Your Mach Ne
GETTING FAMILIAR WITH YOUR MACHINE 1.) Power On/Off Button When the Power On/Off button is pressed, end of program indicator starts lighting 2.) Programme selection button With the programme select ion button, you can select a suitable program for your dishes. -
Page 26: Sw Tch Ng On The Mach Ne And Select Ng A Programme
ENGLISH SWITCHING ON THE MACHINE AND SELECTING A PROGRAMME When you select a program with the program Switching on the machine selection button, the light of the selected program turns on and the end of program indicator turns off. Once the power on/off key is pressed, the end of program indicator turns on. -
Page 27: Changing A Programme With Resetting
ENGLISH Changing a programme with resetting If you would like to cancel a program while a washing program is resumed Open the door of your machine. Light of the last selected program will turn on. Discharge process starts after closing the door of the machine.The machine discharges the water in it for about 30 Keep the program selection button... -
Page 28: Ma Ntenance And Clean Ng
ENGLISH MAINTENANCE AND CLEANING Cleaning the machine in regular intervals prolongs the machine's service life. Oil and lime may accumulate in the machine's washing section. In case of such accumulation; -Fill the detergent compartment without loading any dishes into the machine, select a programme that runs at high temperature, and start the machine. -
Page 29: Spray Arms
Spray arms Check whether or not the holes for the upper and lower spray arms are clogged. If there is any clogging, remove the spray arms and clean them under water. You can remove the lower spray arm by pulling it upwards, while the upper spray arm nut can be removed by turning the nut to the left. - Page 31 ENGLISH If the programme won't start • Check if the plug is connected. • Check your indoor fuses. • Be sure that the water inlet tap is turned on. • Be sure that you have closed the machine door. • Be sure that you switched off the machine by pressing the Power On / Off button. •...
-
Page 32: Pract Cal And Useful Nformat On
ENGLISH Door s not opened / closed properly; • Not proper weight wooden part inserted on the door. ( Follow the weight given in the Assembly manuel ) • The tensile of the door spring not adjusted properly. Adjust it according to the Assembly manuel Call an author sed serv ce f the problem st ll pers sts after the controls or n case of any malfunct on not descr bed above. - Page 33 Tel.: 22 07 26 30 Tel.: 040 38 08 40 Tel.: 020 7756 350 www.gram.no www.gram.se www.gram.fi Gram A/S . Gejlhavegård 2B . DK-6000 Kolding . +45 73 20 10 00 . www.gram.dk 52158178 R20 ...
