  • Page 1 Dishwasher / User Manual DS 4110...
  • Page 2 Thank you for choosing this product. This user manual contains important information on safety and instructions intended to assist you in the operation and maintenance of your appliance. Please take the time to read this user manual before using your appliance and keep this book for future reference.

  • Page 3: Table Of Contents

    CONTENTS 1 SAFETY INSTRUCTIONS ................4 1.1 General Safety Warnings ....................4 1.2 Installation Warnings .....................5 1.3 During Usage........................6 2 INSTALLATION ....................8 2.1 Machine Positioning .......................8 2.2 Water Connection ......................8 2.3 Water Inlet Hose ......................8 2.4 Drain Hose (Model Depending) ..................9 2.5 Electrical Connection ......................9 2.6 Fitting The Machine Undercounter ................10 3 TECHNICAL SPECIFICATIONS ..............

  • Page 4: Safety Instructions

    1 SAFETY INSTRUCTIONS 1.1 General Safety Warnings • Read these instructions carefully before using your appliance and keep this manual for future reference. Please check the packaging of your machine before installation and the outer surface of the machine once the packaging has been removed. Do not operate the machine if it appears damaged or if the packaging has been opened.

  • Page 5: Installation Warnings

    There may be some residue left in the machine after washing. Keep children away from the machine when it is open. 1.2 Installation Warnings • Choose a suitable and safe place to install your machine. • Only original spare parts should be used with the machine.

  • Page 6: During Usage

    Always use the coated plug supplied with your machine. If the electrical cable is damaged, it should only be replaced by a qualified electrician. • Connect the hose directly to the water inlet tap. The pressure supplied by the tap should be a minimum of 0.03 MPa and a maximum of 1 MPa.
  • Page 7 Do not open the door while the machine is in operation, hot water may spill out. Safety devices ensure the machine stops if the door is opened. The machine door should not be left open. It may cause accidents. Place knives and other sharp objects in the cutlery basket in a blade-down position.

  • Page 8: Installation

    2 INSTALLATION 2.2 Water Connection We recommend fitting a filter to your water 2.1 Machine Positioning inlet supply in order to prevent damage to your machine due to contamination (sand, When positioning the machine, place it in rust, etc.) from indoor plumbing. This will an area where dishes can be easily loaded also help prevent yellowing and deposit and unloaded.

  • Page 9: Drain Hose (Model Depending)

    2.5 Electrical Connection WARNING: After the connections are made, turn the tap on fully and check WARNING: Your machine is set to for water leaks. Always turn off the water operate at 220-240 V. If the mains inlet tap after a wash program has finished. voltage supply to your machine is 110 V, connect a transformer of 110/220 V and 3000 W between the electrical connection.

  • Page 10: Fitting The Machine Undercounter

    2.6 Fitting The Machine Undercounter EN - 10...
  • Page 11 4 Adjust the machine’s feet. The following options are available. ops.(+50) H= 870-920 mm EN - 11...
  • Page 12 Option 1: Attach the furniture kickplate. Option 2: Attach the adjustable plinth group. Follow the instructions supplied with the adjustable plint group. EN - 12...

  • Page 13: Technical Specifications

    3 TECHNICAL SPECIFICATIONS .2 Technical Specifications 10 place Capacity settings Dimensions 820-870 (mm) Height 448 (mm) Width 570 (mm) Depth Net weight 33 kg Operating 220-240V voltage / 50 Hz frequency Total current 10(A) .1 General Appearance Total power 1900(W) 1.
  • Page 14 RECYCLING • Some machine components and packaging consist of recyclable materials. • Plastics are marked with the international abbreviations:(>PE<, >PP<, etc. ) • The cardboard parts consist of recycled paper. They can be put into waste paper containers for recycling. •...

  • Page 15: Before Using The Appliance

    4 BEFORE USING THE 4.3 Fill The Salt (IF AVAILABLE) APPLIANCE To add softener salt, open the salt compartment cap by turning it counter 4.1 Preparing Your Dishwasher For First clockwise. (1) (2) At first use, fill the compartment with 1 kg salt and water (3) until it is almost overflowing.

  • Page 16: Test Strip

    4.4 Test Strip Run water Keep the Shake the Wait Set the hardness level of through the strip in the strip. (1min.) your machine. tap (1min.) water (1sec) second munite munite NOTE: The level is set to 3 as default. If the water is well water or has a hardness level above 90 dF, we recommend that you use filter and refinement devices.

  • Page 17: Detergent Usage

    4.8 Detergent Usage 4.10 Using Combined Detergents Only use detergents specifically designed These products should be used according for domestic dishwashers. Keep your to the manufacturer’s instructions. detergents in cool, dry places out of reach Never put combined detergents into the of children.
  • Page 18 In order to change the rinse aid level, follow the below steps before turning on the machine: • Turn on the machine by pressing the On/ Off button. • Press the Programme button for at least 5 seconds immediately after the machine is turned on.

  • Page 19: Loading Your Dishwasher

    5 LOADING YOUR DISHWASHER For best results, follow these loading guidelines. Loading the household dishwasher up to the capacity indicated by the manufacturer will contribute to energy and water savings. Manual pre-rinsing of tableware items leads to increased water and energy consumption and is not recommended You can place cups, glasses, stemware, small plates, bowls, etc.
  • Page 20 Two Folding Racks Upper Basket Height Adjustment The folding racks allow large items, such as pots and pans, to be placed more easily. Turn the Rail Stop Clips, at the ends of the Each part can be folded separately. They rails, to the sides to open them (as shown can either be raised upwards or folded in the image below), then pull out and...
  • Page 21 Height Adjustable Rack (peg type) The foldable racks in the upper basket enable the placement of large items such as pots and pans. Each section can be folded separately. The foldable racks can be either raised up or folded down. EN - 21...

  • Page 22: Alternative Basket Loads

    5.2 Alternative Basket Loads Important Note For Test Laboratories Lower Basket For detailed information required for tests according to EN normatives and a softcopy of the manual, please send the model name and serial number to the following address: dishwasher@standardtest.info Top Basket Incorrect Loads Incorrect loading can cause poor washing...

  • Page 23: Programme Table

    EN - 23...
  • Page 24 • The program duration may change according to the amount of dishes, the water temperature, the ambient temperature and selected additional functions. • Values given for programmes other than the eco programme are indicative only. • Eco programme is suitable to clean normally soiled tableware, that for this use, it is the most efficient programme in terms of its combined energy and water consumption, and that it is used to assess compliance with the EU ecodesign legislation.

  • Page 25: The Control Panel

    7 THE CONTROL PANEL 4. Remaining Time Indicator Programme flow can be monitored via the Wash,Rinse, Dry, End indicators and Remaining Time Indicator. 5. Start/Pause Button Press the Start/Pause button to start the programme. The wash lamp turns on and the Remaining Time Indicator shows the programme duration.

  • Page 26: Changing A Programme

    12. Extra Hygiene Indicator 7.1 Changing a programme Select the Extra Hygiene function to If you would like to change the programme increase the wash temperature, for a when the machine is already running. maximum hygiene washing operation. The Extra Hygiene Indicator will illuminate. Press the Start/ Pause button.

  • Page 27: Switching The Machine Off

    Save Power Mode To activate or deactivate save power mode, When the End light turns on, switch your machine off by follow the below steps: pressing the On/Off button. 1. Open the door and press Program (2) and Option (6) buttons at the same time for 3 seconds.

  • Page 28: Cleaning And Maintenance

    8 CLEANING AND 8.1 Filters MAINTENANCE Clean the filters and spray arms at least once a week. If any food waste remains Cleaning your dishwasher is important to or foreign objects on the coarse and maintain the machine’s service life Make sure that the water softening setting fine filters, remove them and clean them (If available) is done correctly and correct...

  • Page 29: Spray Arms

    8.2 Spray Arms 8.3 Drain Pump Make sure that the spray holes are not Large food residues or foreign objects clogged and that no food waste or foreign which were not captured by the filters may object is stuck to the spray arms. If there is block the waste water pump.

  • Page 30: Troubleshooting

    9 TROUBLESHOOTING FAULT POSSIBLE CAUSE TROUBLESHOOTING Your Dishwasher is not plugged in. Plug your Dishwasher in. Switch your Dishwasher on by pressing the Your Dishwasher is not switched on. On/Off button. Fuse blown. Check your indoor fuses. The programme does not start.
  • Page 31 FAULT POSSIBLE CAUSE TROUBLESHOOTING Use the correct amount of detergent, as Not enough detergent used. instructed in the programme table. Rinse aid dosage and/or water Increase rinse aid and/or water softener softener setting set too low. level. Whitish stains remains on dishes.
  • Page 32 AUTOMATIC FAULT WARNINGS AND WHAT TO DO TROUBLE POSSIBLE FAULT WHAT TO DO CODE Make sure the water inlet tap is open and water is flowing. Separate the inlet hose from the tap and clean the filter of Water inlet system failure the hose.
  • Page 33 Gram A/S Gram A/S Gram A/S Tel.: 22 07 26 30 Tel.: 040 38 08 40 Tel.: 020 7756 350 www.gram.no www.gram.se www.gram.fi Gram A/S . Gejlhavegård 2B . DK-6000 Kolding . +45 73 20 10 00 . www.gram.dk CE�...
