Configure The Router - TP-Link TL-WR841N Quick Installation Manual

Configure the Router

1. Connect your computer to the router (Wired or Wireless)
Wired
Turn off Wi-Fi on your computer and connect the devices as shown below.
Ethernet cable
WPS/ WPS/ WIFI WIFI
RESET RESET ON/OFF ON/OFF
ON/OFF ON/OFF POWER POWER WAN WAN 1 1 2 2 3 3 4 4
Wireless
Connect wirelessly by using the SSID (Network Name) and Wireless
Password/PIN printed on the product label at the bottom of the router.
2. Configure the router using a web browser
A Enter http://tplinkwifi.net or http://192.168.0.1 in the address bar of the
web browser. Enter admin for both username and password, and then click
Login.
Note: If the login window does not appear, please refer to FAQ > Q1.
http://tplinkwifi.net
admin
admin
Login
Copyright © 2016 TP-LINK Technologies Co., Ltd. All rights reserved.
B Click Quick Setup on the left menu, and click Next. Select your WAN
Connection Type. If you are unsure of your connection type, select
Auto-Dectect. Click Next and follow the onscreen instructions.
Quick Setup - WAN Connection Type
Auto-Detect
Dynamic IP (Most Common Cases)
Static IP
PPPoE/Russian PPPoE
L2TP/Russian L2TP
PPTP/Russian PPTP
Note: For users in some areas (such as Russia, Ukraine etc.), please contact your ISP to choose
connection type manually.
C Either use the default or customize your wireless settings, and click Next.
Note: If you change the default SSID and password, write down the new wireless settings.
Quick Setup - Wireless
Wireless Network Name(SSID):
Wireless Security:
D Click Finish to complete the Quick Setup.
Quick Setup - Finish
Congratulations!
The basic internet and wireless settings are finished, please click Finish button and test your internet
connection. If it is failed, please reboot your modem and wait 2 minutes or run the Quick Setup again.
Configure via Tether App
TP-LINK's Tether app lets you conveniently access the router and:
View information about the clients on your network.
Block network access from specific users or devices.
Set up Parental Control with access time and content restrictions.
Change the basic wireless network settings easily.
How to start?
1 Scan the QR code to download the TP-LINK Tether app from the
Apple App Store or Google Play.
2 Ensure your smart device is wirelessly connected to the home
network.
3 Launch the Tether app and start managing your home network.
FAQ (Frequently Asked Questions)
Q1. What can I do if the login window does not appear?
If the computer is set to a static or fixed IP address, change the settings to obtain an IP address
automatically.
Verify if http://tplinkwifi.net or http://192.168.0.1 is correctly entered in the web browser.
Alternatively, enter http://192.168.1.1 in the web browser and press Enter.
Use another web browser and try again.
Reboot your router and try again.
Disable the network adapter used currently and then enable it again.
Back Next
TP-LINK_7AFF
Disable Security
WPA-PSK/WPA2-PSK
XXXXXXXX
(You can enter ASCII characters between 8 and 63 or Hexadecimal
characters between 8 and 64.)
No Change
Back Next
Back Finish
Q2. What can I do if I cannot access the Internet?
Check if the Internet is working properly by connecting a computer directly to the
modem via Ethernet cable. If not, contact your Internet Service Provider.
Open a web browser, enter http://tplinkwifi.net or http://192.168.0.1 and run the
setup again.
Reboot your router and try again.
Note: For cable modem users, reboot the modem first. If the problem still exists, log in to the Web
Management page of the router, and go to Network > MAC Clone, click Clone MAC Address and then
click Save.
Q3. How do I restore the router to its factory default settings?
While the router is powered on, press and hold the WPS/RESET button on the rear
panel of the router for approximately 8 seconds.
Log in to the Web Management page of the router, and go to System tools > Factory
Defaults, click Restore, and then wait until the p rogress bar is finished.
Q4. What can I do if I forget my web management page password?
Refer to FAQ > Q3 to reset the router, and then use the default admin (all ilowercase)
for both username and password to log in.
Q5. What can I do if I forget my wireless network password?
If you have not changed the default Wireless Password, it can be found on the product
label of the router.
If you have changed your password, log in to the router's Web Management page, go
to Wireless > Wireless Security to obtain or reset your password.
Note: If your questions are not answered here, please refer to http://www.tp-link.com/en/support/faq and
click Contact Technical Support for further assistance.
©2016 TP-LINK
