Kyocera FS-C5300DN Service Manual
Hide thumbs
Also See for FS-C5300DN:
- Service manual (180 pages) ,
- Brochure (2 pages) ,
- Command reference manual (410 pages)
Related Manuals for Kyocera FS-C5300DN
Summary of Contents for Kyocera FS-C5300DN
-
Page 1: Service Manual
FS-C5300DN FS-C5200DN FS-C5100DN SERVICE MANUAL Published in December 2009 842HN112 2HNSM062 Rev.2... -
Page 2: Specifications
(1) Precautions ............................1-5-1 (2) Drum..............................1-5-1 (3) Toner container ..........................1-5-1 (4) How to tell a genuine Kyocera Mita toner container................1-5-2 1-5-2 Outer covers ............................1-5-3 (1) Detaching and refitting the left rear cover, left upper cover and left front cover........1-5-3 (2) Detaching and refitting the right rear cover, right upper cover and right front cover ......1-5-6... -
Page 3: Mechanical Construction
2HL/2HM/2HN 1-5-3 Paper feed section ..........................1-5-8 (1) Detaching and refitting the paper feed roller assembly (paper feed roller and pickup roller) ....1-5-8 (2) Detaching and refitting the retard roller ...................1-5-10 (3) Detaching and refitting the MP paper feed roller................1-5-12 1-5-4 Developing section..........................1-5-13 (1) Detaching and refitting the developing unit ..................1-5-13 1-5-5 Drum section............................1-5-15 (1) Detaching and refitting the drum unit ....................1-5-15... - Page 4 2HL/2HM/2HN 2-4 Appendixes 2-4-1 Appendixes .............................2-4-1 (1) Wiring diagram ..........................2-4-1 (2) Repetitive defects gauge........................2-4-3 (3) Maintenance parts list ........................2-4-4...
- Page 5 2HL/2HM/2HN This page is intentionally left blank.
- Page 6 2HL/2HM/2HN 1-1-1 Specifications 26/28 ppm (500-sheet) model Type ..........Desktop Printing method....... Electrophotographic four color (CMYK) printing using tandem (4) drum system Paper weight........Cassette: 60 to 120 g/m MP tray: 60 to 220 g/m Paper types* ........Cassette: Plain, preprinted, bond, recycled, rough, letterhead, color, prepunched, high quality, and custom MP tray: Plain, transparency, preprinted, labels, bond, recycled, vellum, rough, letterhead,...
- Page 7 2HL/2HM/2HN Resolution........600 dpi Operating systems......Microsoft Windows 2000/XP/Vista, Windows Server 2003 Apple Macintosh OS X Interface.......... USB: Hi-Speed USB Network: 10 BASE-T/100 BASE-TX KUIO-LV slot Option: Hard disk Memory card slot ......1 (CompactFlash, 4 GB or less) Margin..........4 mm (left, right, top and bottom) °...
- Page 8 2HL/2HM/2HN 21/23 ppm (500-sheet) model Type ..........Desktop Printing method....... Electrophotographic four color (CMYK) printing using tandem (4) drum system Paper weight........Cassette: 60 to 120 g/m MP tray: 60 to 220 g/m Paper types* ........Cassette: Plain, preprinted, bond, recycled, rough, letterhead, color, prepunched, high quality, and custom MP tray: Plain, transparency, preprinted, labels, bond, recycled, vellum, rough, letterhead,...
- Page 9 2HL/2HM/2HN Resolution........600 dpi Operating systems......Microsoft Windows 2000/XP/Vista, Windows Server 2003 Apple Macintosh OS X Interface.......... USB: Hi-Speed USB Network: 10 BASE-T/100 BASE-TX KUIO-LV slot Memory card slot ......1 (CompactFlash, 4 GB or less) Margin..........4 mm (left, right, top and bottom) °...
- Page 10 2HL/2HM/2HN 21/23 ppm (250-sheet) model Type ..........Desktop Printing method....... Electrophotographic four color (CMYK) printing using tandem (4) drum system Paper weight........Cassette: 60 to 120 g/m MP tray: 60 to 220 g/m Paper types* ........Cassette: Plain, preprinted, bond, recycled, rough, letterhead, color, prepunched, high quality, and custom MP tray: Plain, transparency, preprinted, labels, bond, recycled, vellum, rough, letterhead,...
- Page 11 2HL/2HM/2HN Resolution........600 dpi Operating systems......Microsoft Windows 2000/XP/Vista, Windows Server 2003 Apple Macintosh OS X Interface.......... USB: Hi-Speed USB Network: 10 BASE-T/100 BASE-TX KUIO-LV slot Memory card slot ......1 (CompactFlash, 4 GB or less) Margin..........4 mm (left, right, top and bottom) °...
- Page 12 2HL/2HM/2HN 1-1-2 Parts names (1) Overall 21/23 ppm (500-sheet) model and 26/28 ppm (500-sheet) model 21/23 ppm (500 sheet) model 26/28 ppm (500 sheet) model Figure 1-1-1 Operation panel Waste toner box 17. Envelope switch Front cover 10. Main charger units 18.
-
Page 13: Parts List
FS-C5100DN FS-C5200DN FS-C5300DN PARTS LIST Published in June 2009 2HNPL071... - Page 14 COVER FRONT SUB ASSY (21/23ppm 500sheet) FS-C5200DN 302HN94290 COVER FRONT SUB ASSY (26/28ppm 500sheet) FS-C5300DN 2. Symbols in the "Parts Number" column. • Parts with "•" are component parts or sub-assemblies of the assembly appearing immediately above them. e.g. Parts Number Parts Name...
- Page 15 CONTENTS FIG. 1 Covers 1 (21/23ppm 250sheet) ............2 FIG. 1 Covers 1 (21/23ppm 500sheet, 26/28ppm 500sheet) ......4 FIG. 2 Covers 2 .....................6 FIG. 3 Frames 1 ....................8 FIG. 4 Frames 2 (21/23ppm 250sheet) ............10 FIG. 4 Frames 2 (21/23ppm 500sheet, 26/28ppm 500sheet) .....12 FIG.
- Page 16 FIG. 1 Covers 1 (21/23ppm 250sheet) 2HL/2HM/2HN-1 - 2 -...
- Page 17 Kyocera-Mita FS-C5100DN, FS-C5200DN, FS-C5300DN service manual Kyocera-Mita FS-C5100DN, FS-C5200DN, FS-C5300DN service manual Kyocera-Mita FS-C5100DN, FS-C5200DN, FS-C5300DN service manual Kyocera-Mita FS-C5100DN, FS-C5200DN, FS-C5300DN service manual Kyocera-Mita FS-C5100DN, FS-C5200DN, FS-C5300DN service manual Kyocera-Mita FS-C5100DN, FS-C5200DN, FS-C5300DN service manual Kyocera-Mita FS-C5100DN, FS-C5200DN, FS-C5300DN service manual...
