535B Quick Guide
Customer Support Information .........................................2
Camera Left & Front........................................................3
Camera Right & Back .....................................................4
1. Quick Specs.................................................5
2. Loading Coaxial Magazines ........................6
3. Threading ...................................................8
4. Power On, Camera RUN, Inching...............10
5. Changing Fps ............................................11
6. Changing Shutter Angle.............................12
7. Timecode Sensitivity Table .........................13
7/97a
Advertisement
Table of Contents
Related Manuals for ARRI 535B
Summary of Contents for ARRI 535B
-
Page 1: Table Of Contents
535B Quick Guide Customer Support Information .........2 Camera Left & Front............3 Camera Right & Back .............4 1. Quick Specs..........5 2. Loading Coaxial Magazines ......6 3. Threading ...........8 4. Power On, Camera RUN, Inching....10 5. Changing Fps ..........11 6. Changing Shutter Angle......12 7. -
Page 2: Customer Support Information
• In order to ensure optimal performance, it is essential that you acquaint yourself with this Quick Guide and that you follow the operating instructions described herein. We strongly recommend that you also acquaint yourself with the full 535B instruction manual. • Assembly and initial operation should only be carried out after carefully reading the instructions and familiarizing yourself with the equipment and the assembly procedures! •... -
Page 3: Camera Left & Front
Run indicator light Camera door lock Locking slider MODE button LCD display SEL button SET button Image rotation knob Bubble level Friction adjustment Image rotation release Viewfinder PL mount Mirror shutter Viewfinder extension lock Arriflex 535B Quick Guide, 7/97a, Page 3... -
Page 4: Camera Right & Back
(display unit) RU receptacle (remote unit) ESU & MCL receptacle (external synchronization unit & master clock) Magazine opening cover CCU receptacle (camera control unit) BAT receptacle (power input) Two 3/8-16 mounting holes underneath camera Arriflex 535B Quick Guide, 7/97a, Page 4... -
Page 5: Quick Specs
0 0 0 0 0 0 _ 0 Movement block Film jam in upper Sprocket guides Film jam in lower loop not locked loop area are open area, or film end Arriflex 535B Quick Guide, 7/97a, Page 5... -
Page 6: Loading Coaxial Magazines
Always make sure that a loop protector is on the magazine when it is not on the camera. Also make sure that the magazine opening cover is on the camera when no magazine is attached to the camera. To learn how to load the light weight magazine LM-1, refer to the 535B manual. Step 1: The Feed Side Load unexposed film only in absolute dark - such as in a dark room or changing bag. - Page 7 TCS value by 1. See the table at the end of the Quick Guide for the proper TCS values. SET buttons MODE button Magazine display Collapsible core Lower magazine throat opening Take-up side film compartment Arriflex 535B Quick Guide, 7/97a, Page 7...
-
Page 8: Threading
Note: On the 535B the movement block is disengaged from the drive system when it is swung away from the gate. Both the movement and the drive system can now be turned independently of each other. - Page 9 (clockwise). Alternatively, you can push the PHASE button to electronically inch the camera. Upper film loop marking Knurled disc Upper sprocket roller Sprocket guide lever Movement locking lever Movement Inching knob Knurled disc Lower sprocket roller Lower film loop marking Arriflex 535B Quick Guide, 7/97a, Page 9...
-
Page 10: Power On, Camera Run, Inching
Turning Camera Power On The main power switch for the ARRIFLEX 535B is located on the underside of the electronics cover. When a battery is attached to the camera and the main power switch is turned on, you should see characters appear on the LCD display on the camera left side. -
Page 11: Changing Fps
Note: This minus sign is the only indication that the camera 21.325 fps. will run in reverse. Pay close attention! Note: Camera direction will be set to reverse for the standard speeds (NORM) and for the programmable speeds (PS). Arriflex 535B Quick Guide, 7/97a, Page 11... -
Page 12: Changing Shutter Angle
Note: When you close the shutter down, you have to compensate your exposure. Open up the lens aperture one stop for a 90° and two stops for a 45° shutter angle. Adjustment screw Shutter lock Arriflex 535B Quick Guide, 7/97a, Page 12... -
Page 13: Timecode Sensitivity Table
Color Negative † 5287 Color Negative † 8571 Color Negative 5293 Color Negative † 5294 Color Negative † 5295 Color Negative † 5296 Color Negative 5297 Color Negative 5298 Color Negative 5620 Color Negative Arriflex 535B Quick Guide, 7/97a, Page 13...
