2 CHANNEL DIGITAL PROPORTIONAL RADIO CONTROL SYSTEM
TABLE OF CONTENTS
I. Introduction
II. Components and Specifications
III. R/C Safety Precautions
IV. Operating Your Model
V. Installation
VI. Identification of Transmitter Parts
VII. Parts Listing
VIII. Frequency Chart
IX. Warranty & Service Information
I. INTRODUCTION
Congratulations on your purchase of the JR Python
2-channel radio control set which has been manufactured
and assembled with the greatest care.
We are confident that by following our simple instruc-
tions you will be delighted with your purchase. Please read
the instructions thoroughly, noting all points before use, in
order to avoid mistakes in handling and operation.
INSTRUCTION MANUAL
II. COMPONENTS AND SPECIFICATIONS
Your JR Python Radio includes the following items:
Transmitter................................................................. NET-112
2-Channel Receiver ................................................... NER-102
2-Channel B.E.C. Servo........................................ NES-510 x 2
Accessories............................................ B.E.C. Switch Harness
T
RANSMITTER
Antenna Output ......................................................... 500mW
Frequency............................................................... 27/75 MHz
Modulation......................................................................... AM
Power Supply ............................................................ 9.6V D/C
Dimensions ............................................. 8.15" x 7.00" x 3.35"
Weight............................................................................. 13 oz.
R
ECEIVER
Intermediate Frequency.............................................. 455KHz
Power Supply ................................................... 4.8V-8.4V D/C
Dimensions ............................................. 1.93" x 1.5" x 0.827"
Weight............................................................................ 1.3 oz.
S
ERVO
Torque ........................................................................ 27 in/oz.
Speed ....................................................................... .28 sec/60°
Dimensions ............................................... 1.42" x 1.54" x .75"
Weight............................................................................ 1.2 oz.
S
PECIFICATIONS
S
PECIFICATIONS
S
PECIFICATIONS
