13. LOCAL PROGRAMMING WITH RA-2400

PERFORM THE STEPS DETAILED IN THE
1
RA-2400/PERS REFERENCE GUIDE (P/N 224756)
TO SET UP THE RA-2400 PROGRAM
2 TO LOCALLY PROGRAM
THE CONSOLE, CONNECT
THE MODEM'S LINE JACK
TO THE CONSOLE'S LINE
JACK
PRESS THE TEST BUTTON
3
MOMENTARILY
• CONSOLE ANNOUNCES
TEST MODE
• START A LOCAL CONNECTION WITH
THE RA-2400 SOFTWARE
NOTE: CONSOLE WILL EXIT TEST MODE
AUTOMATICALLY AFTER 3 MINUTES
OR BY PRESSING THE CANCEL BUTTON
WHEN RA-2400 CONNECTION TIMER
4
STARTS COUNTING DOWN,
PRESS THE HELP BUTTON
• THE CONSOLE ANNOUNCES
"PHONE ON" WHEN THE CONSOLE
HAS CONNECTED
PERFORM PROGRAMMING IN THE RA-2400 SOFTWARE, SEND AND SAVE
5
THE ACCOUNT PROFILE, THEN DISCONNECT FROM THE CONSOLE

15. ACTIVITY TIMER OPERATION

NOTE: TO TURN THE ACTIVITY TIMER OFF, PRESS THE HOME BUTTON FOR FIVE
SECONDS, THIS WILL ALSO TURN ON/OFF REMINDER REPORTING IF REMINDER
SCHEDULE TIME OUT REPORT IS ENABLED IN THE RA-2400 SOFTWARE (ACTIVITY
TIMER CAN BE DISABLED SEPARATELY IN RA-2400 ALARMS PROGRAMMING)
2 ACTIVITY TIMER RUNNING
THE HOME INDICATOR WILL LIGHT,
SHOWING THAT THE ACTIVITY
TIMER IS ENABLED
4 RESETTING ACTIVITY TIMER
THE SUBSCRIBER NEEDS TO
PRESS THE HOME BUTTON OR
TRIGGER AN ACTIVITY
TRANSMITTER BEFORE THE
TIMER EXPIRES TO PREVENT
AN INACTIVITY REPORT
PRESSING THE HOME BUTTON
RESTARTS THE TIMER
4
LINE-TO-LINE
ENABLING THE ACTIVITY TIMER
1
PRESS THE HOME BUTTON FOR
5 SECONDS TO TURN THE
ACTIVITY TIMER ON
NOTE: THE ACTIVITY TIMER CAN
BE ENABLED FOR 8, 12, OR
24 HOURS, OR DISABLED BY

PROGRAMMING

3 TIME RUNNING OUT
THE HOME INDICATOR WILL BLINK &
THE CONSOLE ANNOUNCES EVERY
10 SECONDS WHEN LESS THAN
15 MINUTES OF TIME REMAIN

14. SYSTEM OPERATION

CONSOLE
STANDING BY
POWER
LIGHT
IS ON
- IN CASE OF EMERGENCY -
PRESS AND
MOMENTARILY
HOLD THE
HELP BUTTON
CONSOLE
IN ALARM
THE CONSOLE
ANNOUNCES
EMERGENCY
UNTIL THE CANCEL
BUTTON IS PRESSED,
CENTRAL STATION
REPORT IS COMPLETE,
OR THE SIREN TIME EXPIRES

16. AUDIO OPERATION

1 PROGRAM THE CONSOLE FOR THE DESIRED AUDIO MODE:
1) LISTEN-ONLY
2) 2-WAY MANUAL
3) 2-WAY VOICE ACTIVATED (DUPLEX)
2
AFTER THE CENTRAL STATION OPERATOR ACKNOWLEDGES THE
COMMUNICATOR'S REPORT, THE CONSOLE WILL STOP ITS LOCAL
ALARM AND SWITCH TO THE SELECTED AUDIO MODE FOR 90 SECONDS
AUDIO OPERATION CAN ALSO BE ESTABLISHED BY CALLING THE
CONSOLE TWICE AND KEYING IN THE FOUR DIGIT REMOTE AUDIO
PASSWORD FOLLOWED BY THE # KEY (SEE SECTION #22)
3
CENTRAL STATION OPERATOR OR AUDIO CALLER:
USE THESE KEYS ON A TELEPHONE SET TO CONTROL THE CONSOLE'S
AUDIO MODE (IN CENTRAL STATION, CONNECT A TELEPHONE TO THE
SAME TELEPHONE LINE AS THE CENTRAL STATION RECEIVER)
ALL
AUDIO
MODES
2-WAY
MANUAL
AUDIO
MODE
THE "1" AND "3" KEYS ARE NOT USED IN LISTEN-ONLY AUDIO MODE
THE "1" AND "3" KEYS CAN BE USED IN 2-WAY VOICE ACTIVATED MODE.
USING THEM WILL CAUSE THE SYSTEM TO SWITCH TO 2-WAY MANUAL
MODE. PRESSING "8" RESTORES 2-WAY VOICE ACTIVATED MODE.
PRESSING ANY KEY OTHER THAN "9" WILL EXTEND THE AUDIO TIME
90 MORE SECONDS
HOME LIGHT SHOWS
ACTIVITY TIMER STATUS
THE OTHER
CONSOLE
LIGHTS ARE
NORMALLY
OFF
- OR -
ACTIVATE
AN EMERGENCY
TRANSMITTER
PRESS TRANSMITTER
BUTTON FOR AT LEAST
2 SECONDS
SENDING LIGHT
FLASHES DURING
COMMUNICATION
PRESS CANCEL TO
STOP THE ALARM
(ADDS CANCEL TO
ALARM REPORT IN
PROGRESS)
PRESS "9" TO
DISCONNECT THE CALL
PRESS "3" TO LISTEN
PRESS "1" TO TALK
