5. OPTIONAL RELAY OUTPUT CONNECTIONS

NOISEMAKER OR
VISUAL INDICATOR
EXTERNAL
POWER SUPPLY
ROUTE CABLE UNDER
STRAIN-RELIEF CLAMP

7. BACKUP BATTERY

TURN POWER
1
2
SWITCH OFF
ON
OFF
2
FORM "A" DRY CONTACT RELAY
24 VOLTS AT 1 AMP MAXIMUM
5
4 - RELAY NORMALLY OPEN
3 - RELAY COMMON
2
1
CONSOLE
TERMINAL BLOCK
CONNECT WIRES
TO TERMINALS
CONNECT RED LEAD TO
POSITIVE AND BLACK LEAD TO
NEGATIVE BATTERY TERMINAL
BATTERY TYPE: 12-VOLT, 1.2 AMP/HOUR
FIT BATTERY
3
INTO CONSOLE
SLIDE DOWN
THEN BACK

6. OPTIONAL REMOTE SPEAKER/MIC CONNECTIONS

VB-4B
VOICE
BOARD
VB-4B TERMINAL BLOCK
EXTERNAL MICROPHONE (+)
MICROPHONE COMMON (-)
CONSOLE MICROPHONE (+)
NOTE: REMOVE
JUMPER WHEN
USE
USING AN
SHIELDED
EXTERNAL SPKR
TWISTED PAIR
WIRE FOR
MICROPHONE
SPKR
SPKR
MIC (-)
MIC (+)
RSM-1 TERMINAL BLOCK

8. INSTALL TRANSFORMER

PLUG TRANSFORMER
1
INTO AN UN-SWITCHED
117 VAC OUTLET
2
REMOVE
JUMPER
WIRE
CONSOLE
TERMINAL BLOCK
5 - DIALER POWER
4 - RELAY NORMALLY OPEN
3 - RELAY COMMON
DIALER COMMON
2 -
EXTERNAL SPEAKER
1 - EXTERNAL SPEAKER
NOTE: NOT
TESTED BY UL
LINEAR
TERMINALS
MODEL RSM-1
SECURE
TRANSFORMER
WITH SCREW
RSM-1
