- Page 1 GLOBE 4800/4900 CAN MANUALE UTENTE USER INSTRUCTIONS MANUEL D’UTILISATION MANUAL DEL USUARIO 06DE2177B.pmd 28/05/2007, 10.33...
- Page 2 Dear customer, Congratulations on your purchase of this product which has been designed and manufactured to the highest automotive standards utilising the latest technology for total reliability as per the European Community directives. This manual contains the product installation certificate. The manual is divided in 9 parts: Page 13 __________ INTRODUCTION 14 __________ ADDITIONAL PROTECTION...
- Page 3 1 - INTRODUCTION The anti-intrusion alarm systems GLOBE 4800/4900 CAN are operated by the original high-security remote control of the vehicle and interfaced with the original vehicle data link trough a CAN (Controller Area Network) serial interface. It gives a higher functional safety and reliability, reducing also complexity and installation time.
-
Page 4: Additional Protection
2 - ADDITIONAL PROTECTION You can increase the protection level of the system with the following additional sensors: 5452: Level monitor module When the system is armed, this sensor will detect the vehicle being jacked up to tow it away or to steal the wheels. 5462: Hyperfrequency module When the system is armed a microwave emission from the hyperfrequency module hidden in the passenger compartment will ensure the volumetric protection of the vehicle. -
Page 5: Brief Instructions
3 - BRIEF INSTRUCTIONS 3.6 - Deactivating the volumetric ultrasonic sensor The volumetric sensor can be deactivated if you want to leave 3.1 - Arming the windows open or if someone remains in the passenger • Press the button of the radio control to lock the doors (if the compartment. -
Page 6: Basic Functions
4 - BASIC FUNCTIONS 4.1 - Introduction As the standard working features of this system can be modified by the installer he should have indicated the differences with the standard factory set-up (black squares) on this manual. 4.2 - Buzzer 4.5 - Arm/disarm blinker Activated Deactivated... -
Page 7: Advanced Functions
4.8 - Immobilizer alarm 5 - ADVANCED FUNCTIONS 5.1 - Immobilizer auto re-arm Activated Deactivated An alarm function can be added to the immobilizer automatic Activated Deactivated arming. 25 s after the ignition is switched ON the alarm will The immobilizer will automatically rearm if the ignition is not trigger. -
Page 8: Alarm Memory
6 - ALARM MEMORY When disarming, the system signals an alarm with buzzer and 4 blinks of the turn indicators. Pay attention to LED signalling, that will be available up until the next re-arming of the system or until the ignition is switched on. The different signals indicate the cause of the alarm. -
Page 9: Emergency Override
7 - EMERGENCY OVERRIDE The emergency override can happen in two different ways: - the first way is made turning ON the ignition key and in this way it happenes immediately (transponder detecting); - the second way happens through the control panel and to proceed with this way follow the instructions listed below. Press the push button placed on the control panel a number of times corrisponding to the first digit of your PIN CODE. - Page 10 8 - PIN CODE PERSONALISATION • press the button on the control panel for a number of times corresponding to the first digit of the new PIN CODE. The The PIN code should be personalized. As the PIN CODE LED will blink everytime you press the button, a longer enables access to the system, it should not be left in the blink will confirm that the right PIN CODE digit has been unattended vehicle as it can be used to deactivate the system...
-
Page 11: Troubleshooting
9 - TROUBLE SHOOTING The vehicle original remote Refer to the vehicle ower’s When you disarm the system the LED control is not working (remote manual displays a series of flash codes which central door locking not indicates the cause of the trigger (chapter 6) operated Contact your dealer.
