Inset live fuel effect gas fire
Hide thumbs Also See for Expression HE:
Table of Contents

Advertisement

Quick Links

Expression HE
INSET LIVE FUEL EFFECT GAS FIRE
Installation, Maintenance & User Instructions
Hand these instructions to the user
Model No's FHKCEHRN is only for use on Natural Gas (G20) at a
supply pressure of 20 mbar in G.B. / I.E.
** denotes trim and fret variant

Advertisement

Table of Contents
loading

Related Manuals for Flavel Expression HE

Summary of Contents for Flavel Expression HE

  • Page 1 Expression HE INSET LIVE FUEL EFFECT GAS FIRE Installation, Maintenance & User Instructions Hand these instructions to the user Model No’s FHKCEHRN is only for use on Natural Gas (G20) at a supply pressure of 20 mbar in G.B. / I.E.

  • Page 2: Table Of Contents

    CONTENTS Section 1 Information and Requirements PAGE Appliance Information Conditions of Installation Flue and chimney suitability Fireplace / surround suitability Shelf position Chimney inspection Fire place opening / catchment space Fitting to metal flue boxes Fitting to pre-cast flues Spillage monitoring system 1.10 Wall / hearth mounting Section 2...

  • Page 3: Information And Requirements

    SECTION 1 INFORMATION AND REQUIREMENTS APPLIANCE INFORMATION Model FHKCEHRN Gas Type Main injectors (2 off) Size 130 Pilot Type Copreci 21100 / 162 (RC) Max. Gross Heat Input : 4.5 kW Min. Gross Heat Input : 3.5 kW Cold Pressure : All models 20.0 +/- 1.0 mbar Ignition : 9V battery generator (RC models)

  • Page 4: Conditions Of Installation

    INSTALLATION REQUIREMENTS CONDITIONS OF INSTALLATION It is the law that all gas appliances are installed only by a Registered Installer, in accordance with these installation instructions and the Gas Safety (Installation and Use) Regulations 1998 as amended. Failure to install appliances correctly could lead to prosecution.

  • Page 5: Fireplace / Surround Suitability

    FIREPLACE / SURROUND SUITABILITY The fire must only be installed on a hearth it must not be installed directly onto carpet or other combustible floor materials. The fire is suitable for fitting to non-combustible fire place surrounds and proprietary fire place surrounds with a temperature rating of at least 150 o c.

  • Page 6: Fire Place Opening / Catchment Space

    Check the chimney pot / terminal and general condition of the brickwork or masonry. If the chimney or flue is in poor condition or if there is no up-draught do not proceed with the installation. If there is a history of down-draught conditions with the chimney / flue, a tested and certificated flue terminal or cowl suitable for the relevant flue type should be considered.

  • Page 7: Fitting To Metal Flue Boxes

    Table A - Installation Depth Requirements for a Flavel Expression HE being installed into a brick built chimney, requiring 12.0 litres of debris collection volume (figure 2) When installing this product into a brick built chimney, there must be a minimum depth available of 200mm available for the collection of debris behind the firebox when installed.

  • Page 8: Fitting To Pre-Cast Flues

    FITTING TO PRE-CAST FLUES When installing this appliance into pre-cast flues, always ensure that the spigot restrictor baffle has been removed. To install the fire box in to pre-cast flue starter blocks, there must be at least 180mm from the mounting face of the fire to the rear of the pre-cast flue starter block to allow sufficient space for debris collection.

  • Page 9: Wall / Hearth Mounting

    1.10 WALL / HEARTH MOUNTING This appliance must be fitted on a flat, non-combustible base of minimum thickness 12mm. In addition, a non-combustible hearth or physical barrier should be provided in front of the fire. With “hole in the wall” type installations, where it may be desirable not to fit a hearth panel or physical barrier, the product may be installed in accordance with Document J of the building regulations so that every part of the flame or incandescent material is at least 225mm above the floor level.

  • Page 10: Installation Of Fire

    SECTION 2 INSTALLATION OF FIRE UNPACKING THE FIRE Carefully lift the fire out of the carton. Remove the loose item packaging carefully from the front of the appliance. Check the contents as listed :- Packing Check List 1 off Fire box / burner assembly 1 off Boxed ceramic base, front ceramic rail and 7 coals 1 off...
  • Page 11 Proceed as follows :- Remove the top glass retaining cover from the product. It is secured via the two screws as indicated. See figure 6 below. Fig. 6 2 off securing screws Remove the left and right hand side glass securing brackets from the product.
  • Page 12 Lift the glass panel forwards and clear from the firebox, taking care not to damage the glass panel. See figure 8 below. Fig. 8 Remove the burner heat shield, which is retained by 2 off screws as shown below in figure 9. Fig.
  • Page 13 For all Remote Control models proceed as follows :- Remove the two off screws from the left and right hand burner mounting brackets, plus the two screws from the base of the control panel as shown below in figure 10, this will allow removal of the complete burner unit from the firebox.
  • Page 14 Continue as follows :- Whilst the fire box is still in position, decide which side the gas supply is to enter the fire from. If concealed pipe work is required plan the pipe run to enter the fire box through one of the openings in the sides or rear of the fire box below the fuelbed support panel and connect to the isolating / inlet elbow.
  • Page 15 IMPORTANT : Sealing of the Gas Unused Gas Pipe Inlet Apertures In line with current regulations, it is imperative that the gas supply inlet aper- tures that are not utilised during the installation are sealed with the foil tape as supplied. Failure to seal these inlet apertures could lead to flame reversal, which in turn will damage the burner and control systems of the product.
  • Page 16 The preferred method of fixing which is suitable for almost all situations is the cable fixing method which is described in the following section in detail. To fit using the preferred cable method proceed as follows- Mark out and drill 4 off No 14 (6mm) holes in the back face of the fire opening in the positions shown below in figure 14.
  • Page 17 Fig. 15 Evenly tighten the tensioning nuts to tension both cables and pull the fire snugly against the wall. Do not overtighten, it is only necessary to pull the seal up against the sealing face of the wall, it does not need to be compressed.

  • Page 18: Gas Tightness And Inlet Pressure

    The other firebox fixing method is as follows :- In installations where the cable method is not suitable (e.g. loose masonary in rear of fire opening) the firebox can be secured to the fire surround using four screws and wall plugs provided. Below (figure 16) is a diagram to indicate the hole centre positions available on the firebox to facilitate the screw fixing to the fireplace / surround.

  • Page 19: Assembling Fuel Bed And Commissioning

    SECTION 3 ASSEMBLING FUEL BED AND COMMISSIONING ASSEMBLING THE CERAMICS AND FUEL BED - COAL MODELS Place the ribbed ceramic fuelbed base on top of the fuelbed support and pull fully forwards to the burner. Make sure that the fuelbed base is located centrally in the fire box.
  • Page 20 Position the front ceramic coal support onto the burner support as shown below in figure 19. Fig. 19 Positioning of front ceramic coal support onto burner support Fit the front row left hand coal as shown below in figure 20. Fig.
  • Page 21 Fit the front row left hand side central coal as shown below in figure 21. Fig. 21 Fit the front row right hand side central coal as shown below in figure 22. Fig. 22...
  • Page 22 Fit the front row right hand coal as shown below in figure 23. Fig. 23 Fit the rear row of 3 coals as shown below in figure 24. Fig. 24 The exact position and fit of the coals may be very finely adjusted to give the most pleasing and random appearance.
  • Page 23 Warning : Use only the coals supplied with the fire. When replacing the coals remove the old coals and discard them. Fit a complete set of coals of the correct type. Do not fit additional coals or any coals other than a genuine replacement set. To ensure that the release of fibres from these R.C.F (Refractory Ceramic Fibre) articles is kept to a minimum, during installation and servicing we recommend that you use a HEPA filtered vacuum to remove any dust...

  • Page 24: Connecting The Battery Pack

    CONNECTING THE BATTERY PACK (Remote Control Models) To prevent un-necessary battery drain, the battery pack that is used to provide the remote control function for this product is disconnected at the factory. Prior to attempting to light the product, can the installer please ensure that the battery pack is re-connected as shown in section b), &...

  • Page 25: Fixing The Infra-Red Eye

    FIXING THE INFRARED SENSOR IN POSITION The infrared eye as shown below in figure 27 is supplied on a flying lead, the self adhesive pad should be used to secure the infrared eye to the Expression fascia as shown in figure 28, the handset will require line of sight to the infrared eye to ensure correct operation.

  • Page 26: Lighting The Appliance

    LIGHTING THE APPLIANCE The Remote control handset generates an infrared signal, which will be received by the sensor situated at the front right of your fire, behind the black controls cover. This infrared signal requires direct line of sight from the handset to the sensor on the fire to ensure good operation. To light the appliance using the handset, point the handset at the fire and press the 2 left hand buttons together.

  • Page 27: Fitting The Expression Fascia

    FITTING THE EXPRESSION FASCIA Hook the fascia onto the top mounting bracket fitted to the firebox The bottom of the fascia is retained by magnets fitted to the lower retaining brackets. CHECKING FOR CLEARANCE OF COMBUSTION PRODUCTS Close all doors and windows in the room. Light the fire and allow to run for approximately 5 minutes on high position.

  • Page 28: Maintenance

    MAINTENANCE Servicing Notes Servicing should be carried out annually by a competent person such as a registered engineer. This is a condition of the Flavel extended guarantee schemes. The service should include changing the oxypilot as a condition of the guarantee and visually checking the chimney and fire opening for accumulations of debris and a smoke test to check for a positive up-draught in the chimney.

  • Page 29: Removing The Remote Gas Valave

    Removing the Remote Gas Valve from the fire 4.2.1 Prepare work area (lay down dust sheets etc.) 4.2.2 Remove the burner assembly as described in section 4.1. 4.2.3 Disconnect pilot, main and injector pipes and disconnect the wiring loom thermocouple and ignition wire, the valve can then be removed. Re-assemble in reverse order, refit the burner heat shield then refit the coals referring to section 3 for the correct coal layout.

  • Page 30: Repacing The Batteries

    Replacing the Batteries 4.4.1 Prepare work area (lay down dust sheets etc.) 4.4.2 Remove the trim / fret & ashpan cover. 4.4.3 The battery pack is located on the right hand side of the product, below the burner assembly. Slide the battery pack out, and replace the batteries as necessary.
  • Page 31 PARTS SHORTLIST Replacement of parts must be carried out by a competent person such as a registered gas installer. The part numbers of the replaceable parts are as follows, these are available from your local stockist, whose details may be found on the BFM Europe website, address as per rear page.

  • Page 32: Conditions Of Installation & About Your New Fire

    SECTION SIX - USER INSTRUCTIONS 6.1 INSTALLATION INFORMATION CONDITIONS OF INSTALLATION It is the law that all gas appliances are installed only by a competent (e.g. Registered) Installer, in accordance with the installation instructions and the Gas Safety (Installation and Use) Regulations 1998. Failure to install appliances correctly could lead to prosecution.
  • Page 33 ABOUT YOUR NEW EXPRESSION HE (High Efficiency) GAS FIRE The Flavel Expression High Efficiency coal effect gas fire incorporates a unique and highly developed fuel bed which gives the realism of a loose coal layout combined with realistic flames and glow. The use of durable ceramic material in the construction of the fuelbed components ensures long and trouble free operation.

  • Page 34: Operating The Fire

    OPERATING THE FIRE The Remote control handset generates an infrared signal, which will be received by the sensor situated at the front right of your fire, behind the black controls cover. This infrared signal requires direct line of sight from the handset to the sensor on the fire to ensure good operation. To light the appliance using the handset, point the handset at the fire and press the 2 left hand buttons together.

  • Page 35: Remote Handset Malfunction

    6.3 TURNING THE PRODUCT OFF IN THE UNLIKELY EVENT OF A REMOTE HANDSET MALFUNCTION. In the unlikely event of the remote control handset malfunctioning (or if lost or broken) after the appliance has been turned on, the fire can be turned off via the emergency shut off switch on the control panel.

  • Page 36: Re-Assembling The Ceramics And Fuel Bed

    RE-ASSEMBLING THE CERAMICS AND FUEL BED NOTE : The position of the fuel-bed components are critical to the performance of the product. Therefore please ensure that the fuel-bed components are positioned as described in the following section prior to requesting a service call due to soot build up, poor flame pattern etc. Remove the glass panel and retaining trims as detailed on page 11 &...
  • Page 37 Position the front ceramic coal support onto the burner support as shown below in figure 5. Fig. 5 Positioning of front ceramic coal support onto burner support Fit the front row left hand coal as shown below in figure 6. Fig.
  • Page 38 Fit the front row left hand side central coal as shown below in figure 7. Fig. 7 Fit the front row right hand side central coal as shown below in figure 8. Fig. 8...
  • Page 39 Fit the front row right hand coal as shown below in figure 9. Fig. 9 Fit the rear row of 3 coals as shown below in figure 10. Fig. 10 The exact position and fit of the coals may be very finely adjusted to give the most pleasing and random appearance.

  • Page 40: Cleaning The Fire

    Warning : Use only the coals supplied with the fire. When replacing the coals remove the old coals and discard them. Fit a complete set of coals of the correct type. Do not fit additional coals or any coals other than a genuine replacement set. To ensure that the release of fibres from these R.C.F (Refractory Ceramic Fibre) articles is kept to a minimum, during installation and servicing we recommend that you use a HEPA filtered vacuum to remove any dust...

  • Page 41: Removal & Re-Fitting The Expression Fascia

    PLEASE NOTE :- The glass will require cleaning periodically. Condensation produced by the products of combustion will create marks on the inside face of the glass panel. REMOVAL AND RE-FITTING THE EXPRESSION FASCIA Hook the fascia onto the top mounting bracket fitted to the firebox The bottom of the fascia is retained by magnets fitted to the lower retaining brackets.
