PEBBLE FUEL EFFECT GAS FIRE
Installation and Maintenance Instructions
Hand these instructions to the user
Model No's FSCP**MN is only for use on Natural Gas (G20) at a
supply pressure of 20 mbar in G.B. / I.E.
** denotes trim fascia fitted
Supplied By www.heating spares.co Tel. 0161 620 6677
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Flavel Enchant FSCP**MN
Summary of Contents for Flavel Enchant FSCP**MN
- Page 1 Enchant PEBBLE FUEL EFFECT GAS FIRE Installation and Maintenance Instructions Hand these instructions to the user Model No’s FSCP**MN is only for use on Natural Gas (G20) at a supply pressure of 20 mbar in G.B. / I.E. ** denotes trim fascia fitted Supplied By www.heating spares.co Tel.
-
Page 2: Table Of Contents
CONTENTS Section 1 Information and Requirements PAGE Appliance Information Conditions of Installation Flue and chimney suitability Fireplace / surround suitability Shelf position Chimney inspection Fire place opening / catchment space Fitting to Chair bricks Precast Flues Metal Flue boxes 1.10 Hearths 1.11 Spillage Monitoring System... -
Page 3: Information And Requirements Page
SECTION 1 INFORMATION AND REQUIREMENTS APPLIANCE INFORMATION Model FSCP**MN ** denotes fascia fitted Gas Type Main injectors (2 off) Size 235 Pilot Type Copreci Single Flame 21100 / 141 S.I.T. Dual Flame YA OP 9022 Max. Gross Heat Input : 6.5 kW Min. -
Page 4: Conditions Of Installation
INSTALLATION REQUIREMENTS CONDITIONS OF INSTALLATION It is the law that all gas appliances are installed only by a CORGI Registered Installer, in accordance with these installation instructions and the Gas Safety (Installation and Use) Regulations 1998 as amended. Failure to install appliances correctly could lead to prosecution. -
Page 5: Fireplace / Surround Suitability
FIREPLACE / SURROUND SUITABILITY The fire must only be installed on a hearth it must not be installed directly onto carpet or other combustible floor materials. The fire is suitable for fitting to non-combustible fire place surrounds and propri- etary fire place surrounds with a temperature rating of at least 150 o c. If a heating appliance is fitted directly against a wall without the use of a fire surround or fire place all combustible material must be removed from behind the trim. -
Page 6: Fire Place Opening / Catchment Space
There must be no leakage of smoke through the structure of the chimney during or after the smoke pellet test and it is important to check inside upstairs rooms adjacent to the chimney / flue. Check the chimney pot / terminal and general condition of the brickwork or masonry. - Page 7 Table A - Installation Depth Requirements for a Flavel Enchant being installed into a brick built chimney, requiring 12.0 litres of debris collection volume (fig. 2). Opening Width (mm) Minimum Depth Required (mm) 330 (minimum opening width) 440 (maximum opening width) For example, if the appliance was to be fitted into a 400mm wide opening, the depth required would be 189mm.
-
Page 8: Fitting To Chair Bricks
1.7 FITTING TO FIREPLACES WITH EXISTING CHAIRBRICKS AND CONVENTIONAL BRICKBUILT CHIMNEYS This appliance is suitable for use in fireplaces fitted with an existing chairbrick without the need for removal of the chairbrick, providing the minimum depth of the fireplace exceeds 175mm. If the depth is less than 175mm then the chairbrick must be removed. -
Page 9: Hearths
1.10 HEARTHS This appliance must only be installed on to a concrete or non-combustible hearth. The hearth material must be a minimum thickness of 12mm with the top surface at least 50mm above the floor. The hearth must be fitted symmetrically about the fire opening and have a minimum width of 760mm and a minimum projection of 300mm forwards from the fire opening. -
Page 10: Installation Of Fire
SECTION 2 INSTALLATION OF FIRE UNPACKING THE FIRE Carefully lift the fire out of the carton. Remove the loose item packaging carefully from the front of the appliance. Check the contents as listed :- Packing Check List 1off Fire box / burner assembly 1off Boxed ceramic base, ceramic front rails and 17 synthetic pebbles (9 large 8 small - grey and beige mixed) - Page 11 Proceed as follows :- Remove the contemporary trim and ashpan cover. Remove the burner heat shield from the front of the fire box to allow access to the burner. See fig. 3 below. Fig. 3 Ensure that the hearth is protected from damage and carefully lift the fire box into the fire opening, then slide it back into position.
- Page 12 Whilst the fire box is still in position, decide which side the gas supply is to enter the fire from. If concealed pipe work is required plan the pipe run to enter the fire box through one of the openings in the sides or rear of the fire box below the fuelbed support panel and connect to the isolating / inlet elbow.
- Page 13 There is a choice of methods of fixing the firebox which are provided to enable the installer to deal with any type of installation. The preferred method of fixing which is suitable for almost all situations is the cable fixing method which is described in the following section in detail. The fire may be secured using the cable method as described below, or alternatively, in installations where the cable method is not suitable (eg.
- Page 14 Position the fire carefully on the (protected) surface of the hearth and reach into the fire opening. Thread each of the cables vertically downwards through the pair of fixing eyes on the same side of the fire. Thread the free end of the cables through the corresponding circular hole on each side of the lower rear of the fire.
-
Page 15: Gas Soundness And Burner Pressure
Refit the front burner heat shield to the sides of the fire box (2 Screws) and secure the brushed stainless trim to the fire using the magnets provided. Before making the final gas connection, thoroughly purge the gas supply pipework to remove all foreign matter, otherwise serious damage may be caused to the gas control valve on the fire. -
Page 16: Assembling Fuel Bed And Commissioning
the control knob for a few seconds then turn to the full-on position. Check that the gas pressure is 20.0 mbar (+/- 1.0mbar) 8.0 in w.g.(+/- 0.4 in w.g.) Turn off the fire, remove the manometer and refit the pressure test point screw. - Page 17 Position the two halves of the front ceramic (L/H & R/H) on the locating channel in the front ceramic, ensuring they are located onto the lip on the burner front ceramic support. (See fig. 11 below) Fig. 11 Select six of the small pebbles and position evenly along the front ceramic rail, using the location indents in the front ceramic rail as a guide for position.
- Page 18 Select four of the large pebbles and position behind the front row of pebbles, ensuring that the flame paths as indicated below are not interupted. See fig. 13 Fig. 13 Select 2 of the large pebbles and position along the back row of the fuelbed, using the location indents on the back section of the fuelbed as a guide for placement.
-
Page 19: Lighting The Appliance
Select the remaining three large pebbles and position between the second and third rows of pebbles, as shown below in fig. 15. Fig. 15 Warning : Use only the pebble set supplied with the fire. When replacing the pebbles remove the old pebbles and discard them. Fit a complete set of pebbles of the correct type. -
Page 20: Checking For Clearance Of Combustion Products
Slightly depress the control knob and turn to the off position, the pilot will now be extinguished. WARNING : If the fire goes out for any reason or is turned off and it is necessary to re-light the fire it is important to allow the fire to cool for 3 minutes before attempting to re-light it. - Page 21 Servicing Notes Servicing should be carried out annually by a competent person such as a CORGI registered engineer. This is a condition of the Flavel Fires guarantee schemes. The service should include visually checking the chimney and fire opening for accumulations of debris and a smoke test to check for a positive up-draught in the chimney.
- Page 22 Removing the Control Tap from the fire. 4.3.1 Remove the burner assembly as in section 4.1. 4.3.2 Pull the control knob off the control tap spindle. 4.3.3 Loosen and remove the three gas pipe retaining nuts from the control tap and release the ends of the gas pipes from the control tap body. Loosen and remove the thermocouple securing nut from the end of the control tap.
-
Page 23: Cfm Europe Ltd
PARTS SHORTLIST Replacement of any other parts must be carried out by a competent person such as a CORGI registered gas installer. The part numbers of the user replaceable parts are as follows, these are available from CFM Europe Ltd. who may be contacted at the address shown below. - Page 24 Supplied By www.heating spares.co Tel. 0161 620 6677...
