Charging the Scanner

Use the included AC adapter to charge the Cordless Hand Scanner. The included
NiMH batteries must be charged for at least 4 hours before initial use.
The Battery Status LED will emit a solid red light while charging, and turn off when
the batteries are fully charged (see back cover for more information about the LED).
A fully charged scanner should provide roughly 8 hours of normal operation.
WARNING: Charge only NiMH batteries in the CHS. Damage may occur if
alkaline or other types of batteries are charged. Do not store the CHS for more
than 30 days with the batteries installed.
Besides the included AC Adapter, you can charge the CHS using AC and DC
adapters of the most recent Pocket PCs from Casio, Dell, Fujitsu, HP and Toshiba.
The adapter rating is 5V, 2A, positive pole center.
The red Battery Status LED will not function properly if standard AAA alkaline
batteries are being used.
A charging cradle is available separately for the CHS 7P (not
compatible with 7E or 7M).
For more information, please visit:
www.socketcom.com/product/AC4026-708.asp
About the Touch Screen Stylus
The CHS features a stylus tip in the tail of the
scanner that you can use on Pocket PC and other
device touch screens. The stylus can be removed
with small pliers if desired. Visit the Socket
website to purchase replacement styli.
WARNING: Do not use the stylus if damaged. A
damaged stylus may scratch the display screen
of your device.
The stylus does not work with XP Tablet computers using Active Matrix displays.
5
S W M
ETUP FOR INDOWS OBILE
Follow these instructions to set up the Socket Cordless Hand Scanner for use with a
Bluetooth enabled device running Windows Mobile 2003, 2003SE or 5.0
Before you begin the instructions below, make sure you have installed the batteries
and charged the scanner.

STEP 1: Install the Software

You must install SocketScan, but installing Connect!Agent is optional.
Should I install Socket Connect!Agent software?
Socket Connect!Agent simplifies Bluetooth by automatically setting up and
managing the Bluetooth connection. It runs in the background and requires
no interaction from the user. If you choose not to install Connect!Agent, you
will need to use your Bluetooth software to manually configure and manage
the Bluetooth connection.
1. Delete any bar code scanning software already installed in your device, including
software from other companies. Make sure the software is closed. Tap Start |
Settings | System tab | Remove Programs. Use the utility to delete the software.
2. Use ActiveSync and a serial/USB cable or cradle to make an active connection
between your mobile computing device and a host PC.
IMPORTANT: ActiveSync 4.0 or greater is required.
ActiveSync should report "Connected," and the ActiveSync icon should turn green.
3. Insert the SocketScan installation CD into the CD drive of your host PC.
6
