Sub-Zero ICB648PRO Use & Care Manual page 12

S U B - Z E R O
F R E E Z E R
A D J U S TA B L E S L I D E - O U T B I N S
The PRO 48 features two versatile, adjustable
stainless steel slide-out bins that fit neatly
under any refrigerator compartment shelf. The
glass shelves have integrated rails that make it
possible to position the slide-out bins in a
variety of locations.
To remove the slide-out bin, simply pull the
handle portion of the bin forward until it stops,
lift it up and out of the rails mounted below
the glass shelf. Refer to the illustration of the
adjustable slide-out bin below.
Adjustable slide-out bin
12
P R O 4 8 U S E & C A R E
S T O R A G E F R E E Z E R S T O R A G E
A D J U S TA B L E S H E LV E S
The adjustable shelves of the PRO 48 upper
freezer compartment are cantilevered and
100% stainless steel.
The freezer shelves are repositioned the same
way as the glass shelves in the refrigerator
compartment. To remove or adjust the freezer
shelves, first tilt the shelf up at the front, then
lift it up and out of the tracks on the rear wall
of the freezer.
To replace a shelf, insert in the tracks on the
rear wall of the freezer with the front of the
shelf raised slightly. As you push the shelf in,
lower the front of the shelf until it locks into
position.
I C E B U C K E T R E M O V A L
The automatic ice maker and stainless steel ice
bucket are located in the lower freezer drawer.
To remove the ice bucket, pull the freezer
drawer out until it stops, lift the ice bucket up
and out of the drawer. The entire lower freezer
drawer can now be used for more ice storage
if necessary.
