Sw-C Board; Jack Board; Mic Board - Icom IC-7800 Service Manual Addendum

[SW-C BOARD]

REF ORDER
NO. NO.
R1 7030003480 S.RES ERJ3GEYJ 222 V (2.2 k)
R2 7030003520 S.RES ERJ3GEYJ 472 V (4.7 k)
R3 7030003580 S.RES ERJ3GEYJ 153 V (15 k)
R4 7030003540 S.RES ERJ3GEYJ 682 V (6.8 k)
R5 7030003480 S.RES ERJ3GEYJ 222 V (2.2 k)
R6 7030003520 S.RES ERJ3GEYJ 472 V (4.7 k)
R7 7030003580 S.RES ERJ3GEYJ 153 V (15 k)
R8 7030003540 S.RES ERJ3GEYJ 682 V (6.8 k)
R9 7030003480 S.RES ERJ3GEYJ 222 V (2.2 k)
R10 7030003520 S.RES ERJ3GEYJ 472 V (4.7 k)
R11 7030003580 S.RES ERJ3GEYJ 153 V (15 k)
R12 7030003540 S.RES ERJ3GEYJ 682 V (6.8 k)
R13 7030003480 S.RES ERJ3GEYJ 222 V (2.2 k)
R14 7030003520 S.RES ERJ3GEYJ 472 V (4.7 k)
R15 7030003540 S.RES ERJ3GEYJ 682 V (6.8 k)
R51 7030003400 S.RES ERJ3GEYJ 471 V (470)
R52 7030003400 S.RES ERJ3GEYJ 471 V (470)
R53 7030003400 S.RES ERJ3GEYJ 471 V (470)
R54 7030003400 S.RES ERJ3GEYJ 471 V (470)
R55 7030003400 S.RES ERJ3GEYJ 471 V (470)
R56 7030003400 S.RES ERJ3GEYJ 471 V (470)
R57 7030003400 S.RES ERJ3GEYJ 471 V (470)
R58 7030003400 S.RES ERJ3GEYJ 471 V (470)
C1 4030011600 S.CER C1608 JB 1E 104K-T
C2 4030011600 S.CER C1608 JB 1E 104K-T
C3 4030011600 S.CER C1608 JB 1E 104K-T
C4 4030011600 S.CER C1608 JB 1E 104K-T
J1 6510021720 S.CNR 30FLT-SM1-TB
J2 6510019971 S.CNR 52808-1071
DS51 5040002930 S.LED SML-512MW T86
DS52 5040002930 S.LED SML-512MW T86
DS53 5040002930 S.LED SML-512MW T86
DS54 5040002930 S.LED SML-512MW T86
DS55 5040002930 S.LED SML-512MW T86
DS56 5040002930 S.LED SML-512MW T86
DS57 5040002930 S.LED SML-512MW T86
DS58 5040002930 S.LED SML-512MW T86
S1 2260002740 S.SW LS8J2M-T
S2 2260002740 S.SW LS8J2M-T
S3 2260002740 S.SW LS8J2M-T
S4 2260002740 S.SW LS8J2M-T
S5 2260002740 S.SW LS8J2M-T
S6 2260002740 S.SW LS8J2M-T
S7 2260002740 S.SW LS8J2M-T
S8 2260002740 S.SW LS8J2M-T
S9 2260002740 S.SW LS8J2M-T
S10 2260002740 S.SW LS8J2M-T
S11 2260002740 S.SW LS8J2M-T
S12 2260002740 S.SW LS8J2M-T
S13 2260002740 S.SW LS8J2M-T
S14 2260002740 S.SW LS8J2M-T
S15 2260002740 S.SW LS8J2M-T
S16 2260002740 S.SW LS8J2M-T
S17 2260002740 S.SW LS8J2M-T
S18 2260002740 S.SW LS8J2M-T
S19 2260002740 S.SW LS8J2M-T
S20 2260002740 S.SW LS8J2M-T
S21 2260002740 S.SW LS8J2M-T
S22 2260002740 S.SW LS8J2M-T
DESCRIPTION M.
LOCATION
B 32.7/126.7
B 30.7/122.6
B 30.7/118.1
B 30.6/125.7
B 30.6/100.1
B 30.6/97.4
B 31.9/94.7
B 31.9/101.7
B 34.8/71.3
B 35.5/69.3
B 35.5/66.6
B 32.7/84.5
B 43.1/46.9
B 49.2/44.4
B 43.1/50.6
B 38.3/124.2
B 41.2/124.2
B 37.9/107.7
B 46.6/102.1
B 43.2/98.8
B 46.6/99.4
B 48.7/89.9
B 48.7/93.3
B 28.9/94.5
B
B 32.1/71.3
B 43.5/82.4
B
B 44.2/113.1
T 36.5/123.3
T 48/123.3
T 36.5/104.8
T 48/104.8
T 36.5/94.8
T 48/94.8
T 36.5/84.8
T 48/84.8
T 36.7/129.1
T 48.2/129.1
T 36.7/118.9
T 48.2/118.9
T 36.7/100.4
T 48.2/100.4
T 36.7/90.4
T 48.2/90.4
T 36.7/80.4
T 48.2/80.4
T
T 36.7/61.2
T 36.7/52.4
T 36.5/42.7
T 61.5/42.7
T 12.2/32.4
T 74.3/27.4
T 12.2/14.7
T 75.2/14.2
T 12.2/2.3
T 75.2/2.3
T 25.7/2.3

[JACK BOARD]

H/V REF ORDER
NO. NO.
L1 6200003950
L2 6200003950
L3 6200003950
L4 6180000900
L5 6180000900
L6 6180000900
R1 7030006060
R2 7030006060
C1 4030006880
C2 4030006880
C3 4030006880
C101 4030006880
C102 4030006880
J1 6510019971
J2 6510023891
J102 6510023900
EP101 6910012350
EP102 6910012350
41.2/82
37.9/89

[MIC BOARD]

REF ORDER
NO. NO.
L1 6200003261
L2 6200003261
L3 6200003261
L4 6200003950
C1 4030006880
C2 4030006880
C3 4030006880
C4 4030007130
C5 4030006880
C6 4030006880
C7 4030006880
C8 4030007090
J1 6510000190
J2 6510019971
36.7/70
EP2 6910012350
EP3 6910012350
EP4 6910012350
EP5 6910012350
EP6 6910012350
EP7 6910015130
EP8 6910015130
EP9 6910015130
EP10 6910015130
EP11 6910012350
M.=Mounted side (T: Mounted on the Top side, B: Mounted on the Bottom side)
5 - 3
DESCRIPTION
S.COL HF50ACC 322513-T
S.COL HF50ACC 322513-T
S.COL HF50ACC 322513-T
COL LAL 03NA 101K
COL LAL 03NA 101K
COL LAL 03NA 101K
S.RES ERJ12YJ100U (10)
S.RES ERJ12YJ100U (10)
S.CER C1608 JB 1H 472K-T
S.CER C1608 JB 1H 472K-T
S.CER C1608 JB 1H 472K-T
S.CER C1608 JB 1H 472K-T
S.CER C1608 JB 1H 472K-T
S.CNR 52808-1071
CNR S-G4617#01F
CNR LGR4619-7000
S.BEA MMZ1608Y 102BT
S.BEA MMZ1608Y 102BT
DESCRIPTION
S.COL NLV32T-101J
S.COL NLV32T-101J
S.COL NLV32T-101J
S.COL HF50ACC 322513-T
S.CER C1608 JB 1H 472K-T
S.CER C1608 JB 1H 472K-T
S.CER C1608 JB 1H 472K-T
S.CER C1608 CH 1H 101J-T
S.CER C1608 JB 1H 472K-T
S.CER C1608 JB 1H 472K-T
S.CER C1608 JB 1H 472K-T
S.CER C1608 CH 1H 470J-T
CNR FM214-8SS (P)
S.CNR 52808-1071
S.BEA MMZ1608Y 102BT
S.BEA MMZ1608Y 102BT
S.BEA MMZ1608Y 102BT
S.BEA MMZ1608Y 102BT
S.BEA MMZ1608Y 102BT
S.BEA MMZ1608D 301BT
S.BEA MMZ1608D 301BT
S.BEA MMZ1608D 301BT
S.BEA MMZ1608D 301BT
S.BEA MMZ1608Y 102BT
H/V
M.
LOCATION
T 33/7.8
T 23.5/2.7
T 16.2/2
T 24.1/6.1
T 16.8/5.4
B 26.4/2.1
B 26.4/4.8
B 20.7/6.9
B 15.3/6.9
B 11.6/2.1
B 19/3.2
B 15.3/8.2
B 10.3/2.1
H/V
M.
LOCATION
B 4.5/17.8
B 2.4/12.5
B 4.5/2
B 15.2/15.1
B 8.6/16.1
B 2.8/5.5
B 14.2/12.3
B 10.1/11.2
B 1.5/5.5
B 9.6/.9
B 7.7/10.1
B 9.4/13.9
B 12.7/20.2
B 4.1/6.3
B 7.6/2
B 10.4/16
B 2.7/8.1
B 7.7/7.7
B 17.2/10.8
B 15.9/10.8
B 10.2/6.9
B 11.5/9.1
B 5.4/14.1
S.=Surface mount
