Page 1 MOCET IG7600 Smart Telephone System Administration Manual...
Page 2: Fcc Statement
IG7600 Administration Manual Environment The equipment you have purchased must not be disposed of with household waste. You should return these to your distributor if they are to replace or dispose of them in an approved recycling centre. FCC Statement...
Page 3 Electrical Powering: The IG7600 can be powered with correct power adaptor; the power adaptor must be 12V/1.5A. Any damage caused to the IG7600 as a result of using unsupported power adaptors will not be covered by the manufacturer’s warranty.
Page 4: Table Of Contents
IG7600 Administration Manual Table Of Contents Introduction ..............................2 Getting to Know the IG7600 .......................... 2 2.1 Front Panel..............................2 2.2 Rear Panel..............................2 IG7600 Voice General Features ........................2 3-Way Conference .......................... 2 Access Control for Web Page......................2 Answering Position ........................
Page 5 4.36 Volume Control ..........................2 4.37 Web Management........................... 2 Quick Installation............................. 2 5.1 Connecting the IG7600..........................2 5.2 Wizard Setup..............................2 5.2.1 WAN Setting ............................. 2 5.2.2 Secondary WAN Setting ........................2 5.2.3 LAN Setting............................2 5.2.4 Wireless Basic........................... 2 5.2.5 Internet Time.............................
Page 6 IG7600 Administration Manual 6.5.1 Basic ..............................2 6.5.2 Security............................. 2 6.5.3 MAC Filter............................2 6.5.4 Wireless Bridge..........................2 6.5.5 Advanced ............................2 6.5.6 Station Info ............................2 6.5.7 Power Saving ............................ 2 6.6 Voice ................................2 6.6.1 Phone ..............................2 6.6.2 Trunk..............................
Page 7: Introduction
The IG7600 is so easy to configure that a fully working system can be set up in minutes. Plug and Play feature allows IP phone, iPhone or Android phone with M54 App to be automatically detected and registered when they are connected.
Page 8 (2) To build a common setting file for most users. (3) To configure each phone and install them into the network. (4) To configure each interfaces and install them into IG7600. (5) And to solve the problems that users encounter during operation.
Page 9: Getting To Know The Ig7600
IG7600 Administration Manual Getting to Know the IG7600 2.1 Front Panel The front panel contains several LEDs that indicate the status of the IG7600. Figure 2-1. Front Panel of IG7600 LED Name Color Status Description POWER Red/Blue Red Flashing Application Restarting...
Page 10: Rear Panel
IG7600 Administration Manual 2.2 Rear Panel The rear panel contains the ports for the IG7600's data and power connections. Figure 2-2. Rear Panel of IG7600 Label Function RJ-45 connector: Connects the device to your cable modem, or to your ADSL Modem. It’s to connect to the remote network.
Page 11: Ig7600 Voice General Features
IG7600 supports one conference room with at most 3 participants. The voice is mixed on IG7600. PS：：：： IG7600 supports this function only when it is a new hardware version IG. Access Control for Web Page...
Page 12 IG7600 Administration Manual simultaneous calls with following functions. Auto Attendant Functions • The Auto Attendant provides an incoming caller with a customized welcome greeting and specific prompts that will describe the options available to the caller. Play the welcome greeting messages depending on the system service mode: Working, Holiday, and Temporary.
Page 13: Auto Provisioning
To make an intercom call, dial a Station number (IP Terminal, POTS) or a Voice Mail number. To make an outside call, dial a phone number. IG7600 chooses a line (PSTN line, IP trunk, another IG7600) via Call Routing Table to dial out.
Page 14: Call By Name
IG7600 Administration Manual Call By Name IG supports Call by Name now, but it is not enabled as default. We should activate it manually before we use it. Get ready for dial by name process: find the web page Voice-> Voice Mail->General->Auto Attendant->Dial by Name Code and We input a number ( for example “9“) here to use it as a dial by name code.
Page 15 “1” to listen to the current greeting to confirm if it is OK. Now IG7600 is ready for dial by name process. Incoming call to Auto attendant and transfer the call thru “dial by name”: Incoming call to IG7600 auto attendant pickup auto attendant playing “…for dial by name, please dial “9”…”...
Page 16: Call Operator (Call Attendant)
Trunk Access • IG7600 checks the field only when a call matches the associated entry. If the field is set to “Y”, the entry is valid when the trunk is accessed previously. If the field is set to “N”, the trunk isn’t accessed previously. The trunk will be accessed through Call Routing Table.
Page 17 If Priority is “Allowed”, IG7600 will check Allowed Table first, if any entry is matched IG7600 will search Denied Table then, the call can be made only when there is any matched entry found in Allowed Table and there is no any matched entry found in Denied Table.
Page 18: Call Routing
Destination defines the outbound call interface trunk 3.13 Caller ID Detection/Generation IG7600 provides the ability to detect the calling party identification provided by CO via PSTN lines or by Uplink Server via IP trunks. This data when received by the telephone carrier will be displayed on all ringing IP phones.
Page 19: Class Of Service (Cos)
Call Waiting Tone 3.17 Direct In Dialing (DID) IG7600 provides a Direct In Dialing Table for IP Trunks. It will be able to offer its individual phone number for each extension. IG7600 provides 100 entries in the Direct In Dialing Table. Each entry includes DID Number: used to check the caller ID of the incoming call.
Page 20: Direct Inward System Access (Disa)
Flash is the momentary operation of the hook-switch at the analog device, which can be deciphered by the IG7600 system in such a way that the previous call in progress is held, or placed in a status of transfer awaiting further instructions from the user.
Page 21: Ip Trunk
IG7600 Administration Manual 3.24 IP Trunk IG7600 can register up to 12 SIP Uplink Servers. The extensions may make a call to the users of the Uplink Servers, or any user in the world through the Uplink Servers. • SIP messages, including INVITE, re-INVITE, ACK, CANCEL, BYE, REGISTER, INFO, REFER and NOTIFY messages •...
Page 22: Pstn Backup
• Call Park Number • Conference Room Number 3.28 PSTN Backup In case of power failure, IG7600 automatically switches the first PSTN line to the Single-line analog phone. The other PSTN lines are not supported 3.29 Registration Server The IG7600 combines Proxy and Registrar servers in its application. For a Registrar server, it acts as the front end to the location service for a domain, reading and writing mappings based on the contents of REGISTER requests.
Page 23: Service Mode
3.31 Service Mode IG7600 provide Day and Night settings for each weekday in service mode page. It will be applied in the following function: - Answering Position: Trunk incoming call may be forwarded to different extensions according to the settings.
Page 24: System Speed Dial
Numbers are assigned in Numbering Table. The Speed Dial is only for outgoing calls. IG7600 stores up to 100 Speed Dial Numbers. In the Speed Dial Number, it’s allowed to store Phone number up to 20 digits in length. Call Restriction and Call Routing are applied and extensions may utilize only those numbers allowed based on their extension COS.
Page 25 IG7600 Administration Manual Basically in one IGW Group we demand one of the IGs works under master mode, others work under slave mode. The members in the group need to be found by each other on the internet make sure about it before you use this function. When an IGW Group is build up successfully we can choose IGW Group as a Call Routing way in Call Routing configuration page.
Page 26 IG7600 Administration Manual Entity-2 Entity-1 IG-A Internet IG-B IG-C Entity-4 Entity-5 Entity-6 Entity-3 IG-A IG-B IG-C Operation Support Entity-1 Entity-3 Entity-1 call/hold/retrieve Entity-3 Entity-1, Entity-3 Entity-1 transfer/forward Entity-2 to Entity-2 Entity-3 Entity-1, Entity-3 Entity-1 transfer/forward Entity-3 to Entity-2 Entity-2 Entity-1...
Page 27 IG7600 Administration Manual With this setting IG A’s Ext 299 can transfer a call from 201 to IG B’s Ext 101 by dialing 101 directly. Get Ready [IG7600 programming—IGW Group] IGW Name: The name of IG. It will be referred for the other IGs.
Page 28 IG7600 Administration Manual [IG7600 programming—Call Routing Rule] To fulfill the condition of the Sample, IG A has one Call routing rule to IGW Group member -- IG B whose settings are like this figure shows: when the dialing is from 101 to 199 and is exactly a 3 digit number, IG A Transfer the dialing to IG B directly without deleting any of the digit.
Page 29 IG7600 Administration Manual Daylight Saving Time Default Set Direct In Dialing (DID) Direct Inward System Access (DISA) Emergency Call Extension Password Fax/Modem Flash Analog Port (SLT) Flash – Recognition IP Trunk Message Waiting Indication (MWI) Music on Hold Numbering Plan...
Page 30: Wizard Setup
Volume Control Web Management 3.38 Wizard Setup The IG7600 has a setup Wizard that provides the system administrator with a series of step-by-step operations. You can get in the wizard process from the entry shown on the main page. When you start setup wizard you can configure the corresponding settings step by step.
Page 31: Ig7600 Voice Extension Features
IG7600 Administration Manual IG7600 Voice Extension Features IG7600 follows SIP standard to serve SIP phones. Basically, telephone features that meets SIP standard can be applied in IG7600. Smart Phone M54(-i) , M22, M62 and IP2061 phone support many phone features. But...
Page 32: 3-Way Conference
The Conference feature allows the user to connect two calls into a single conversation. IP2061/M22/M62 can establish a 3-way conference on the phone. M54(-i) needs to use IG7600’s resource to establish the 3-way conference call. IG7600 supports 1 set of 3-way conference for M54(-i).
Page 33: Auto Hold
For the Call Fork destination, IG7600 supports to have the second Fork destination. If the first destination is non-existed or busy, make the forking call to the second Forking Destination.
Page 34: Call Hold
IG7600 Administration Manual *24 + Type + * + (PSWD) + * + Outside Number To disable, dial **24. Follow Me Call Forward: Forwards calls at your extension to the extension where you are currently working. To enable, dial *25 + Type + Ext No + * + Password To disable, dial **25 + Ext No + * + Password These Call Forward features can also be set / cancelled in web page of IP2061/M22/M62.
Page 35: Call Pickup – Individual
IG7600 Administration Manual by inputting the Trunk Access Code 701. Meanwhile, other extensions can also pick up this trunk call by pressing the IDLE Individual Call Park key and input the extension number “101”. 4.11 Call Pickup – Individual You may answer the calls at another specified extension. The feature allows you to easily access calls ringing via the feature access code.
Page 36: Do Not Disturb (Dnd)
Direct FWD > DND > Busy/No Answer FWD. 4.18 DSS/EDM IG7600 supports to provide the status of the extensions and trunk lines. The status can be shown on the LED of IP2061/M22/M62’s flexible keys. For IP2061, M22 and M62, they support EDM modules that can have 24 more keys.
Page 37: Hold Reminder
30 minutes. Live Recording feature isn’t applied in the conference call. 4.25 Multi-Line Appearance IG7600 provides PSTN line and IP line status to IP2061/M22/M62, it also provides PSTN line or IP Line status to M54(-i). Trunk LED: Dark –...
Page 38: Mute
4.28 Paging (All/Group) / Paging Answer Paging function can be initiated from any extension in the IG7600. Dialing a Paging Group Directory number allows an extension to broadcast a page to all assigned members of the selected paging group.
Page 39: Plug & Play
When IP2061/M22/M62 and IG7600 connect to the same Router, IG7600 will assign a valid extension number to the IP2061/M22/M62 also. IG7600 will do Plug & Play with M54(-i) only when the pairing button is pushed. 4.33 Reminder Tone Play stutter dial tone to remind the user that DND or DCFW is enabled at your extension.
Page 40: Web Management
IG7600 Administration Manual 4.37 Web Management The IP2061/M22/M62 is supported two-level web management. The Administrator has several pages to configure the IP phone. User is able to configure personal information by himself. User level is not including these two pages – software update, SIP configuration.
Page 41: Quick Installation
IG7600. Use of a different adapter may result in product damage. (4) Now that you have connected the IG7600 to your network, you are ready to begin setting it up. The Setup Wizard will take you through all necessary steps to help you to configure the IG7600 easily.
Page 42 IG7600 Administration Manual Figure 5-1. Wan Settings (Static IP mode) The Dynamic Host Configuration Protocol (DHCP) is an Internet protocol for automating the configuration of computers that use TCP/IP. DHCP can be used to automatically assign IP addresses, to deliver TCP/IP stack configuration parameters such as the subnet mask and default router, and to provide other configuration information.
Page 43 Wan Settings (PPPoE mode) 5.2.2 Secondary WAN Setting IG7600 supports secondary WAN which is dedicated for IP Trunk. If you check “Enable Secondary WAN” then it will turn LAN port into secondary WAN port. And you still can use wireless interface for LAN access. Regarding secondary WAN settings, please refer to 5.2.1 WAN settings.
Page 44 Wireless Basic 5.2.5 Internet Time The page allows you to configure the NTP time server, so the IG7600 can have correct system time. It is useful such as reviewing the System Log. (Figure 5-6). Copyright 2013 Tecom, Co. LTD. All rights reserved...
Page 45: Wizard Setup Finished
Then the system will reboot as shown below.(Figure 5-7) Figure 5-7. Wizard Setup finished Congratulations! The wizard setup of the IG7600 is complete. For additional details, advanced configuration, or any other questions, refers to the next chapter. Copyright 2013 Tecom, Co. LTD. All rights reserved...
Page 46: Establish The Connection
Connect the IG7600 to PC. The default LAN IP of the IG7600 is 192.168.123.1. The default WAN IP of the IG7600 depends on upper router’s DHCP server. For web login, the default user name is “admin1234”; the default password is “adminxxxxxx”.
Page 48: Statistics
IG7600 Administration Manual 6.3 Device Info This information reflects the current Status of IG7600 connection. It includes the following topics: Summary Statistics Route DHCP 6.3.1 Summary In the page (Figure 6-2) you can get the information reflects the current software version and connection status.
Page 49 IG7600 Administration Manual Figure 6-4. Device Info – Statistics – WAN 6.3.3 Route In this page you can get the IP route information of the device. (Figure 6-5) Figure 6-5. Device Info – Route 6.3.4 ARP This page shows an ARP table which maps IP network addresses to hardware addresses used by data link level protocol.
Page 50 Figure 6-6. Device Info – ARP 6.3.5 DHCP This page shows a DHCP Leases table which shows the all used IP addresses under IG7600’s DHCP Server. (Figure 6-7) Figure 6-7. Device Info – DHCP Copyright 2013 Tecom, Co. LTD. All rights reserved...
Page 51: Advanced Setup
Upnp 6.4.1 WAN There are three modes that you can give WAN IP address to IG7600: Static IP mode, DHCP mode and PPPoE mode. You can also enable or disable Firewall. Network Address Translation (NAT) allows you to share one public WAN IP address for multiple computers on your LAN side.
Page 52 IG7600 Administration Manual The Dynamic Host Configuration Protocol (DHCP) is an Internet protocol for automating the configuration of computers that use TCP/IP. DHCP can be used to automatically assign IP addresses, to deliver TCP/IP stack configuration parameters such as the subnet mask and default router, and to provide other configuration information.
Page 53: Secondary Wan
IG7600 Administration Manual 6.4.2 Secondary WAN IG7600 supports secondary WAN which is dedicated for IP Trunk. If you check “Enable Secondary WAN” then it will turn LAN port into secondary WAN port. And you still can use wireless interface for LAN access. Regarding secondary WAN settings, please refer to 6.4.1 WAN settings.
Page 54 IG7600 Administration Manual Figure 6-11. Advanced – LAN 6.4.4 NAT It’s separated into three parts: Virtual Servers, Port Triggering, and DMZ Host. 6.4.4.1 Virtual Servers Virtual Server allows you to direct incoming traffic from WAN side identified by Protocol and External port to the internal server with private IP address on the LAN side. The “Internal Port”...
Page 55 LAN initiates a TCP/UDP connection to a remote party using the "Trigger Ports". IG7600 allows the remote party from the WAN side to establish new connections back to the application on the LAN side using the "Open Ports".
Page 56 Figure 6-15. Advanced – NAT – Port Triggering – Add 6.4.4.3 DMZ Host IG7600 will forward IP packets that do not belong to any of the applications configured in the Virtual Servers table to the DMZ host computer. Enter the computer's IP address and click "Save Settings"...
Page 57: Security
IG7600 Administration Manual Figure 6-16. Advanced – NAT – DMZ 6.4.5 Security It supports IP Filtering Setup. It’s separated into two parts: Outgoing and Incoming. 6.4.5.1 IP Filtering - Outgoing It allows the administrator to create a filter rule to identify outgoing IP traffic by specifying a new filter name.
Page 58 By default, all incoming IP traffic from the WAN will be blocked if it is not consistent with the incoming filter rules. In fact, IG7600 has opened some necessary ports such as web port, sip port, and rtp port, to make sure that voice application can communicate well.
Page 59: Parental Control
It’s separated into two parts: Time Restriction, and URL Filter. 6.4.6.1 Time Restriction The administrator can add time restriction to a special LAN device connected to IG7600. The “Browser's MAC Address” automatically displays the MAC address of the LAN device where the browser is running. To restrict other LAN device, click the "Other MAC Address"...
Page 60 IG7600 Administration Manual Figure 6-22. Advanced – Parental Control – Time Restriction – Add 6.4.6.1 URL Filter The administrator can add 100 entries maximum to include/exclude the URL address and Port number. Choose “Include” means the user can only connect to the URL that you add.
Page 61: Quality Of Service
IG7600 Administration Manual Figure 6-24. Advanced – Parental Control – URL Filter – Add 6.4.7 Quality of Service It’s separated into two parts: DSCP Marking, and Bandwidth Control 6.4.7.1 DSCP Marking IP QoS is applied to the traffic from LAN to WAN; the traffic from WAN to LAN will not be applied.
Page 62: Routing
IG7600 Administration Manual all voice packets have been queued in the highest IP packets, and the others have been queued in the normal IP packets if they have not been set in the traffic class rule. Figure 6-26. Advanced – Quality of Service – Bandwidth Control 6.4.8 Routing...
Page 63: Dynamic Dns
The Dynamic DNS service allows you to alias a register domain name to a dynamic IP address. It allows IG7600 to be more easily accessed from various locations on the Internet. Click “Add” or “Remove” to configure Dynamic DNS. (Figure 6-29) Figure 6-29.
Page 65: Upnp
It’s used to enable or disable the universal plug and play function. (Figure 6-33) Figure 6-33. Advanced – Upnp 6.5 Wireless Use the Wireless screen to configure the IG7600 for wireless access. It is separated into 7 parts: Basic Primary Additional Copyright 2013 Tecom, Co.
Page 66: Security
The max clients are 16. (Figure 6-34) Figure 6-34. Wireless – Basic – Primary 6.5.1.2 Additional IG7600 supports to configure 3 additional Wireless networks. Each SSID can have different name and configurations. (Figure 6-35) Copyright 2013 Tecom, Co. LTD. All rights reserved...
Page 68 User can use Push-Button or PIN to configure the connection with IG7600. In Push-Button method, IG7600 and client must press the WPS button to establish connection. In PIN mode, when the Access Point Pin is used, client can input the PIN to establish the connection.
Page 69 IG7600 Administration Manual Figure 6-37. Wireless – Security – 1 Figure 6-38. Wireless – Security – 2 WEP Encryption: Selecting Disabled disables WEP data encryption. Selecting Enabled enables WEP data encryption and requires that a valid network key be set and selected unless 802.1X is enabled.
Page 70 IG7600 Administration Manual physical layer. WEP is designed to make up for the inherent security in wireless transmission as compared to wired transmission. Network Key: Set whether shared key authentication is required to associate. A valid network key must be set and selected if required.
Page 71 All devices in your wireless network must use the same channel in order to function correctly. Auto Channel Timer: The IG7600 should search for the best wireless channel in this period (minute). 802.11n/EWC: Automatic or disable 802.11n support.
Page 72 IG7600 Administration Manual Control Sideband: Specify if the extension channel should be in the “Upper” or “Lower” sideband. 802.11n Rate: Set the Physical Layer rate. These rates are only applicable when the”802.11n/EWC” is configured as “Auto”. 802.11n Protection: In “Auto” mode, the wireless devices use RTS/CTS to improve 802.11n performance in mixed 802.11g/802.11b networks.
Page 73 IG7600 Administration Manual Figure 6-42. Wireless – Advanced RTS Threshold: This value should remain at its default setting of 2347. The range is 0~2347 bytes. Should you encounter inconsistent data flow, only minor modifications are recommended. If a network packet is smaller than the packet RTS threshold size, the RTS/CTS mechanism will not be enabled.
Page 74: Voice
IG7600 Administration Manual WMM (Wi-Fi Multimedia): Feature that improves the experience for audio, video and voice applications over a Wi-Fi network. WMM No Acknowledgement: When the “WMM No Acknowledgement" is enabled, the receiver will not acknowledge received packets during wireless packet transmit. It is suitable in the environment where communication quality is good and interference is weak.
Page 75: Trunk
IG7600 Administration Manual 6.6 Voice Use the Voice screen to configure the IG7600’s voice related parameters. It allows system administrator to configure the following topics: Phone Phone Extension Video Doorphone Settings Security Card Registration Programmable keys Trunk IP Trunk Trunk DID...
Page 76 Mac Binding: If a phone number is assigned by Plug-and-Play, the number is bound to the extension’s Mac address. You can also add Mac binding at IG7600’s web page. Copyright 2013 Tecom, Co. LTD. All rights reserved...
Page 77 Minimal Expire: Minimal registered period of IP phone. SIP Port: The IG7600 listens for requests on the SIP port. This port is used for UDP application and 5070 is its default value. The port number cannot be the same as the “Local SIP Port for IP Trunk”...
Page 78 IG7600 Administration Manual Figure 6-47. Voice – Phone – Door Settings Door Phone: Door Phone Numbers. Status: Door Phone Status(Disconnected/Closed/Opened) Start Time/ End Time: During this period Door Phone should turn on its LED light. Open Time: This is the time that door phone delays before open the door when receiving an open door request.
Page 79 This page allows you to configure the default settings for IP phone’s programmable Keys. While a new-allocated IP phone is registering to IG7600, IG7600 will send these settings to the phone. You can select Extension, Trunk, Call Park, Feature key, Do Not Disturb, Live Record, Virtual Mailbox and Others to these Programmable keys.
Page 80 IG7600 Administration Manual Auto Hold: When you are using a line and press another key, IG7600 can hold the original line. Select “Enable” to open this function. Copyright 2013 Tecom, Co. LTD. All rights reserved Page 74 of 74...
Page 81 IG7600 Administration Manual Figure 6-49. Voice – Phone – Programmable keys When there are IP phones registered to IG7600, you can configure their key setting. In Extension List, press “Configure” to configure keys of the specific phone. Follow Gateway Settings: Use default IG7600 key setting for the IP phone. If you check the checkbox, all the input operations are disabled, and the Ext’s...
Page 83 IG7600 Administration Manual Figure 6-50. Voice – Phone – Extension Linekey-Configure 6.6.2 Trunk Use the Trunk screen to configure the PSTN/IP Trunk function related parameters. It is separated into 7 parts: IP Trunk Trunk DID Trunk Group Answering Position Call Routing Call Restriction Copyright 2013 Tecom, Co.
Page 84 IG7600 Administration Manual Emergency Numbers 6.6.2.1 IP Trunk This page allows you to configure the Proxy and Register server of IP Trunks; up to 12 lines of IP Trunk are supported. (Figure 6-51, Figure 6-52) Figure 6-51. Voice – Trunk – IP Trunk – 1 Figure 6-52.
Page 85 Trunk 1 to 5. It means it can have 5 concurrent calls in the account. Server Type: If “Server Type” is CHTM, and if the Caller ID of the incoming Trunk call exists, IG7600 will use the Caller ID in From and P-Asserted-Identify header in the outgoing IP Trunk call.
Page 86 Choose “Enable” to use this function. Transmission Timer: If an outgoing trunk call matches more than one entries in Call Routing Table, if the former matched entry gets timeout after this specific seconds, IG7600 will try the next one. 6.6.2.2 Trunk DID The table offers its individual phone number for each extension (Figure 6-53).
Page 87 You can choose the search order to use the specified access priority. For example, when you choose IP First and increase, IG7600 will try to find an available IP Trunk and search from the first IP Trunk in the Group.
Page 88 IG7600 Administration Manual Figure 6-55. Voice – Trunk – Trunk Group – 2 6.6.2.4 Answering Position Figure 6-56. Voice – Trunk – Answering Positions This page allows you to configure an answering position for each Trunk line's incoming call including PSTN trunk and IP Trunk. You can choose Auto Attendant, Operator, UCD Group or manually configure the target extension phone number on Day/Night basis.
Page 89 Table Type decides into which table this entry will be added. Priority decides which table will be checked first. If Priority is “Allowed”, IG7600 will check Allowed Table first, if any entry is matched IG7600 will search Denied Table then, the call Copyright 2013 Tecom, Co. LTD. All rights reserved...
Page 90 Denied Table. If Priority is “Denied”, IG7600 will check Denied Table first, if any entry is matched IG7600 will search Allowed Table then, the call will be forbidden only when there is any matched entry found in Denied Table and there is no any matched entry found in Allowed Table.
Page 91 End extension: It’s the end phone number of system internal extension. All valid extension number can’t be greater than it. If receiving an IP2061/M22/M62’s Plug & Play request, IG7600 will allocate the first unused number from this limited region. FXS Phone Number: It determines the FXS phone number.
Page 92 You can dial these numbers directly to access PSTN trunks. Start IP Trunk number: IG7600 provides 12 IP Trunk lines at most. Every line has its own internal alias number. You can dial these numbers directly to access IP Trunks.
Page 93 IG7600 Administration Manual Start Paging Group number: 3 paging groups are defined in IG7600. If dialing a Paging Group number, the call will page to predefined internal IP phones. It can also select the Range like All Paging Number. The maximum phones for each paging group are 49.
Page 94 (Figure 6-64) Figure 6-64. Voice – System – Speed Dial Start Call Park Number: IG7600 supports to park 4 trunk calls maximum. The Call Park number can be programmed on the line keys. Start Conference Room Number: Conference Room Number allows the users to build a conference conversation.
Page 95 IG7600 Administration Manual Figure 6-65. Voice – System – Service Mode Figure 6-66. Voice – System – Service Mode 6.6.3.3 Transmission This page allows you to configure the Audio, FXS, and FXO settings. Click “Save Settings” button to save the new configuration. (Figure 6-67) Copyright 2013 Tecom, Co.
Page 97 RFC2833 Payload: It’s used as the default RFC2833 payload type when making the outbound calls. DTMF Type: In IG7600, there are two methods for transmitting DTMF tone. Select RFC2833 Method, the DTMF tone will be transmitted by event packet. Select SIP-INFO Method, the DTMF tone will be represent in SIP INFO Message.
Page 98 Ring Abandon Time: It specifies the maximum time between valid ring signals from the CO/PBX. If the duration between rings exceed the Ring Abandon time, IG7600 stops ringing the destination(s) and the port returns to idle. The timer range is 1 to 10 seconds on 1 second increments.
Page 99 IG7600 Administration Manual Figure 6-68. Voice – System – SMDR Figure 6-69. Voice – System –SMDR – View SMDR The “PSTN Outgoing Call Duration Start Time” is used to estimate whether the PSTN outgoing call to be recorded. If the duration is less than it, the call won't be recorded. If log mode is configured, the specified SMDR record will be sent to local or/and remote log server.
Page 100 This page shows the Call Log for incoming call to UCD group. (Figure 6-71) Figure 6-71. Voice – System – UCD Call Log 6.6.4 Voice Mail IG7600 provides a built-in Auto Attendant and Voice Mail System. It is separated into 7 parts: General...
Page 101 IG7600 Administration Manual The configurable items for each part would be described in the following. 6.6.4.1 General This page allows you to configure the general settings of the auto attendant and voice mail. Auto Attendant: (Figure 6-72) Admin Password: The password of administrator.
Page 102 IG7600 Administration Manual Figure 6-72. Voice – Voice Mail – General – 1 Figure 6-73. Voice – Voice Mail – General – Single Digit Table Copyright 2013 Tecom, Co. LTD. All rights reserved Page 96 of 96...
Page 103 Max recording time: The range of recording time is form 1 to 30 minutes. Silence detection for VM recording: Set “Enable” of this item will do the silence detection in VM recording. If “silence” is detected, IG7600 will terminate the recording and release the line. It doesn’t work when AA’s codec is G.729.
Page 104 IG7600 Administration Manual Figure 6-75. Voice – Voice Mail – Phone Extension The following items will be configured in the Extension Configuration (Figure 6-76, Figure 6-77): Voice Mail: Enable/Disable. To disable this item, there is not allowed to listen to the message from outside party.
Page 105 Figure 6-77. Voice – Voice Mail – Phone Extension – Distribution Lists 6.6.4.3 Virtual Extension IG7600 provides 50 Virtual Mailboxes. These Virtual Mailboxes can be used by the members not works in the office, or as a secondary mailbox (Figure 6-78).
Page 106 IG7600 Administration Manual Figure 6-78. Voice – Voice Mail – Virtual Extension Figure 6-79. Voice – Voice Mail – Virtual Extension Configuration 6.6.4.4 Update MOH File The Music On Hold (MOH) could be uploaded from the Local PC side. Click the “Browse”...
Page 107 IG7600 Administration Manual Figure 6-80. Voice – Voice Mail – Update MOH File 6.6.4.5 Update Voice File The voice files could be uploaded from local PC side. These voice files are compressed in Linux System. It allows a “.tar”, “.tgz” or “.tar.gz” compressed format file. (Figure 6-81) Figure 6-81.
Page 108 IG7600 Administration Manual Figure 6-82. Voice – Voice Mail – Holiday 6.6.4.7 Advanced This page allows you to browse, upload or download voice files through IG7600’s ftp server. (Figure 6-83) Figure 6-83. Voice – Voice Mail – Advanced 6.6.5 NAT Traversal If IG is put behind a Router, you need to configure this page to enable NAT Traversal.
Page 109 IG7600 Administration Manual Figure 6-84. Voice – NAT Traversal – 1 Figure 6-85. Voice – NAT Traversal - 2 The following items will be configured in the NAT Traversal page: NAT Traversal Enable: Enable/Disable. IG can work properly if it’s pub behind NAT only when it’s enabled.
Page 110 Please be noted that “Always” RTP Relay by IG7600 will occupy more network bandwidth and CPU loading of IG7600, so it is not chosen as default mode. But if you meet any situation that leads to no audio or one way audio issue, you can try to change it to “Always”...
Page 111 IG7600 Administration Manual Note: When do you need this function? If IG has a public IP for remote EXTs to reach there is NO NEED to use NAT Traversal. When IG works under the public network, and has a domain name, there is NO NEED to use NAT Traversal either.
Page 112 Save SIP packets: If it’s checked, IG7600 will record SIP packets sent to or received from IP2061/M22/M62/M54(-i). Save IP Trunk SIP packets: If it’s checked, IG7600 will record SIP packets sent to or received from each IP Trunk. Download Log: You can download maintenance log to your local PC by pressing this button.
Page 114: Upgrade Phone Software
6.7.1.1 Backup Click “Backup Settings”; you may save your IG7600’s configurations to a file on your PC. The backup file is a compress file (.tar). It includes System Configuration file, backupsettings.conf, and the individual extension’s voicemail configuration files (.ini) (Figure 6-88) Figure 6-88.
Page 115: Diagnostics
IG7600 Administration Manual Figure 6-89. Management – Settings – Update 6.7.1.3 Restore Default You can choose restore Voice Files or Default Settings or Restore All in the drop-down menu. Click “Restore” to restore selected default settings. This would be helpful when the voice files or settings are messed up.
Page 116 6.7.3.1 Internet Time This page allows you to configure the Internet time setting. You can choose the “Automatically synchronize with internet time servers”. So the IG7600 can synchronize its system time with NTP time server automatically (Figure 6-92). When you choose “Manual Date and Time Settings”, you can manually configure the date and time settings (Figure...
Page 117 IG7600 Administration Manual Figure 6-93. Management – Time Setting – Internet Time – Manually 6.7.3.2 Daylight Saving Time This page allows you to configure the Daylight Saving Time (DST) which supports auto adjustment for daylight saving time. Click “Save Settings” button that you can save the new configuration.
Page 118 Address access control, and password for user, support, and administrator. 6.7.4.1 Service Port This page allows you to change the IG7600's web port, ftp port, tftp port, ssh port and telnet port. And they will take effect after reboot. (Figure 6-96) Figure 6-96.
Page 119 IG7600 Administration Manual 6.7.4.2 Services A Service Control List enables or disables services from being used. (Figure 6-97) Figure 6-97. Management – Access Control –Services 6.7.4.3 IP Addresses If the Access Control mode is enabled, permits access to local management services from IP addresses contained in the Access Control List.
Page 120 Administrator has unrestricted access to change and view configuration of your IG7600. The Support is used to allow an ISP technician to access your IG7600 for maintenance and to run diagnostics. The User can access the IG7600, view configuration settings and statistics, as well as, update the router’s software.
Page 121 IG7600 Administration Manual 6.7.6 IP Camera IG7600 now provide 8 entries for IP Camera, You can either add IP Cameras automatically when you are configuring a tecom special supported IP Camera, or manually add an ordinary one. (Figure 6-101) Figure 6-101.
Page 122 IG7600 Administration Manual to process the software update. NOTE: The upgrade process takes about 5 minutes to complete, and your IG7600 will reboot. (Figure 6-103) Figure 6-103. Management – Upgrade Software 6.7.8 Upgrade Phone Software Upgrade Phone Software page is for you to manage your IP Phones’ software, when the IP Phone Extensions’...
Page 123 IG7600 Administration Manual Door Phone to upgrade its firmware using the image we stored. There are three FWs for Door Phone, one for voice part upgrading, and two for video part upgrading. You can delete the firmware if you don’t want to use it.(Figure 6-105) Figure 6-105.
Page 124 6.7.11 Reboot Figure 6-107. Management – Save/Reboot Click “Reboot” to reboot the IG7600. The IG7600 would automatically save the configuration before reboot, so that modified settings would take effect after reboot. (Figure 6-107) Copyright 2013 Tecom, Co. LTD. All rights reserved...
Page 125 This page provides the following information to users: (Figure 6-108, 6-109) The network connection information on the net. The status of IG7600's PSTN Line. The status of IG7600’s IP Trunk Line. The status of IG7600’s AA Line. The status of IG7600’s FXS.
Page 126 Diagnostics - Missed Voice Files 6.9 Logout Press “Logout”, you can logout the IG7600 web configuration page. 6.10 Web UI Language Move your mouse to the upper right corner of the webpage, a list will pop up to show the languages you can choose.
Page 127: Appendix 1: Product Summary
IG7600 Administration Manual Appendix 1: Product Summary TCP/IP Protocols IP Protocol (791) ARP (RFC 826) / RARP (RFC 903) ICMP (RFC792) TCP (RFC 793) UDP (RFC 768) SNTP HTTP Telnet IP Address Assignment Static Dynamic Subnet Mask PPPoE Client (RFC 2516)
Page 128: Configuration Management
IG7600 Administration Manual G.168 Echo Cancellation Voice Codec: G.711u, G.711a, G726-16, G726-24, G726-32 and G.726-40 (G.729a optional) Support FAX/modem tone detection and auto-fallback to G.711 T.38 Digital Audio Codec: G.711 a-law/µ-law 64Kbps, G.729 SIP Call Offer /Answer: Codec auto capacity exchange Echo Cancellation: G.168 for each voice line...
Page 129: Language Support
IG7600 Administration Manual Language Support English (North America) – default LED Status LED Name Color Status Description POWER Red/Blue Red On Firmware updating Blue System booting up Flashing Blue On System initialized and running Power off WIRELESS Blue Wireless LAN is active...
Page 130: Appendix 2: Feature Access Codes
Appendix 2: Feature Access Codes The Feature Access Codes are applied in IP2061/M62/M22 Phones, M54 Smart Phones and FXS phone only. It’s to activate/cancel some IG7600 user-specified functions. These Feature Access Codes are used when the phone is at idle state.
Page 131: Do Not Disturb
IG7600 Administration Manual To Activate *25 + Type + Ext No + * + Password To Cancel **25 + Ext No + * + Password Call Fork When extension gets an incoming call, the extension gets ringing. It rings another extension or rings an outside destination simultaneously.
Page 132: Reset To Default
Reset all feature buttons to IG7600’s setting. *68 + (Password) Reset To Default Selected IG7600 extension features can be returned to default setting. *69 + (Extension/Administrator password) Feature Key Programming To program the line keys as a PSTN, IP Trunk, Trunk Group number, Call-Park number or Extension number.
Page 133: Call Waiting
IG7600 Administration Manual Agent Log On/Off It can control the status in an UCD group. To Activate (Log On) To Cancel (Log Off) **91 Phone Lock/Unlock You can use the Lock feature to prevent unauthorized trunk calls from being made from extension.
