Summary of Contents for Mocet IP3032
- Page 1 How to Find the MAC Address How to Set the Configuration Server How to Restore to Factory Default Mocet IP3062 & IP3062HD How to Find the IP Address How to Find the MAC Address How to Set the Configuration Server...
- Page 2 Press the “Menu” button. Use the navigation arrows and highlight option 3, “Information.” Then Press “OK.” Scroll to option 9, which will display the IP Address. How to Find the MAC Address Press the “Menu” button. Use the navigation arrows and highlight option 3, “Information.” Then Press “OK.” Scroll to option 5, which will display the MAC Address.
- Page 3 When prompted, enter your user name and password. By default the user name is “admin” and the password is “1234.” From the home page of the GUI, click on the “SW Upgrade” tab at the top. Then next to “Auto Provisioning Settings” on the left, fill out the “APS Server” field to your PBX. Generally this would be an IP Address, such as 10.10.0.1 in our example.
- Page 4 How to Restore to Factory Default Press the “Menu” button.
- Page 5 Then scroll to option 5, which is “Reset to Default.” Press “OK.” Lastly, select your Reset Type. Option 3 is “Reset All.” Press “OK” and you will be prompted with a screen to confirm your selection. Mocet IP3062 & IP3062HD...
- Page 6 How to Find the IP Address Press the “Menu” button.
- Page 7 Use the navigation arrows and highlight option 3, “Information.” Then Press “OK.” Scroll to option 13, which will display the IP Address. How to Find the MAC Address Press the “Menu” button. Use the navigation arrows and highlight option 3, “Information.” Then Press “OK.”...
- Page 8 Scroll to option 5, which will display the MAC Address. How to Set the Configuration Server Enter the IP Address into a local web browser address field. When prompted, enter your user name and password. By default the user name is “admin” and the password is “1234.” From the home page of the GUI, click on the “SW Upgrade”...
- Page 9 How to Restore to Factory Default Press the “Menu” button. Use the navigation arrows and highlight option 2, “Admin Setting.” Then Press “OK.”...
- Page 10 You will then be prompted to enter your Admin Password. This is “1234” by default. Then scroll to option 7, which is “Reset to Default.” Press “OK.” Lastly, select your Reset Type. Option 3 is “Reset All.” Press “OK” and you will be prompted with a screen to confirm your selection.
