Unpacking and Inspection
Connection Area (Under Control Pad)
Figure 2-4. Customer Connection Area/Loose Parts Location
Figure 2-4 illustrates the following:
9.
Customer connection area (beneath and behind the control pad)
•
• Fuel regulator
• Battery compartment
• Location of Loose Parts shipped
Main AC/Control Wiring
Conduit Hole (3/4 inch) with Cap Plug
Fuel Inlet Connection
10
Fuel
Regulator
Battery Compartment
Conduit Hole (1-1/4 inch) with Cap Plug
Figure 2-5. Generator Back View
Loose Parts
MAIN AC/Control Wiring
Base Fascia (If Equipped)
Installation Guidelines for Air-Cooled Generators
