Unpacking and Inspection
2.3 — Unpacking
Remove shipping carton. See Figure 2-1.
1.
Remove four bolts with crating clamps. Carefully lift the generator off the wooden pallet. Do NOT drag the gener-
2.
ator off the pallet or damage to the base will occur. See Figure 2-2.
Access Panel
Pallet
8
Figure 2-1. Unpack Generator
Lid
Front
Crating Clamps (4)
Figure 2-2. Remove Crating Clamps
15 kW
Generator
15 kW
Installation Guidelines for Air-Cooled Generators
Wooden
Frame
