DANGER
Only qualified electricians or contractors should
!
attempt such installations, which must comply
strictly with applicable codes, standards and
regulations.
1.1

UNPACKING/INSPECTION

After unpacking, carefully inspect the contents
for damage.
• This standby generator set has been factory sup-
plied with a weather protective enclosure that is
intended for OUTDOOR INSTALLATION ONLY.
• This standby generator set is packaged with an
automatic transfer switch with built in load center.
The combination transfer switch and load center is
pre-wired with a two foot and 30 foot conduit.
Circuit breakers for emergency circuit connections
are included.
• This UL listed, 2-pole switch is rated at 100 AC
amperes at 250 volts maximum. This transfer
switch is for indoor use only.
If this generator is used to power electrical load
circuits normally powered by a utility power
source, it is required by code to install a trans-
fer switch. The transfer switch must effectively
isolate the electrical system from the utility dis-
tribution system when the generator is operat-
ing (NEC 701). Failure to isolate an electrical
system by such means will result in damage to
the generator and also may result in injury or
death to utility power workers due to backfeed
of electrical energy.
If any loss or damage is noted at time of delivery, have
the person(s) making the delivery note all damage on
the freight bill or affix his or her signature under the
consignor's memo of loss or damage.
If loss or damage is noted after delivery, separate the
damaged materials and contact the carrier for claim
procedures.
"Concealed damage" is understood to mean damage
to the contents of a package that is not in evidence at
the time of delivery, but is discovered later.
4
Generac
®
Power Systems, Inc.
Section 1 — General Information
Air-cooled 7 kW Generator
1.2

PROTECTION SYSTEMS

Unlike an automobile engine, the generator may have
to run for long periods of time with no operator pres-
ent to monitor engine conditions. For that reason, the
engine is equipped with the following systems that
protect it against potentially damaging conditions:
1. Low Oil Pressure Sensor
2. High Temperature Sensor
There are LED readouts on the control panel to noti-
fy personnel that one of these faults has occurred.
There is also a "System Set" LED that is lit when all
of the conditions described in Section 1.3 are true.
1.3
SYSTEM SET LED

1.3.1 7 KW UNIT

1. The AUTO/OFF/MANUAL switch is set to the
AUTO position.
2. The utility voltage being supplied to the unit is
being sensed by the PCB. If the utility sense volt-
age is not connected to the unit or if it is below
168 volts AC, the system set LED will flash rap-
idly. This indicates that if the AUTO/OFF/MANU-
AL switch is placed in the AUTO position, the
generator will start.
3. The NOT IN AUTO dip switch is set to the OFF
position on the control board.
4. No alarms are present, for example, low oil pres-
sure, high temperature, etc.
3. Overcrank
4. Overspeed
