- Page 1 OWNER’S MANUAL ROBOKING Before using, please carefully read the Safety Precautions pages to allow for safe operation of the product. After reading this manual, please keep it in an easily accessible location. VR626** Ser. VR647** Ser. VR627** Ser. VR646** Ser. www.lg.com...
-
Page 2: Location Search Function
FEATURES Corner Master By having adopted a brand new concept design that is appropriate for walls, the Robot Cleaner's cleaning performance is incredibly efficient. Learning Mode The Robot Cleaner is capable of memorizing the cleaning environment via its Smart Operation feature for smarter cleaning. Turbo Mode In the Turbo mode, the Robot Cleaner operates the suction motor and the brushes at a greater speed giving cleaner results. -
Page 3: Table Of Contents
CONTENTS BEFORE USING ADDITIONAL INFORMATION Safety precautions 36~38 Troubleshooting Included with product Before you call for service Parts description 10~11 Button functions Display status information REFERENCE Before you start Product specifications Overview Reference items METHOD OF USE How to install the home station How to turn the Robot Cleaner power supply on &... -
Page 4: Safety Precautions
3. If the supply cord is damaged, it must be replaced by LG Electronics Service Agent in order to avoid a hazard 4. This appliance can be used by children aged from 8 years and above and persons with reduced physical,... - Page 5 Failure to follow this warning can cause electric shock, fire or product failure. If the power cord is broken, do not plug it in. Take the product to an LG Electronics Authorised service repairer. Do not place the home station...
- Page 6 SAFETY PRECAUTIONS WARNING Do not spray or use Turn the power supply off immediately if any abnormal inflammable materials, sound, odor, or smoke is surfactants, or drinking water in the vicinity of the Robot generated from the Robot Cleaner by removing it from the Cleaner.
- Page 7 Do not put any water Doing so can cause product failure. or detergent on the Robot Cleaner. If liquids get inside of the Robot Cleaner, turn off the power supply and contact an LG Electronics sales agent or customer care center.
- Page 8 SAFETY PRECAUTIONS CAUTION If the floor is wet or has wet When the robot cleaner is operating, it may hit the chair spots, wipe them up before leg, desk leg, table leg or other using the Robot Cleaner. Do not use the Robot Cleaner on a narrow pieces of furniture.
-
Page 9: Included With Product
Pour plus de détails, veuillez consulter le manuel de l'utilisateur.a Après avoir lu le manuel d'utilisation, conservez-le dans un endroit Veuillez lire attentivement ce qui suit avant d'installer et de mettre en service le produit. facilement accessible à tout moment. www.lg.com www.lg.com Cleaning Tool Dust bin filter (spare) - Page 10 PARTS DESCRIPTION - ROBOT CLEANER Plan view Upper camera sensor Dust bin cover Display & function buttons Dust bin compartment release button Front view Ultrasonic sensors Obstacle detecting sensor window Detecting sensors of home station & Receiving sensors of remote controller Rear view Main Power switch Ventilation port...
- Page 11 PART DESCRIPTION – HOME STATION / DUST BIN Home station Remote controller holder Charging terminal Power switch Power cord fixing hook Dust bin Dust bin handle Cleaning brush Dust bin cover Suction port flap Sponge filter Dust bin lid opening button HEPA filter Filter cover s Figures can be different from actual objects.
-
Page 12: Button Functions
BUTTON FUNCTIONS – ROBOT CLEANER • If the button is pressed, ‘Turbo Mode’ will be set with a voice confirmation. TURBO • If the button is pressed whilst in ‘Turbo Mode’ , it will be canceled. • Used to turn the power on from Standby, start or stop cleaning. •... - Page 13 BUTTON FUNCTIONS – REMOTE CONTROLLER Home Used to recharge the Robot Start Cleaner by making it return to the Pressing this button will Home Station. (p18) start the cleaning. (p17) Mode Turbo Changes the cleaning Used to activate or deactivate mode.
-
Page 14: Display Status Information
DISPLAY STATUS INFORMATION Mute icon This icon indicates whether the Mute is ON or OFF. Battery icon This icon indicates the residual battery level, it flashes if Lock icon the battery needs Indicates whether 'Lock‘ recharging. is activated or not. AM/PM icon Schedule icon This indicates a.m. -
Page 15: Before You Start
BEFORE YOU START Check these items before cleaning • Do not use this device in a room where a child is left alone. The child could be injured. • Remove fragile or unnecessary objects from the room to be cleaned. Especially, remove expensive ceramics and valuables from the floor. -
Page 16: Overview
OVERVIEW Install the home station. (p15) 1.5 Insert the power cord plug into an outlet and locate 2 the station against a wall. If power is not supplied to 1.5 the home station, the Robot Cleaner will not charge. Turn on the power supply of the Robot Cleaner. -
Page 17: How To Install The Home Station
Do not operate the Robot Cleaner if the Home Station has a damaged cord or plug, if it is not working properly, or if it has been damaged or dropped. To avoid electrical hazards, the cord must be replaced by LG Electronics, Inc. or a qualified service person. -
Page 18: How To Turn The Robot Cleaner Power
HOW TO TURN THE ROBOT CLEANER POWER SUPPLY ON & OFF Turning on the main power supply Make sure the Power Switch is on at the rear-left of the Robot Cleaner. If the power is OFF, turn the switch ON. ※... -
Page 19: How To Start And Stop Cleaning
HOW TO START AND STOP CLEANING Using the buttons on the Robot Cleaner After the Robot Cleaner main power switch is turned on, press the START/STOP button to begin cleaning. A melody will sound and cleaning will begin. Press the START/STOP button during the cleaning cycle to stop cleaning. -
Page 20: How To Charge The Battery
HOW TO CHARGE THE BATTERY Automatic charging The Robot Cleaner returns to the home station at the end of a cleaning cycle or when its battery is running low. ※ If 10 minutes elapse without the Robot Cleaner moving or the battery is too low, the power will be automatically turned OFF. - Page 21 HOW TO CHARGE THE BATTERY Remaining Battery Charge Indicator The Battery level is indicated on the Status Display, as follows. • If recharging is in progress, the Battery Level indicator flashes showing the battery charge status level. • If recharging is complete, only the 'Battery' and 'Clean Mode' icons are displayed to save the energy. •...
-
Page 22: Cleaning Modes
CLEANING MODES Zigzag Cleaning In 'Zigzag' mode, Robot Cleaner repeats a zigzag operation to clean each and every spot in the cleaning area. If you need to quickly clean an area choose 'Zigzag' mode. Press ‘Mode’ button on Remote Controller or main unit to select 'Zigzag' mode and press 'Start' button. - Page 23 CLEANING MODES My Space Cleaning Pressing 'My Space' on the Remote Controller will set the My Space cleaning mode with a voice message. For cleaning of particular spaces, select this mode. The 1st stage: Use the Remote Controller to manually set the parameters of each cleaning block.
-
Page 24: Auxiliary Cleaning Modes
AUXILIARY CLEANING MODES Manual Cleaning By pressing a direction key on the Remote Controller, you can move the Robot Cleaner manually. Robot Cleaner will clean the area, by pressing the forward/backward/left/right buttons accordingly on the keypad of the remote control. While in 'Manual' mode, the robot cleaner will run into obstacles placed behind it if the backward key on the remote is pressed or held down. - Page 25 AUXILIARY CLEANING MODES Turbo Mode Pressing the 'Turbo' button on the Remote Controller or main unit will activate 'Turbo' mode, with a voice message. While in 'Turbo' mode, pressing the same button will cancel 'Turbo' mode, with a voice message. In 'Turbo' mode, Robot Cleaner runs more intensely for a powerful clean.
-
Page 26: Time Setting
TIME SETTING You can set or change the current time on the Robot Cleaner. Pressing ‘Clock' button on the Remote Controller, when the Robot Cleaner is in standby mode, will start the clock setting mode. Flickering Set the hour by using 'uv' buttons on Remote Controller. -
Page 27: Scheduled Cleaning
SCHEDULED CLEANING You can schedule cleaning so that the Robot Cleaner starts cleaning at a scheduled time. Pressing 'Schedule' button on Remote Controller, only when the Robot Cleaner is recharging, will start the scheduled cleaning setting. Setting/Cancelling the schedule cleaning is only possible when the unit is recharging on the home station Select ‘Once reservation’... -
Page 28: Mop Cleaning (Option)
MOP CLEANING (OPTION) By attaching the ultra microfiber mop, you can effectively use the Robot Cleaner to remove dust on hard floor surfaces. When the mop plate is attached, the Robot Cleaner will not climb on to carpets or over thresholds, in order to prevent transferring dirt Caution from the mop. -
Page 29: Location Search Function
LOCATION SEARCH FUNCTION The Robot Cleaner remembers its location while cleaning. If the user moves the Robot Cleaner while it is operating, it will search for the location it was moved from by using its navigational location search function before continuing to clean. -
Page 30: Smart Diagnosis
SMART DIAGNOSIS Robot Cleaner uses this Smart Diagnosis feature to run a self-diagnosis. If any irregularity is found from the diagnosis, please contact the local LG Electronics service center. ※ During Smart Diagnosis, the Robot Cleaner will move about within a 50 cm radius. So, make sure no objects are in the way within a 1 m radius around the Home Station, before starting Smart Diagnosis. - Page 31 Charging cannot be done due to a problem in infrared Run Smart Diagnosis again and, if the same message is sensor. announced, contact an LG Electronics service center. Charging cannot be done due to a problem in ultrasonic Run Smart Diagnosis again and, if the same message is sensor.
-
Page 32: Cleaning The Dust Bin
CLEANING THE DUST BIN If the dust bin is full, suction power can be reduced. Clean the dust bin before or after each cleaning session. Clean the dust bin using the following sequence: 1. Open the dust bin compartment cover by pressing the PUSH button on the Robot Cleaner. -
Page 33: Cleaning The Dust Bin Filter
CLEANING THE DUST BIN FILTER The Dust Bin Filter consists of a HEPA Filter and Sponge Filter. Clean both the HEPA and Sponge filters as per the following sequence. 1. Pull the hook on the left of the HEPA Filter module on the rear side of Dust Bin to separate the HEPA Filter and the sponge. -
Page 34: Cleaning The Brush
CLEANING THE BRUSH The rotating Brush, located on the bottom of Robot Cleaner, helps collect the dust. Clean the Brush as per the following sequence. ※ Before turning over the main unit, lay a soft cloth on the floor and remove the Dust Bin. Otherwise, the main unit can get scratched and dust will fall from the Dust Bin. -
Page 35: Cleaning The Sensor/Charging Terminal
CLEANING THE SENSORS/CHARGING TERMINALS There are sensors on the Robot Cleaner that detect obstacles, stairways and the home station for charging the battery. In order to maintain the performance of the Robot Cleaner, regularly clean the sensors and charging terminals as follows: 1. -
Page 36: Cleaning The Side Brush
CLEANING THE SIDE BRUSH Foreign objects/materials such as hair can easily adhere to the side brush. Remove such materials at least once a week. If excessive amounts of foreign materials are stuck to the brush, there is the risk of damage to the brushes. If the floor is rough or frequently cleaned, the side brushes may bend or become deformed. -
Page 37: Cleaning The Ultra Microfiber Mop (Option)
※ If the Mop is used in a damp or wet state, it will cause the Robot Cleaner to malfunction. • To avoid product malfunction, only use the ultra microfiber mop provided with the Robot Cleaner. • Additional microfiber mops can be purchased by visiting a nearby LG Electronics service center. -
Page 38: Troubleshooting
TROUBLESHOOTING Upon a voice message, "The wheels are not touching the floor. Please move Roboking onto flat floor." A warning message will be given if a wheel does not contact the floor surface for any reason. • Is a wheel trapped in the front door, balcony, stairway, etc? s Move the Robot Cleaner on to the flat floor. - Page 39 TROUBLESHOOTING Upon a voice message, "Please check if the dust bin is installed with the filter." A warning message will be given if there is no Dust Bin or Filter housing fitted. • Is the Dust Bin fitted to the Robot Cleaner? s Open the Dust Bin compartment cover and check to ensure the Dust Bin is in place.
- Page 40 TROUBLESHOOTING Upon a voice message, "Please remove foreign material from the brushes on the bottom." A warning message will be given if foreign materials restrict the Brush's rotation. Turn off the main power switch on the rear of the Robot Cleaner. Lay a soft cloth on the floor and put the Robot Cleaner upside down on it.
- Page 41 BEFORE YOU CALL FOR SERVICE Confirm before reporting the failure of Robot Cleaner. Problem Solutions (Reference page) The power supply cannot be Check that the power switch is turned on. (Page 16) turned on. The power supply This is not a failure. Robot Cleaner has its own power saving automatically turns off.
- Page 42 PRODUCT SPECIFICATIONS Item/Model LG Robot Cleaner VR627** Ser. / VR626** Ser. / VR647** Ser. / VR646**Ser. External Dimensions 340 mm × 340 mm × 89 mm Weight 3 kg Power Consumption 13 W Battery (Fully Charging) DC 16.8 V Traveling Velocity...
- Page 43 REFERENCE ITEMS Open source software notice To obtain the source code under GPL, LGPL, MPL and other open source licenses, that is contained in this product, please visit http://opensource.lge.com. In addition to the source code, all referred license terms, warranty disclaimers and copyright notices are available for download.
- Page 44 Disposal of waste batteries/accumulators 1. When this crossed-out wheeled bin symbol is attached to batteries/accumulators of Your product it means they are covered by European Directive 2006/66/CE. 2. This symbol may be combined with chemical symbols for mercury(Hg), cadmium(Cd) or lead(Pb) if the battery Contains more that 0.0005% of mercury, 0.002% of cadmium or 0.004% of lead.
